Kyocera TASKalfa 7002i Manual de usuario

TASKalfa 7002i

TASKalfa 8002i

TASKalfa 9002i

PF-730(B)/PF-740(B)

PF-7120/PF-7130

DF-7110

MT-730(B)

BF-730

PH-7A/PH-7C/PH-7D

FAX System 12

SERVICE

MANUAL

PublishedinDecember2021

Rev.5

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BAT-

TERIES ACCORDING TO THE INSTRUCTIONS.

It may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste

officials for details in your area for proper disposal.

ATTENTION

IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE DE TYPE

INCORRECT. METTRE AU REBUT LES BATTERIES UTILISEES SELON LES INSTRUCTIONS DONNEES.

Il peut être illégal de jeter les batteries dans des eaux d’égout municipales. Vérifiez avec les fonctionnaires

municipaux de votre région pour les détails concernant des déchets solides et une mise au rebut appropriée.

Notation of products in the manual

For the purpose of this service manual, products are identified by print speed.

Product name Print speed 100 V 120 V 220-240 V Australia

TASKalfa 9002i 90 ppm - ○○○

TASKalfa 7002i 80 ppm ○○○○

TASKalfa 8002i 70 ppm ○○○○

Revision history

Revision Date Pages Revised contents

1 30 June 2017 Contents

1-1 Correction: Warm-up Time

1-3 Correction: Power source, Note

1-4,1-5 Correction: Operating System

1-7 Correction: 4,000-Sheet Finisher: Space Required

2-2,2-3 Correction: Installation procedures

2-6 Correction: Procedures 8

2-29,2-31 Correction: Procedures Letter→A4,B5

2-37 Added: 120 V: 70/80 ppm model

2-43 Correction: Setting procedures 2

2-44 Correction: (18-1) Set up in a high altitude

2-99 to 2-101 Added: Cassette heater installed model as standard

2-136 Correction: Procedures 17, design

2-147 Correction: (1-3) bundled items

2-150 Correction: (1-6) parts name

2-154 to 2-164 Added: (14)Attach the optional cable

3-37 Correction: design, 21

3-88 Correction: design

4-2,4-3 Correction: (1) Maintenance kits Part No.

4-140 Added: Note

4-167 Correction: Procedures 10

4-169 Correction: Procedures 15 design

4-175 Correction: Procedures 7

4-244 Correction: Parts No. H-4, H-7

6-10 Correction: design (11)TonerLog

6-15 Correction: (11)TonerLog #

6-18 Correction: design

6-19 Correction: (4),(5)

6-22 Added:(87)Software version of option language

6-49 to 6-51 Correction: U053

6-40,6-55,6-

58,6-60,6-

62,6-64,6-167

Added:Note

U034,U065,U067,U070,U071,U072,U402

6-67 Correction: U087 Initial Setting value 48→125

6-71 Correction: U099 original Area

6-76 Added: U101

6-98 Correction: U140 Magnification Initial Setting

6-101 Added: U148 Note

1 6-103 Deletion: U156 B/W

6-105,6-107 Correction: U161 Contents Belt Mode, Belt Mode

6-109 Added: U167 Setting: Correction

6-110 Correction: U169 CT Mode Note

6-118 Added: U204 Parallel Coin Vender,Note

6-119 Added: U206 Note

6-140 Added: U246 Shift Front HP / Shift Tail HP

6-151 Correction: U253 DBL(A3/Ledger)/DBL(B4)

6-177,6-178 Correction: U411 Method: DP FD(ChartB), DP FD

(Chart A)

6-190 Added: U460 Conveying Sensor Note

6-195 Correction: U465 Contents: Laser Power

6-259 Correction: U964 Contents

6-264,6-265 Correction: U981 Background Of Printing, Thin

Concentration Initial Setting

7-382 Correction: C6000

7-392 Correction: C6200

8-1 to 8-129 Added: Connector list

9-2 Deletion: D4

9-12 to 9-14 Deletion: (original)

9-13,9-14 Correction: U066,U067 Rotate

9-27,9-30 Correction: (13),(16) design

9-31,9-32,9-

34,9-36,9-37

Correction: (1),(2),(4),(6),(7) design

2 24 January 2018 1-1, 1-4, 1-5 Added: 90 ppm model

1-6 Added: 90 ppm model

Correction: Transmission System *2

2-1, 2-37,2-

43,2-143

Added: 90 ppm model

2-144 Correction: Destination code list

2-153 Deletion: (2) 70 ppm/ 80ppm

3-13,3-24 Added: 2-2 (90 ppm) Engine PWB, LK-6722, LED PWB

Correction: Waste toner collection motor Parts No.

3-38, 3-89 Correction: Paper feeder (PF-7130) Block diagram

4-112,116 Correction: Procedures, Illust

4-148 to 4-150 Added: Detaching and reattaching the fuser discharge

needle unit

5-1, 5-3 Added: Engine firmware 90ppm model

6-4,6-119 Added: U208

6-17 to 6-22 Correction: Detail of service status page

6-38 to 6-40 Deletion: U034 70ppm/ 80ppm

Revision Date Pages Revised contents

2 6-44,6-45 Added: U051 Initial setting 90ppm

6-48 to 6-50 Added: U053 Initial setting 90ppm

6-56 to 6-59,6-

61,6-63

Deletion: Initial setting 70 ppm/ 80ppm

6-74 Added: U100 Initial setting 90ppm

6-76 to 6-80 Added: U106 Initial setting 90ppm

6-87 Added: U131 Initial setting 90ppm

6-96 Added: U147 Initial setting 90ppm

6-103 Added: U161 Initial setting 90ppm

6-125 Correction: U230 PF1→PF2, PF2→PF3

6-126 Correction: U237 Procedure

6-146 Correction: U250 Cassette1 to 7 Initial setting

6-166,6-167 Correction: U403, U404 left margin, right margin

6-190,6-191 Correction: U464 Initial setting: Leaving Time, Driving

Time

6-202 Correction: U600 Destination code (Country Code

default) list

8-50,8-51 Correction: YC24 Pin 1 to 38 →A1 to A19, B1 to B19

9-3 Correction: N5 10→60

9-4 Added: R0 (When DF-7110 is installed)

9-5 Added: R4 Cassette 5 to 7

9-21 Correction: (7) Feed PWB (3)

9-26 Correction: (12) CCD - Engine PWB

3 15 June 2018 Deletion; Firmware update

4 20 August 2019 3-27 Correction: Power source fan motor (302HN4401_ >

302K09430_)

5 8 December 2021 7-97 to 7-98

7-302 to 7-318

Added: Add JAM code (J7910 to J-7935)

Revision Date Pages Revised contents

This page is intentionally left blank.

Safety precautions

This booklet provides safety warnings and precautions for our service personnel to ensure the safety of

their customers, their machines as well as themselves during maintenance activities. Service personnel

are advised to read this booklet carefully to familiarize themselves with the warnings and precautions

described here before engaging in maintenance activities.

Safety warnings and precautions

Various symbols are used to protect our service personnel and customers from physical danger and

to prevent damage to their property. These symbols are described below:

DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect

compliance with warning messages using this symbol.

WARNING: Serious bodily injury or death may result from insufficient attention to or incorrect compliance

with warning messages using this symbol.

CAUTION: Bodily injury or damage to property may result from insufficient attention to or incorrect com-

pliance with warning messages using this symbol.

Symbols

The triangle ( ) symbol indicates a warning including danger and caution. The specific point of attention is

shown inside the symbol.

General warning. Warning of risk of electric shock.

Warning of high temperature.

indicates a prohibited action. The specific prohibition is shown inside the symbol.

General prohibited action. Disassembly prohibited.

indicates that action is required. The specific action required is shown inside the symbol.

General action required. Remove the power plug from the wall outlet.

Always ground the copier.

1. Installation Precautions

WARNING

• Do not use a power supply with a voltage other than that specified. Avoid multiple connections to

one outlet: they may cause fire or electric shock. When using an extension cable, always check that

it is adequate for the rated current. .....................................................................................................

• Connect the ground wire to a suitable grounding point. Not grounding the copier may cause fire or

electric shock. Connecting the earth wire to an object not approved for the purpose may cause

explosion or electric shock. Never connect the ground cable to any of the following: gas pipes, light-

ning rods, ground cables for telephone lines and water pipes or faucets not approved by the proper

authorities. ..........................................................................................................................................

CAUTION:

• Do not place the copier on an infirm or angled surface: the copier may tip over, causing injury. .........

• Do not install the copier in a humid or dusty place. This may cause fire or electric shock. .................

• Do not install the copier near a radiator, heater, other heat source or near flammable material. This

may cause fire. ...................................................................................................................................

• Allow sufficient space around the copier to allow the ventilation grills to keep the machine as cool

as possible. Insufficient ventilation may cause heat buildup and poor copying performance. ............

• Always handle the machine by the correct locations when moving it. .................................................

• Always use anti-toppling and locking devices on copiers so equipped. Failure to do this may cause

the copier to move unexpectedly or topple, leading to injury. ..............................................................

• Avoid inhaling toner or developer excessively. Protect the eyes. If toner or developer is accidentally

ingested, drink a lot of water to dilute it in the stomach and obtain medical attention immediately.

If it gets into the eyes, rinse immediately with copious amounts of water and obtain medical atten-

tion. .....................................................................................................................................................

• Advice customers that they must always follow the safety warnings and precautions in the copier’s

instruction handbook. .........................................................................................................................

2. Precautions for Maintenance

WARNING

• Always remove the power plug from the wall outlet before starting machine disassembly. ................

• Always follow the procedures for maintenance described in the service manual and other related

brochures. ..........................................................................................................................................

• Under no circumstances attempt to bypass or disable safety features including safety mechanisms

and protective circuits. ........................................................................................................................

• Always use parts having the correct specifications. ............................................................................

• Always use the thermostat or thermal fuse specified in the service manual or other related brochure

when replacing them. Using a piece of wire, for example, could lead to fire or other serious acci-

dent. ...................................................................................................................................................

• When the service manual or other serious brochure specifies a distance or gap for installation of a

part, always use the correct scale and measure carefully. ..................................................................

• Always check that the copier is correctly connected to an outlet with a ground connection. ...............

• Check that the power cable covering is free of damage. Check that the power plug is dust-free. If it

is dirty, clean it to remove the risk of fire or electric shock. .................................................................

• Never attempt to disassemble the optical unit in machines using lasers. Leaking laser light may

damage eyesight. ...............................................................................................................................

• Handle the charger sections with care. They are charged to high potentials and may cause electric

shock if handled improperly. ...............................................................................................................

CAUTION

• Wear safe clothing. If wearing loose clothing or accessories such as ties, make sure they are safely

secured so they will not be caught in rotating sections. ......................................................................

• Use utmost caution when working on a powered machine. Keep away from chains and belts. ..........

• Handle the fixing section with care to avoid burns as it can be extremely hot. ..................................

• Check that the fixing unit thermistor, heat and press rollers are clean. Dirt on them can cause

abnormally high temperatures. ...........................................................................................................

Otros manuales para TASKalfa 7002i

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Kyocera

Kyocera

Kyocera ECOSYS P7240cdn Manual de referencia

Kyocera

Kyocera TASKALFA 300I Manual de usuario

Kyocera

Kyocera Copystar CS 3011i Manual de usuario

Kyocera

Kyocera FS-3040MFP Manual de usuario

Kyocera

Kyocera PE-MF2 Manual de usuario

Kyocera

Kyocera ECOSYS FS-C8650DN Manual de usuario

Kyocera

Kyocera TASKalfa 650c Instrucciones originales

Kyocera

Kyocera KM-1530 Manual

Kyocera

Kyocera KM-C2630D Manual de usuario

Kyocera

Kyocera TASKALFA 300I Manual de usuario

Kyocera

Kyocera FS-1024MFP Manual de usuario

Kyocera

Kyocera FS-C5100DN Manual de usuario

Kyocera

Kyocera KM-2550 Manual de usuario

Kyocera

Kyocera KM-8030 Manual de usuario

Kyocera

Kyocera ECOSYS MA4500fx Manual de usuario

Kyocera

Kyocera FS-1018MFP Manual de usuario

Kyocera

Kyocera FS-1128MFP Instrucciones de instalación y mantenimiento

Kyocera

Kyocera ECOSYS M5526cdw Manual de instrucciones

Kyocera

Kyocera TASKalfa 5551ci Manual de usuario

Kyocera

Kyocera KM-2560 Manual de usuario

Kyocera

Kyocera TASKalfa 500ci Series Manual de usuario

Kyocera

Kyocera ECOSYS PA3500cx Manual de usuario

Kyocera

Kyocera FS-C1020MFP Manual de usuario

Kyocera

Kyocera TASKalfa 7052ci Manual de instalación y funcionamiento

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
