Kyla Smart Temperature/ Humidity Sensor Manual de usuario
User Guide
Thanks for using Aztech Kyla product
If you need support or help,
please visit www.kyla.aztech.com
Smart Temperature/
Humidity Sensor
01
Product Description 02
The Smart Temperature/Humidity Sensor
monitors home temperature and humidity
values anywhere even when out of home. It
adopts ultra-low power consumption
Zigbee wireless network technology. With
dust-proof and insect-proof function, the
product is designed to secured.
With high-precision temperature and
humidity built-in sensor, it can perceive and
report temperature and humidity
conditions in real-time through App. The
product is suitable for environmental
monitoring in residentials, factory buildings,
computer rooms, shopping malls, hotels,
office buildings, banks, libraries, as well as
warehouses and many other places.
03
Operation Guide
Step 1:
Download Aztech Kyla App from
Google Play/App Store
Step 2:
Login to Aztech Kyla App, then add “Smart
Temperature/ Humidity Sensor” to device
list to enable the device.
Aztech Kyla App
04
Step 3:
Remove battery insulation film to power on.
05
Step 4:
Following the App instructions, long press
the device’s networking key until the green
LED flashes. The App will be prompted once
connected succesfully to the network.
Network Status
Lamp
Network
Key
06
Step 5:
Tear off the gummed film then stick the
equipment to the required area.
07
Step 6:
Note that the mounting base shall be
upright as shown on the diagram below.
Finally, hang the Smart Temperature/
Humidity Sensor onto the mounting base.
08
Technical
Specications
Working Voltage
DC3V (1* CR2450 Button Battery)
Standby Current
≤ 10uA
Networking Mode
Zigbee Ad-Hoc Network
Wireless Networking Distance
≤ 100m (Open Area)
Working Environment
-15 ~ 60°C
Working Humidity
Max 95% RH
Product Dimensions
79 x 68 x 31mm
©2018 Aztech Technologies Pte Ltd.
All rights reserved.
