Kwikset SmartCode 912 Instrucciones de funcionamiento

Programming and Troubleshooting Guide

Mastercode 2

Troubleshooting: Locked Turnbutton 6

Troubleshooting: Keypad 7

Troubleshooting: Smart Home Systems 8

Troubleshooting: Battery 10

Battery FAQ 11

62813 / 01

1 / 11

Technical Support

1-866-863-6584

www.kwikset.com

Mastercode

Programming timeout: If no button is pressed for ve seconds, the system will time out

and you will need to restart the procedure.

1. Keep door open. Press and HOLD the Program button until the keypad

ashes green (about 5 seconds).

2. Enter new Mastercode.

3. Press Lock button once.

4. Re-enter Mastercode.

5. Press Lock button once.

If programming is successful, the keypad will flash green once with

one beep.

If programming is unsuccessful, the keypad will ash red three times

with three beeps. Make sure the Mastercode has not already been

programmed. Attempt the procedure again, making sure to enter the

same new Mastercode in step 2 and 4.

6. Make sure switch #3 is on, and press the Program button once. If

you hear three beeps and see the keypad ash green three times, the

Mastercode is enabled.

Note: The lock will time out after ve seconds.

Using a Mastercode is an optional, added-security measure. It is not enabled by default. A Mastercode is

used to add and delete user codes, but it cannot unlock the door (unless the same code is programmed

as a user code, though this is not recommended). The Mastercode must be 4-8 digits.

62813 / 01

2 / 11

Technical Support

1-866-863-6584

www.kwikset.com

About the Mastercode

Enabling and Setting the Mastercode

1. Keep door open. Press the Program button once. The keypad will ash

green and you will hear three beeps.

2. Enter Mastercode.

3. Press Lock button once.

4. Press the Program button the number of times that corresponds to

the user code position being programmed.

Example: If programming the third code, press the button three times.

5. Enter new user code.

6. Press Lock button once.

The procedure for adding user codes is different when the Mastercode is enabled. For instuctions on how

to add user codes when the Mastercode is disabled, see the Installation and User Guide that came with

your lock.

Procedure continued on next page

62813 / 01

3 / 11

Technical Support

1-866-863-6584

www.kwikset.com

CAdding User Codes with the Mastercode Enabled

If programming is successful, the keypad will flash green once with

one beep.

If programming is unsuccessful, the keypad will ash red three times

with three beeps. Make sure the user code is not a duplicate and that it

is between 4 and 8 digits during your next attempt. Make sure to enter a

valid Mastercode in step 2.

7. While the door is open and locked, test the user code to make

sure it unlocks the door.

62813 / 01

4 / 11

Technical Support

1-866-863-6584

www.kwikset.com

1. Keep door open. Press and HOLD the Program button until the keypad

ashes green (about 5 seconds).

2. Press Lock button once.

3. Enter Mastercode.

4. Press Lock button once.

5. Re-enter Mastercode.

6. Press Lock button once.

If programming is successful, the keypad will flash green once with

one beep.

If programming is unsuccessful, the keypad will ash red three times with

three beeps. Make sure the Mastercode has been enabled before trying

to disable it. Attempt the procedure again, making sure to enter the same

Mastercode in steps 3 and 5.

7. Make sure switch #3 is on, and press the Program button once. If you

don’t immediately hear three beeps and see the keypad ash green

three times, the Mastercode is disabled.

Note: The lock will time out after ve seconds.

62813 / 01

5 / 11

Technical Support

1-866-863-6584

www.kwikset.com

DDisabling and Deleting the Mastercode

Troubleshooting: Locked Turnbutton

The set screw in the lever was not fully

tightened.

Fully tighten the pre-installed set screw at the bottom of the interior

lever.

62813 / 01

6 / 11

Technical Support

1-866-863-6584

www.kwikset.com

AThe turnbutton cannot rotate.

BB The lock beeps, the keypad ﬂashes red, and the door cannot lock or unlock.

Troubleshooting: Keypad

Keypad error test

Install a fresh set of batteries and turn switch #3 to the ON position. Test

each button on the keypad (one at a time) and listen for a beep on each

button press. If beeping is not heard on all buttons, contact Technical

Support for further troubleshooting.

Keypad lockout

If three incorrect codes were entered within one minute, the keypad will

lock for 60 seconds.

No user codes are programmed.

If there are no codes in the lock, the lock button will not lock the door.

This is indicated by the keypad ashing red three times with three

beeps. Program at least one user code and test the Lock button again.

The battery is too low to lock the door.

This is indicated by the keypad ashing red three times with three beeps.

Remove the batteries and replace with a fresh set.

The set screw in the lever was not fully

tightened.

Fully tighten the pre-installed set screw at the bottom of the interior

lever.

62813 / 01

7 / 11

Technical Support

1-866-863-6584

www.kwikset.com

The keypad is unresponsive.

The Lock button does not lock the door.

Troubleshooting: Smart Home Systems

The lock was not removed completely from

another network before being paired with the

new network.

Follow your smart home system’s instructions to remove (exclude/unpair)

the device from any other network. Then, attempt to pair (add/include)

the lock again.

The lock is not close enough to the controller.

Some Z-wave systems require that the lock be within 12” of the

controller during the pairing process. If the lock has already been

installed on the door, remove the interior assembly from the mounting

plate. Make sure the batteries are installed, and bring the interior

assembly next to the controller. Follow your smart home system’s

instructions to begin pairing at the controller. The lock may need to

remain stationary for 60 seconds during pairing.

Z-Wave

Controller

12"

305 mm

Note: Some locks have an anti-tamper alarm that will sound if the

interior is disconnect from the exterior. If this alarm is heard, perform the

following:

a. Remove the battery pack from the interior.

b. Remove the exterior assembly from the door.

c. Connect the cable from the exterior assembly to the interior

assembly.

d. Reinstall the battery pack.

e. Perform the pairing process while the interior and exterior are

connected.

Z-Wave

Controller

12"

305 mm

62813 / 01

8 / 11

Technical Support

1-866-863-6584

www.kwikset.com

AThe lock fails to pair with a smart home system.

The system needs a repeater or router to

reach the lock.

Adding repeaters to your system may help communication between your

lock and the controller, especially if they are far away from each other.

The network conﬁguration changed.

If any repeaters or routers in the system were moved since adding the

lock to the system, perform the “rediscover” process in your system’s

user interface.

The lock is in sleep mode.

If the lock has been unable to communicate with the system after

multiple attempts, it will go into sleep mode. Lock and unlock the door

with a key so that the lock status transmits to the system. If it still does

not communicate, remove (exclude/unpair) the lock from your system.

Then, pair (add/include) the lock with your system again. If the problem

persists, add a repeater or router between the controller and lock if none

presently exist in the system.

The light module or switch is not beaming

capable.

Z-Wave locks: Ensure the light module or switch located between the

controller and lock is beaming capable.

ZigBee locks: Ensure the router is reachable by both controller and lock.

62813 / 01

9 / 11

Technical Support

1-866-863-6584

www.kwikset.com

BI can see the lock in my controller, but I can’t control it from the controller.

Troubleshooting: Battery

The lock must be replaced. Contact Technical Support.

Keypad error.

See “Keypad error test” on page 7.

The Wireless Card LEDs are staying on.

Remove the battery pack, press and hold the program button for ve

seconds. Replace the battery pack. If the Wireless Card LEDs continue

to stay on, contact Technical Support.

The smart home system’s user interface falsely

reports a low battery.

If you receive an alert from your smart home system indicating that

the battery is low, conrm this is true at the lock. Turn on switch #1 so

that the status LED ashes every six seconds. If the LEDs turn amber

or green, followed by a red ash, the battery is low. If the red ash is

not seen, the battery is not low. This is an error on the smart home

system side that will often be xed when the lock is manually locked or

unlocked.

The smart home system controller’s

communication with the lock is draining the

battery.

Remove the lock from your system. Put a new set of batteries in the

lock. Operate the lock in stand-alone mode for a week. If the batteries

drain within the week, the problem resides in the lock. If the batteries do

not drain, the problem may be the smart home controller. Call Technical

Support.

The smart home system controller’s ping

frequency is too high.

Decrease the ping frequency from the controller to the lock to the lowest

possible setting.

62813 / 01

10 / 11

Technical Support

1-866-863-6584

www.kwikset.com

The batteries drain within one day.

The batteries drain within one week.

The batteries drain within a few weeks.
