KTI Networks KS-115F Series Manual de usuario
-12-
Installation Guide
10/100 Fast Ethernet Switch
KS-115FSeries
P/N:750-0136-001
DOC.000112-KS115F-K
-13-
1999 KTI Networks Inc. All rights reserved. No part of this documen-
tation may e reproduced in any form or y any means or used to make
any directive work (such as translation or transformation) without per-
mission from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to
make changes in content from time to time without o ligation on the part
of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: 713-2663891
Fax: 713-2663893
E-mail: [email protected]
WWW: http://www.ktinet.com/
International Fax: 886-2-26983873
E-mail: [email protected]
WWW: http://www.ktinet.com.tw/
-15-
The information contained in this document is subject to change without prior notice.
Copyright KTI. A Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
This device complies with Class A Part 5 the FCC Rules. Operation is subject to the following two
conditions: ( ) This device may not cause harmful interference, and (2) this device must accept any
interference received including the interference that may cause.
CISPRACOMPLIANCE:
This device complies with EMC directive of the European Community and meets or exceeds the follow-
ing technical standard.
EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information
Technology Equipment. This device complies with CISPR Class A.
WARNING: This is a Class A product. In a domestic environment this product may cause radio inter-
ference in which case the user may be required to take adequate measures.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the
European Community. Such marking is indicative that this equipment meets or exceeds the following
technical standards:
EN 55022: Limits and Methods of Measurement of Radio Interference characteristics of Information
Technology Equipment.
EN 50082/ :Generic Immunity Standard -Part : Domestic Commercial and Light Industry.
EN 60555-2: Disturbances in supply systems caused by household appliances and similar electrical equip-
ment - Part 2: Harmonics.
-16-
Table of Contents
1. Introduction ................................................................................. 1
1.1 Features ................................................................................................................. 2
1.2 Specifications ....................................................................................................... 3
2. Installing the Switch ................................................................... 4
2.1 Unpacking ............................................................................................................ 4
2.2 Checking AC Power ............................................................................................ 4
2.3 nstalling the Switch ............................................................................................ 5
3. Making Network Connections ....................................................
3.1 Network Switched Ports ..................................................................................... 6
3.2 UTP Cable ............................................................................................................ 7
3.3 Fiber Cable ............................................................................................................ 8
3.4 Network Connections ......................................................................................... 9
3.5 Operating Mode ................................................................................................. 1 0
4. LED Indicators ............................................................................ 11
4.1 LED Panel .......................................................................................................... 1 1
4.2 nterpretation .................................................................................................... 1 1
-1-
1. Introduction
Driven y recent advances in desktop computing technology, todays
network applications have increased in speed, power and the a ility to
process information. To meet the demands of these more powerful appli-
cations, this afforda le switch device provides significant increase in
performance for your Ethernet or Fast Ethernet network. This 5-port Fast
Ethernet switch comes with four 10/100 TP ports and one fi er port, each
capa le of transmitting or receiving information simultaneously at full
wire speed to control and allocate the network andwidth.
The key features of this switch unit are:
Optimized Bandwidth : Com ining five 10/100M ps- ased Fast
Ethernet switched ports, the switch delivers a high network
andwidth for your Fast Ethernet network
Easy Migration : With 10BASE-T support on each port, the switch
provides a non-disruptive and smooth migration path from
Ethernet to a Fast Ethernet network.
Fiber Uplink Support : With 100BASE-FX port, the switch provides
a connectivity to a Fast Ethernet network via fi er ca le.
Easy Installation : With the functions of auto-speed-sensing and
auto-negotiation on each port, the switch supports plug-and-play
installation which eliminates configuration pro lems.
-2-
1.1 Features
Designed for resolving congestion pro lems caused y andwidth-hun-
gry devices and andwidth-intensive applications as well as a high num-
er of users, the switches not only adhere to the IEEE 802.3 10BASE-T,
802.3u 100BASE-TX and 100BASE-FX standards, ut also feature:
Four 10/100BASE-TX auto-negotiation switched ports and one
100BASE-FX port for flexi le connections to desktop PCs, servers
and Ethernet hu s.
The 10/100BASE-TX switched ports support:
- auto speed sensing for 100M ps or 10M ps connection
- auto configuration with auto-negotiation devices
- full-duplex or half-duplex operation
For the fi er port, the switch series support variety of fi er connec-
tors for different application needs. The fi er connectors include
ST, SC, MT-RJ, and VF-45 types for multimode and single mode
fi er ca les.
Supports duplex mode selector for the 100BASE-FX fi er port.
Self learning for active MAC addresses
Store and forward switching to ensure only good packets are forwarded
Forwarding and filtering at full wire speed
Supports IEEE 802.3x flow control for full-duplex operation
Supports ack-pressure flow control for half-duplex operation
Comprehensive LED indicators provide quick, easy to read port
and switch information
-3-
1.2 Specifications
Port 1 - 4 MDI-X RJ-45 jacks for 10/100BASE-TX connectivity
Port 5 One fi er connector for 100BASE-FX connectivity
Cables 10BASE-T Cat. 3, 4, 5 UTP ca le (100 meters max.)
100BASE-TX Cat. 5 UTP ca le (100 meters max.)
100BASE-FX multimode or single mode fi er ca le
LED indicators Power status
10/100M, Link/Activity,Duplex/Collision status per port
Filtering rate 14,880 pps for Ethernet (10BASE-T)
148,800 pps for Fast Ethernet (100BASE-TX)
Forwarding rate 14,880 pps for Ethernet (10BASE-T)
148,800 pps for Fast Ethernet (100BASE-TX)
Filtering address Multicast/Broadcast/Unicast address
8K MAC addresses per unit
RAM buffers 256KB
Environment Temperature 0oC to 40oC
Relative humidity 10% to 90% non-condensing
Dimensions 144 mm x 100 mm x 26 mm (WxDxH)
5.67 x 3.94 x 1.02 inch
Power +5V 1.2A minimum
Models vs Fiber Specifications
Model Connector Fiber Cable Max. Distance
KS-115F/T ST MM*1 2Km
KS-115F/C SC MM 2 Km
KS-115F/SA SC SM*2 15 Km
KS-115F/S3 SC SM 30 Km
KS-115F/S5 SC SM 50 Km
KS-115F/JM MT-RJ MM 2 Km
KS-115F/JS MT-RJ SM 15 Km
KS-115F/VM VF-45 MM 2 Km
KS-115F/VS VF-45 SM 15 Km
*1 : Multimode fiber
*2 : Single Mode fiber
-4-
2. Installing the Switch
2.1 Unpacking
Check to see that you have everything efore you start the installation.
Installation guide
The switch unit
One AC power adapter for the unit
2.2 Checking AC Power
Before you egin the installation, check the AC voltage of your area. The
AC power adapter which is used to supply the DC power for the unit should
have the AC voltage matching the commercial power voltage in your area.
The specifications of the AC power adapter are:
AC input power: AC power voltage of your area
DC output power: +5V VDC 1.2A min.
DC plug type:
-5-
The DC power socket for the AC power adapter is located on the rear of
the switch as shown elow:
2.3 Installing the Switch
1. Install the switch with the AC power adapter provided.
2. Connect the power adapter ca le to the switch efore connecting
the adapter to the AC outlet.
-6-
3. Making Network Connections
3.1 Network Switched Ports
There are five ports on the switch for connection to five LAN segments.
Each segment is an independent shared network in one collision-domain.
Four 10/100BASE-TX switched ports
Each port consists of one RJ-45 connector and is used for connection to
either a 10BASE-T or 100BASE-TX device. The RJ-45 connectors are fixed
MDI-X jacks which are designed with internal crossover function. It allows
a connection to an end station using straight-through UTP ca le.
One 100BASE-FX fiber switched port
This fi er port comes with one fi er connector. For ST and SC
connectors, the contact la eled TX is used for transmission and
the other one la eled RX is used for reception. One duplex mode
selector is located on the rear panel. Either full duplex or half duplex
mode can e selected (factory default: full-duplex).
