Kramer 4x1V Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODELS:

4x1V and 4x1VB

4:1Video Switchers

P/N: 2900-300162 Rev 1

4x1V and 4x1VB – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1Achieving the Best Performance 2

3Overview 3

3.1Defining the 4x1V and 4x1VB 4:1 Video Switchers 3

4Connecting and Operating the 4x1V and 4x1VB 5

5Technical Specifications 7

Figures

Figure 1: 4x1V and 4x1VB 4:1 Video Switchers 4

Figure 2: Connecting the 4x1V and 4x1VB 4:1 Video Switchers 6

4x1V and 4x1VB - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix

Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;

GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;

GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and

GROUP 11: Sierra Products.

Congratulations on purchasing your Kramer 4x1V or 4x1VB 4:1 Video Switchers,

which are ideal for the following typical applications:

•Presentation and display systems

•CCTV and home theater applications

•Rental and staging applications

•Also compatible with any other high frequency signal

2 4x1V and 4x1VB - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Position your Kramer 4x1V and 4x1VB away from moisture, excessive

sunlight and dust

4x1V and 4x1VB - Overview 3

3 Overview

The KramerTOOLS 4x1V and 4x1VB are high-quality 4x1 mechanical switchers

designed for composite video signals using RCA or BNC connectors. They accept

up to four inputs and let you select any input to be routed to one output using

buttons located on the front panel. High-quality switching components ensure

minimal crosstalk and a high bandwidth of 400MHz (-3dB).

The entirely passive design of the 4x1V and 4x1VB eliminates the need for a

power supply. Unselected inputs are automatically terminated into a 75Ωresistor.

3.1 Defining the 4x1V and 4x1VB 4:1 Video Switchers

This section defines the 4x1V and 4x1VB.

4 4x1V and 4x1VB - Overview

Figure 1: 4x1V and 4x1VB 4:1 Video Switchers

# Feature Function

1 OUTPUT Connector Connect to the composite video acceptor

RCA connector (4x1V), BNC connector (4x1VB)

2 IN 1 to IN 4 Connectors Connect to the composite video sources (1 to 4)

RCA connectors (4x1V), BNC connectors (4x1VB)

3 INPUT SELECTOR

Buttons

Buttons for choosing the input CV source

4x1V and 4x1VB - Connecting and Operating the 4x1V and 4x1VB 5

4 Connecting and Operating the 4x1V and

4x1VB

To connect the 4x1V and 4x1VB as illustrated in the example in Figure 2:

1. Connect up to four composite video sources to the IN 1 to IN 4 connectors

(for example, composite video players).

You do not have to connect all inputs.

2. Connect the OUTPUT connector to a composite video acceptor (for

example, a composite video recorder).

Note: The 4x1V uses RCA connectors. The 4x1VB uses BNC

connectors.

To operate the 4x1V and 4x1VB:

Press an INPUT SELECTOR button to switch the desired source to the output.

6 4x1V and 4x1VB - Connecting and Operating the 4x1V and 4x1VB

Figure 2: Connecting the 4x1V and 4x1VB 4:1 Video Switchers

4x1V and 4x1VB - Technical Specifications 7

5 Technical Specifications

INPUTS: 4 video, 1Vpp/75Ωon RCA connectors (4x1V) or BNC

connectors (4x1VB)

OUTPUT: 1 composite or single component video, 1Vpp/75Ωon an

RCA connector (4x1V) or BNC connector (4x1VB)

BANDWIDTH (-3dB): 400MHz

SWITCHING SYSTEM: Mechanical, break-before-make

OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)

STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)

HUMIDITY: 10% to 90%, RHL non-condensing

DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.9" x 1")

WEIGHT: 0.28kg (0.62lbs) approx. (4x1V)

0.30kg (0.67lbs) approx. (4x1VB)

OPTIONS: RK-3T 19” rack adapter

Specifications are subject to change without notice at http://www.kramerelectronics.com
