Kramer DigiTOOLS KW-11T Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODELS:

KW-11T

Wireless High Definition

Transmitter

KW-11R

Wireless High Definition

Receiver

P/N: 2900-300194 Rev 8

KW-11T/KW-11R – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Recycling Kramer Products 3

2.3 Accessory to Medical Equipment (IEC 60601-1) 3

3Overview 4

4Defining the KW-11T/KW-11R Line Transmitter and Receiver 5

4.1 Defining the KW-11T Wireless High Definition Transmitter 5

4.2 Defining the KW-11R Wireless High Definition Receiver 6

5Connecting the KW-11T and KW-11R 7

5.1 Connecting the KW-11T and KW-11R 7

6Frequently Asked Questions 9

7Technical Specifications 10

7.1 Supported Video Formats 11

7.2 KW-11T Mini USB Pinout 11

8FCC Radio Frequency Interference Statement 12

Figures

Figure 1: KW-11T Wireless High Definition Transmitter Top and Side Panels 5

Figure 2: KW-11R Wireless High Definition Receiver Front and Rear Panels 6

Figure 3: Connecting the KW-11T and KW-11R 7

Figure 4: KW-11T Mini USB Pinout 11

KW-11T/KW-11R - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; and GROUP 13: Audio, and

GROUP 14: Collaboration.

Thank you for purchasing the Kramer KW-11T Wireless High Definition

Transmitter and DigiTOOLS®KW-11R Wireless High Definition Receiver which

are ideal for:

Home theater

Presentation and multimedia applications

Short range video and audio distribution

KW-11T/KW-11R - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Always mount the KW-11R vertically using the supplied stand

Do not place objects next to the KW-11T transmitter or KW-11R receiver

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer KW-11T and KW-11R away from moisture, excessive

sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building

KW-11T/KW-11R - Getting Started

2.2 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

2.3 Accessory to Medical Equipment (IEC 60601-1)

In the modern medical environment remote access is essential, for example, to

transfer clinical data between doctors and to train to medical students. Both the

KW-11T and KW-11R are certified according to the IEC 60601-1-2, Clause 2.1.3,

Medical Electrical Equipment, Part 1: General Requirements for EMC standard

which is required when accessory devices are used at locations where medical

personnel and patients are present.

The KW-11T and KW-11R constitute an optional component that can be

considered necessary and suitable as part of medical equipment or for use as part

of a medical system to provide real time simultaneous video feeds to those

present at the local medical environment and at remote locations. In this

environment, the KW-11T and KW-11R can be added to the system ONLY if the

connecting equipment has been evaluated and meets the IEC 60601-1-2 EMC

standards. Note, that when attaching accessory devices to a digital or analog

interface, they must comply with the IEC standard for which they are used: for

EMC Standard (IEC 60601-1-2), Information Technology equipment (IEC 60950-1

(2ed)).

KW-11T/KW-11R - Overview

3 Overview

The KW-11T and KW-11R is a high-definition, wireless, HDMI transmitter and

receiver combination for indoor use over short range distances.

The KW-11T converts an HDMI signal into a wireless signal. The KW-11R

converts the wireless signal back into HDMI.

The KW-11T and KW-11R support:

Uncompressed video resolutions up to 1080p @60Hz

Zero latency

EDID

HDCP

CEC

OSD (On Screen Display)

Secure link using AES-128 bit encryption

A transmission range of up to 12m (39ft)

Medical equipment compliance requirements

KW-11T/KW-11R - Defining the KW-11T/KW-11R Line Transmitter and Receiver

4 Defining the KW-11T/KW-11R Line

Transmitter and Receiver

This section defines the:

KW-11T Wireless High Definition Transmitter (see Section 4.1)

KW-11R Wireless High Definition Receiver (see Section 4.2)

4.1 Defining the KW-11T Wireless High Definition

Transmitter

The KW-11T encodes an HDMI signal and transmits it uncompressed and without

delay over a wireless link to the KW-11R receiver. Figure 1 defines the top and

side panels of the KW-11T.

Figure 1: KW-11T Wireless High Definition Transmitter Top and Side Panels

Feature

Function

Code Button

For factory use only

VIDEO LED

Lights green when there is a valid HDMI input signal

CONNECTED LED

Indicates the following:

Lights blue when there is a wireless connection to the receiver

Does not light when there is no connection

Flashes to indicate a device fault

HDMI Input Connector

Connect to the HDMI source (see Section 5)

POWER Mini-USB

Connector

Connect to the supplied 5V DC USB power adapter

KW-11T/KW-11R - Defining the KW-11T/KW-11R Line Transmitter and Receiver

4.2 Defining the KW-11R Wireless High Definition Receiver

The KW-11R receives the wireless signal from the Kramer KW-11T and converts

it into an HDMI output.

Figure 2 defines the front and rear panels of the KW-11R.

Figure 2: KW-11R Wireless High Definition Receiver Front and Rear Panels

Feature

Function

Code Button

For factory use only

Infrared Receiver

Window

For factory use only

VIDEO LED

Lights green when there is a valid HDMI signal

CONNECTED LED

Indicates the following:

Lights green when there is a wireless connection to the transmitter

Does not light when there is no connection

Flashes to indicate a device fault

USB Connector

For the use of Kramer service personnel only

HDMI OUT Connector

Connect to the HDMI acceptor (see Section 5)

POWER Connector

Connect to the supplied +5V DC power adapter. Center pin positive

KW-11T/KW-11R - Connecting the KW-11T and KW-11R

5 Connecting the KW-11T and KW-11R

Always switch off the power to all devices before connecting your

KW-11T and KW-11R.

5.1 Connecting the KW-11T and KW-11R

Note: For best performance always mount the KW-11R receiver vertically using

the supplied stand.

Figure 3: Connecting the KW-11T and KW-11R
