Kramer Electronics, Ltd.

USER MANUAL







Model:

VS-808DS

8x8 Video Audio Matrix Switcher / Scaler

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

Your VS-808DS 8x8 Video Audio Matrix Switcher / Scaler 3

Installing on a Rack 7

Connecting the VS-808DS 8

6.1

Connecting a PC 10

6.2

Connecting via RS-485 11

6.3

Setting the VS-808DS Dipswitches 12

6.3.1

Setting the SELF ADDRESS Dipswitches 12

6.3.2

Setting the REPLY Dipswitch 13

6.3.3

Setting the RS-232/RS-485 Dipswitch 13

Operating Your VS-808DS 14

7.1

Displaying the Unit Characteristics 14

7.2

Selecting and Connecting an Output and/or Input 14

7.3

Choosing the Audio-Follow-Video or Breakaway Option 15

7.3.1

Setting the Audio-Follow-Video Option 15

7.3.2

Setting the Breakaway Option 15

7.4

Confirming Settings 15

7.4.1

Toggling between the At Once and Confirm Modes 16

7.4.2

Confirming a Switching Action 16

7.5

Storing/Recalling Input/Output Configurations 17

7.5.1

Storing an Input/Output Configuration 17

7.5.2

Recalling an Input/Output Configuration 17

7.5.3

Deleting an Input/Output Configuration 17

7.6

Resetting the Machine 17

Technical Specifications 18



Table of Hex Codes for the Master VS-808DS 19

Communication Protocol 20

Figures

Figure 1: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Front Panel 4

Figure 2: Connecting the VS-808DS 8x8 Video Audio Matrix Switcher / Scaler 9

Figure 3: Connecting a PC without using a Null-modem Adapter 10

Figure 4: Controlling via RS-485 (for example, using an RC-3000) 11

Figure 5: VS-808DS Dipswitches 12

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Tables

Table 1: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Front Panel Features 5

Table 2: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Rear Panel Features 6

Table 3: Dipswitch Settings 12

Table 4: Self Address # Dipswitch Settings 13

Table 5: Technical Specifications of the VS-808DS 18

Table 6: Hex Codes for Switching the Master VS-808DS 19

Table 7: Protocol Definitions 20

Table 8: Instruction Codes 21

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video, audio

and presentation professional on a daily basis. In recent years, we have redesigned

and upgraded most of our line, making the best even better! Our 500-plus

different models now appear in 8 Groups

, which are clearly defined by function.

Congratulations on purchasing your Kramer VS-808DS 8x8 Video Audio

Matrix Switcher / Scaler!It is ideal for:

Audio/video duplication

Production studios

Professional presentation systems

The package includes the following items:

VS-808DS 8x8 Video Audio Matrix Switcher / Scaler

Power cord and Null-modem adapter

Windows®-based Kramer control software

Remote IR cable (optional)

Infra-red remote control transmitter (including the required batteries and a

separate user manual

) and this user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation:

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Downloadable from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Video

Player

Video Recorder

LCD Display

Overview

3 Overview

The VS-808DS 8x8 Video Audio Matrix Switcher / Scaler is a high

performance matrix switcher for composite video and unbalanced stereo

audio signals. It lets you simultaneously route any or all of the eight inputs to

any or all of the eight outputs, plus one scaled output

(that is, output 8 also

goes to the Scaler). Switching during the vertical interval ensures glitch-free

switching with genlocked sources.

The VS-808DS features:

A video bandwidth of 200MHz that ensures transparent performance even

in the most critical applications

Switching synchronization that lets you synchronize either to the external

reference or to the incoming video

Both audio-follow-video and breakaway options

The storing of eight setups

(presets) to be recalled and executed when

needed

A TAKE button for executing multiple switches all at once

The ability to control via the front panel buttons, via the infra-red remote

control transmitter, via an external remote IR receiver (optional

) and

remotely by RS-485 or RS-232 serial commands transmitted by a touch

screen system, PC, or other serial controller

Scaled graphics output resolutions: VGA (640x480), SVGA (800x600),

XGA (1024x768), or WXGA (1366x768)

Acceptance of PAL-B/D/G/H/I, NTSC 3.58, and NTSC 4.43 video formats

The VS-808DS is housed in a 19" 2U rack-mountable enclosure and is fed

from a 100-240 VAC universal switching power supply.

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position

your VS-808DS away from moisture, excessive sunlight and dust

4 Your VS-808DS 8x8 Video Audio Matrix Switcher / Scaler

This section defines the front and rear panels of the VS-808DS 8x8 Video

Audio Matrix Switcher / Scaler:

1 The signal that is converted via the scaled output is the input signal that is routed to output 8

2 Note, that the saved setup does not include the scaler setup

3 Kramer P/N: 95-0103050)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-808DS 8x8 Video Audio Matrix Switcher / Scaler

Figure 1: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Front Panel

Your VS-808DS 8x8 Video Audio Matrix Switcher / Scaler

Table 1: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Front Panel Features

# Feature Function

1 IR Receiver The red LED is illuminated when receiving signals from the infra-red remote

control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 OUTPUT

RES. Button

Press to select the scaler output resolution: VGA, SVGA, XGA, or WXGA

SCALER

CONTROL

LEDs Light the specific resolution selected via the OUTPUT RES. button: VGA

(640x480), SVGA (800x600), XGA (1024x768), or WXGA (1366x768)

5 INPUT SELECTOR

Buttons

Select the input to switch to the output (from 1 to 8)

6 OUTPUT SELECTOR

Buttons

Select the output to which the input is switched (from 1 to 8)

7 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs

8 OFF Button An OFF-OUT combination disconnects that output from the inputs; an OFF-ALL

combination disconnects all the outputs

9 TAKE Button Pressing TAKE toggles the mode between the Confirm mode

and the At

Once mode (user confirmation per action is unnecessary). When in TAKE

mode, pressing TAKE implements the action

10 AFV Button When pressed (illuminates), actions relate to video and audio channels.

Audio channels follow the video channels

11 AUDIO Button When pressed

(illuminates), actions relate to audio, and display shows audio

status

12 VIDEO Button When pressed (illuminates), actions relate to video, and display shows video

status

13 STATUS 7-segment

Display

Displays the selected input switched to the output (marked above each

input). Also displays the firmware version number and the MACHINE #

14 RCL (Recall) Button Pressing the RCL button and the corresponding OUTPUT key recalls a setup

from the non-volatile memory

15 STO (Store) Button Pressing STO followed by an output button stores the current setting

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 When in Confirm mode, the TAKE button illuminates

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-808DS 8x8 Video Audio Matrix Switcher / Scaler

Table 2: VS-808DS 8x8 Video Audio Matrix Switcher / Scaler Rear Panel Features

# Feature Function

16 AUDIO INPUT L RCA

Connectors

Connect to the LEFT audio sources (from 1 to 8)

17 AUDIO INPUT R RCA

Connectors

Connect to the RIGHT audio sources (from 1 to 8)

18 EXT. SYNC BNC Connector Connect to an external SYNC

19 SYNC SELECT EXT. / IN 1

Pushbutton

Press to select the external SYNC, release to select the SYNC

from input 1

20 VIDEO INPUT BNC

Connectors

Connect to the composite video sources (from 1 to 8)

21 AUDIO OUTPUT L RCA

Connectors

Connect to the LEFT audio acceptors (from 1 to 8)

22 AUDIO OUTPUT R RCA

Connectors

Connect to the RIGHT audio acceptors (from 1 to 8)

23 VIDEO OUTPUT BNC

Connectors

Connect to the composite video acceptors (from 1 to 8)

24 RS-485 Terminal Block Port Pin G is for Ground connection

; Pins B (-) and A (+) are for

RS-485

25 RS-232 DB 9F Port Connects to the PC or the Remote Controller

26 SCALER OUTPUT HD15

Connector

Connects to the video acceptor that displays the scaled output

27 Dipswitches Dipswitches for setup of the unit (1, 2, and 3 are for setting the

Machine # (SELF ADDRESS), 4 is for RS-485 Termination, 5 is

for Reply, and 8 is for RS-232/RS-485 (see section 6.3)

28 Power Connector with Fuse AC connector enabling power supply to the unit

29 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the machine via

an IR remote controller (instead of using the front panel IR receiver)

1 Usually not connected. If shielded twisted pair is used for RS-485, G may be connected to the shield

2 The signal that is converted via the scaled output is the input signal that is routed to output 8

3 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the VS-808DS (only if the internal

IR connection cable has been installed)

Installing on a Rack

5 Installing on a Rack

This section describes what to do before installing on a rack and how to rack

mount.

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer Sierra Pro XL 1616V3S Manual de usuario

Kramer

Kramer VS-402XL Manual de usuario

Kramer

Kramer VS-44H2A Manual de usuario

Kramer

Kramer VS-88HDxl Manual de usuario

Kramer

Kramer VS-6464DN-EM Manual de usuario

Kramer

Kramer VS-88DVI Manual de usuario

Kramer

Kramer VS-66HDCPxl Manual de usuario

Kramer

Kramer VS-44HDCP Manual de usuario

Kramer

Kramer 1608HDS Manual de usuario

Kramer

Kramer VS-1604 Manual de usuario

Kramer

Kramer 3232HD Manual de usuario

Kramer

Kramer VP-8x8TP Manual de usuario

Kramer

Kramer Sierra Video 4832V5Sxl Manual de usuario

Kramer

Kramer XL 1616V2 Manual de usuario

Kramer

Kramer XL 1208V Manual de usuario

Kramer

Kramer LASSEN XL 3216S Manual de usuario

Kramer

Kramer VP-1608 Manual de usuario

Kramer

Kramer Sierra Pro XL 1208V5 Manual de usuario

Kramer

Kramer VP-1608 Manual de usuario

Kramer

Kramer VS-62H Manual de usuario

Kramer

Kramer 1616DEE Manual de usuario

Kramer

Kramer VP-23RC Manual de usuario

Kramer

Kramer VS-44UHDA Manual de usuario

Kramer

Kramer Sierra Video 1608V3 Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
