USER MANUAL





Model:

729

Presentation Switcher / Scaler

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

About HDMI 5

3.2

Recommendations for Best Performance 6

Your Presentation Switcher / Scaler 6

Installing in a Rack 10

Connecting your Presentation Switcher / Scaler 11

6.1

Connecting a PC 13

6.2

Connecting the VP-729 via the ETHERNET Port 13

Presentation Switcher / Scaler Buttons 14

7.1

Switching an Input 14

7.2

The PIP Button Feature 14

7.2.1

Activating the PIP Feature 15

7.2.2

Selecting the PIP Source 15

7.2.3

Toggling between the PIP and the Screen Source (Swap) 16

7.2.4

Quick Selection of the PIP Source via the Front Panel Buttons 16

7.3

Locking and Unlocking the Front Panel 18

7.4

The Infrared Remote Control Transmitter 18

Configuring the VP-729 via the OSD MENU Screens 20

8.1

The Input Screen 21

8.2

The Picture Screen 22

8.3

The Output Screen 23

8.4

The PIP Screen 24

8.5

The Audio Screen 25

8.6

The Geometry Screen 26

8.7

The Setup Screen 27

8.7.1

The Slideshow Feature 28

8.7.2

The Advanced Setup Screen 28

8.8

Verifying Configuration Details via the Info Screen 32

Using Text Overlay 33

Audio Flash Memory Upgrade 35

10.1

Downloading from the Internet 35

10.2

Connecting the PC to the RS-232 Port 35

10.3

Upgrading the Audio Firmware 36

Technical Specifications 41

VP-729 Communication Protocol 46

12.1

Error Codes Description 56

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figures

Figure 1: VP-729 Presentation Switcher / Scaler Front Panel 7

Figure 2: VP-729 Presentation Switcher / Scaler Rear Panel 7

Figure 3: Connecting the VP-729 Rear Panel 12

Figure 4: Connecting the PC 13

Figure 5: PIP Source Over Background 15

Figure 6: OSD SWAP Status 16

Figure 7: Infrared Remote Control Transmitter 19

Figure 8: MENU Items 20

Figure 9: Input Screen 21

Figure 10: Picture Screen 22

Figure 11: Output Screen 23

Figure 12: PIP Screen 24

Figure 13: Audio Screen 25

Figure 14: Geometry Screen 26

Figure 15: Setup Screen 27

Figure 16: Advanced Setup Screen 28

Figure 17: Misc Setup Screen 29

Figure 18: Information Screen 32

Figure 19: TextOverlay Application Screen 33

Figure 20: RS-232 PINOUT Connection 35

Figure 21: Splash Screen 36

Figure 22: Atmel – Flip Window 37

Figure 23: Device Selection Window 37

Figure 24: Selecting the Device Window 38

Figure 25: Loading the Hex 38

Figure 26: RS-232 Window 39

Figure 27: Atmel – Flip Window (Connected) 39

Figure 28: Atmel – Flip Window (Operation Completed) 40

Tables

Table 1: Front Panel Presentation Switcher / Scaler Features 8

Table 2: Rear Panel Presentation Switcher / Scaler Features 9

Table 3: PIP Source Appearance Availability 17

Table 4: Infrared Remote Control Transmitter Functions 19

Table 5: Input Screen Functions 21

Table 6: Picture Screen Functions 22

Table 7: Output Screen Functions 23

Table 8: PIP Screen Functions 24

Table 9: Audio Screen Functions 25

Table 10: Geometry Screen Functions 26

Table 11: Available Settings for Each Application 26

Table 12: Setup Screen Functions 27

Table 13: Mode Set Functions 29

Table 14: OSD Functions 29

Table 15: Misc Functions 30

Contents

iii

Table 16: Input Functions 31

Table 17: Output Functions 31

Table 18: Features and Functions of the TextOverlay Application 34

Table 19: RS-232 PINOUT Connection 36

Table 20: Technical Specifications of the VP-729 Presentation Switchers / Scaler 41

Table 21: Technical Specifications of the RGBHV / RGBS (PC) / RGsB (PC) Input Signal 42

Table 22: Technical Specifications of the HDMI Input Signal (for RGB Colorspace)42

Table 23: Technical Specifications of the Y/C, Video Signal 43

Table 24: Technical Specifications of the HDMI input Signal (for RGB or YUV Colorspace) 43

Table 25: Technical Specifications of the Component Input Signal 43

Table 26: Technical Specifications of the RGBHV/Comp/YPbPr Output Signal 44

Table 27: Technical Specifications of the HDMI/DVI/RGB Output Signal 45

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups

that are clearly defined by function.

Congratulations on purchasing your Kramer VP-729 Presentation Switcher /

Scaler, which is ideal for the following typical applications:

Projection systems in conference rooms, boardrooms, auditoriums, hotels and

churches

Production studios, rental and staging

Any application where high quality conversion and switching of multiple and

different video signals to graphical data signals is required for projection

purposes

The package includes the following items:

VP-729 Presentation Switcher / Scaler

Infrared remote control transmitter

Two sets of C-SF/2RVM cables, power cord

and null-modem adapter

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

The quick start charts summarize the basic setup and operation steps of the

VP-729.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 We recommend that you use only the power cord that is supplied with this machine

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer VP-729 is a 9-input Proscale™ Presentation Switcher / Scaler

with unbalanced stereo and digital S/PDIF audio.

The VP-729 scales any composite, s-Video (Y/C), component video (YUV),

HDMI or computer graphics video signal, as well as jpeg files (via USB) up

or down to a selectable graphics or HDTV output resolution and provides

glitch-free switching between sources through FTB™ (fade-thru-black)

switching technology. The output signal is available simultaneously on a

15-pin HD computer graphics video (UXGA) connector and on an HDMI

connector.

The VP-729 features include:

Silicon Optix HQV® Video Processing - HQV (Hollywood Quality Video)

processing represents the state-of-the-art in video processing technology, with

the highest quality de-interlacing, noise reduction, and scaling performance for

both standard-definition and high-definition signals

Fade-Thru-Black (FTB™) Switching - the video fades to black and then the

new input fades from black for glitch-free and smooth switching. The output

signal provides constant sync so the display never glitches

K-IIT XL™ Picture-in-Picture Image Insertion Technology - ultra stable

picture-in-picture, picture-and-picture, and split screen capability. Any video

source can be inserted into or positioned next to a computer graphics video

source or vice versa with window positioning and sizing controls

Four user definable (universal) video inputs (each can be set as composite

video, s-Video (Y/C) or component video), two computer graphics video inputs,

two HDMI inputs and 1 USB input (for reading JPEG picture files

)

HDTV compatible component input

HDTV output resolutions - 480p, 576p, 720p 1080i, and 1080p

Scaled video outputs - HDMI and computer graphics video

HDMI supports up to 2.25Gbps bandwidth per graphic channel

Multiple computer graphics output resolutions - including a user-defined output

resolution with selectable refresh rates

Multiple aspect ratio selections

Companion AFV (audio-follow-video) for every analog video input - supports

embedded audio on the two HDMI inputs and output

Built-in noise reduction and picture enhancement features

1 JPEG files are recognized up to 2048x1536

2 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

Audio inputs - four (stereo audio or S/PDIF on two RCA connectors) for each

of the four universal video inputs; two stereo audio (on 3.5mm connectors) for

the two computer graphics video inputs; and embedded audio on the HDMI

inputs

Audio outputs - S/PDIF and stereo audio (RCA connectors). Transcodes stereo

or S/PDIF audio to both stereo and S/PDIF audio and embeds audio onto the

HDMI output

Built-in Time Base Corrector - stabilizes video sources with unstable sync

Built-in video Proc-Amp - color, hue, sharpness, contrast, and brightness are set

individually for each input

A BLANK button, a FREEZE button, a RESET TO XGA/720P button (to

hardware-reset the output resolution); and a PANEL LOCK button

Built-in audio Proc-Amp - with bass, treble, balance and loudness control, as

well as audio delay

Firmware upgrade support

via the USB port

A slideshow feature, letting you run a slideshow via the USB port

An OSD (On-Screen Display) – for making adjustments – that can be located

anywhere on the screen

In addition, the VP-729:

Includes non-volatile memory that retains the last settings, after switching the

power off and then on again

Digitally reprocesses the signal to correct mastering errors, and regenerates the

video at a higher line and pixel rate format, providing native-resolution video for

LCD, DLP and plasma displays

Is specifically designed to improve video quality by reducing chroma noise

Scales and zooms (to up to 400% of the original size)

Can provide non-linear scaling for 4:3, 16:9 transformation

Control your VP-729 directly via the front panel push buttons, or:

By RS-232 serial commands transmitted by a touch screen system, PC, or other

serial controller

Remotely, from the infrared remote control transmitter (with on-screen menus)

Via the Ethernet

The VP-729

is housed in a 19” 1U rack mountable enclosure, with rack “ears”

included, and is fed from a 100-240 VAC universal switching power supply.

1 The front panel blank, freeze and lock buttons can be programmed via the OSD menu (see Table 15)

2 To check if firmware upgrades are available, go to our Web site at http://www.kramerelectronics.com

3 Centered on the screen, or in one of the four corners

Overview

3.1 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the maximum high-definition image and sound quality in use

today. Note that Kramer Electronics Limited is an HDMI Adopter

and an HDCP

Licensee

In particular, HDMI

Provides a simple

interface between any audio/video source, such as a set-top

box, DVD player, or A/V receiver and video monitor, such as a digital flat LCD

/ plasma television (DTV), over a single lengthy

cable

Supports standard, enhanced, high-definition video, and multi-channel digital

audio

on a single cable

Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

Benefits consumers by providing superior, uncompressed digital video quality

via a single cable

, and user-friendly connector

Is backward-compatible with DVI (Digital Visual Interface)

Supports two-way communication between the video source (such as a DVD

player) and the digital television, enabling new functionality such as automatic

configuration and one-button play

Has the capacity to support existing high-definition video formats (720p, 1080i,

and 1080p/60), standard definition formats such as NTSC or PAL, as well as

480p and 576p

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 See http://www.hdmi.org/about/adopters_founders.asp

3 See http://www.digital-cp.com/list/

4 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

licensing LLC

5 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

6 HDMI technology has been designed to use standard copper cable construction at up to 15m

7 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

8 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Presentation Switcher / Scaler

3.2 Recommendations for Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise-levels

(often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position your

Kramer VP-729 away from moisture, excessive sunlight and dust

4 Your Presentation Switcher / Scaler

Figure 1, and Table 1 define the front panel of the VP-729; Figure 2 and

Table 2 define the rear panel.

Otros manuales para VP-729

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer VS-88H Manual de usuario

Kramer

Kramer Sierra Video 3232V5 Manual de usuario

Kramer

Kramer Sierra Video 3248V5Sxl Manual de usuario

Kramer

Kramer MTX3-34-M Manual de usuario

Kramer

Kramer VP-88K Manual de usuario

Kramer

Kramer VS-44HN Manual de usuario

Kramer

Kramer VS-606xl Manual de usuario

Kramer

Kramer VS-1604 Manual de usuario

Kramer

Kramer 88V3S Manual de usuario

Kramer

Kramer XL 1608V2 Manual de usuario

Kramer

Kramer Sierra Video 3216V3 Manual de usuario

Kramer

Kramer Sierra Pro XL 1204V5 Manual de usuario

Kramer

Kramer 88DEE Manual de usuario

Kramer

Kramer VS-44HDCP Manual de usuario

Kramer

Kramer Sierra Pro XL 1616V5S Manual de usuario

Kramer

Kramer VS-44UHD Manual de usuario

Kramer

Kramer XL 3216VS Manual de usuario

Kramer

Kramer XL 1204V4 Manual de usuario

Kramer

Kramer VP-725DS Manual de usuario

Kramer

Kramer Sierra Video 1608V3 Manual de usuario

Kramer

Kramer XL 3216V2 Manual de usuario

Kramer

Kramer VS-6464DN Manual de usuario

Kramer

Kramer VS-1616AD Manual de usuario

Kramer

Kramer VS-44HD Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
