Kramer VGA Manual de usuario

USER MANUAL

MODEL:

VGA Extender

P/N: 2900-300286 Rev 2

VGA Extender – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

4Connecting the VGA Extender System 5

4.1 Connecting the Transmitter 6

4.2 Connecting the Receiver 6

4.3 Connecting the CAT 5/6/7 Cable 7

4.4 Connecting the Power Supply 7

4.5 Connecting the Line Splitter 7

5Operating the VGA Extender 9

5.1 LED Indicators 9

5.2 Switching On 9

5.3 Adjusting the Picture 9

6Technical Specifications 10

Figures

Figure 1: VGA Extender System 5

Figure 2: Expanded VGA Extender System Overview 5

Figure 3: Connecting the Transmitter 6

Figure 4 VDS Dual Screen Connections 6

Figure 5 Line Splitter 7

Figure 6 Detailed Connections 8

VGA Extender - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VGA Extender, which is ideal for the

following typical applications:

Digital signage

Media extension

VGA Extender - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VGA Extender away from moisture, excessive sunlight

and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VGA Extender - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VGA Extender - Overview

3 Overview

The VGA Extender extends video (VGA) signals up to 110m (360ft) depending on

the resolution.

The VGA Extender is made up of three components:

VDS transmitter

VDS dual screen receiver

Optional CAT 5 VDS line splitter

This table defines the models:

Kramer Model

Kramer Part

Number

Full Description

EXT-VGA

(0VS23077)

50-0000999011

Minicom CAT5 VGA Extender

The VGA Extender features:

A maximum range of up to 110m (360ft)

Support for CAT 5/6/7 FTP/UTP cable

Plug and Play installation with no extra protocols needed

Cascadability –adding VDS line splitters increases the number of receivers

up to 64

The VDS transmitter supports the following resolutions:

720 x 400p @70Hz - IBM VGA

640 x 480p @60Hz - IBM VGA

640 x 480p @67Hz - Apple Mac II

640 x 480p @72Hz - VESA

640 x 480p @75Hz - VESA

800 x 600p @56Hz - VESA

800 x 600p @60Hz - VESA

800 x 600p @72Hz - VESA

800 x 600p @75Hz - VESA

832 x 624p @75Hz - Apple Mac II

1024 x 768p @60Hz - VESA

1024 x 768p @70Hz - VESA

1024 x 768p @75Hz - VESA

1280 x1024p @75Hz - VESA

1152 x 870p @75Hz - Apple Mac II

1600 x1200p @60Hz - VESA STD

1280 x1024p @60Hz - VESA STD

1280 x 960p @60Hz - VESA STD

1152 x 864p @75Hz - VESA STD

VGA Extender - Connecting the VGA Extender System

4 Connecting the VGA Extender System

This section describes how to connect the VGA Extender system.

Before installation:

Switch off the computer

Place cables away from fluorescent lights, air conditioners, and machines

that are likely to generate electrical noise

Figure 1 illustrates an overview of the VGA Extender system.

Connect the receiver to one or two screens, up to 110m/360ft away from the

transmitter (depending on resolution).

Figure 1: VGA Extender System

Figure 2 illustrates the VGA Extender system with a connected Line Splitter

adding up to 14 more screens to the system. (With cascading you can have a

maximum of 64 screens).

Figure 2: Expanded VGA Extender System Overview

VGA Extender - Connecting the VGA Extender System

4.1 Connecting the Transmitter

Figure 3 illustrates how to connect the transmitter:

Figure 3: Connecting the Transmitter

Note. Although we recommend connecting the transmitter to a computer that is

switched off, you can connect it to a computer that is switched on.

To do so, you must connect it in the following order:

USB connector

Video connector

4.2 Connecting the Receiver

Figure 4 illustrates how to connect the VDS Dual Screen receiver:

Figure 4 VDS Dual Screen Connections

Keybd

Mouse 100T

Video

Serial A

Parallel

Serial B

Transmitter

To USB Port

To Video

port

To VDS Dual Screen

/ Line Splitter

System cable to

Transmitter / Line

Splitter To

monitors

VDS Dual Screen

VGA Extender - Connecting the VGA Extender System

4.3 Connecting the CAT 5/6/7 Cable

A CAT 5/6/7 cable connects to the RJ-45 ports of the transmitter and the VDS

Dual Screen.

4.4 Connecting the Power Supply

Connect the supplied 5V DC power adapter to the receiver. The transmitter is

powered only via its USB connection.

Note: If connected to a USB hub, the hub must be powered.

4.5 Connecting the Line Splitter

Connect up to 64 screens by adding up to 2 levels of CAT 5 video display line

splitters to the VGA Extender system.

Figure 5 illustrates the ports of the line splitter and Figure 6 illustrates the detailed

connections of the system including the transmitter, the receivers and a line

splitter.

For the line splitter connect the supplied 12V DC power adapter.

Figure 5 Line Splitter

SYSTEM IN

12VDC

SYSTEM OUT

System cables

Power

connector

CAT5 cable from Transmitter or

previous Line Splitter

VGA Extender - Connecting the VGA Extender System

Figure 6 Detailed Connections

www.minicom.com

SYSTEM IN

12VDC

SYSTEM OUT

CAT5 cables to

Receivers or Line

Splitter

Line

Splitter

Transmitter

Computer

CAT5 cables to

Receivers or

Line Splitter

To USB Port

To Video port

VDS Dual

Screen

Keybd

Mouse 100T

VideoSerial A

Parallel

Serial B

To wall socket
