JetBox 8100 User Manual
Hardware
Copyright@2007
Korenix Technology Co., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
V1.0
Copyright Notice
Copyright© 2007 Korenix Technology Co., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Information provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the
preparation of this document to assure its accuracy, Korenix assumes no
liabilities resulting from errors or omissions in this document, or from the use of
the information contained herein.
Korenix reserves the right to make changes in the product design without
notice to its users.
Acknowledgments
Korenix is a registered trademark of Korenix Technology Co., Ltd.
All other trademarks or registered marks in the manual belong to their
respective manufacturers.
ii
Table of Contents
JetBox 8100 User Manual...............................................................................i
Hardware .........................................................................................................i
Copyright Notice.................................................................................ii
Acknowledgments..............................................................................ii
Table of Contents..........................................................................................iii
Chapter 1: Overview......................................................................................1
1.1 Introduction................................................................................1
1.1.1 Highly Robust Coating Construction ..................................2
1.1.2 Highly Compact Size................................................................2
1.1.3 Highly Scalable Performance with low power
consumption ..............................................................................2
1.1.4 Optimized Integration ..............................................................2
1.1.5 Wide Range of Power Source................................................2
1.2 Hardware Specifications...........................................................3
1.3 Dimension ..................................................................................4
1.4 Packing List ...............................................................................4
Chapter 2: Hardware Functionality...............................................................5
2.1 Introduction of JetBox 8100 external I/O Connectors............5
2.2 VGA Connector..........................................................................5
2.3 PS2 Keyboard /Mouse Connector............................................6
2.4 COM 1 Connector ......................................................................6
2.5 COM2 Connector .......................................................................7
2.6 Ethernet Connector (LAN) ........................................................7
2.7 USB Connector..........................................................................8
2.8 Audio MIC/ Earphone Connector..............................................8
2.9 Power Input Connector .............................................................8
2.10 Power ON/OFF Button.............................................................9
2.12 LED Indicators .........................................................................9
Chapter 3: Hardware Installation and Upgrade.........................................10
3.1 Jumpers and Connectors .......................................................10
3.2 Setting Jumpers.......................................................................10
3.3 COM2 RS232/422/485 Jumper Setting (JP2)..........................11
3.4 Install the DDR SDRAM Memory Module...............................12
3.5 Inserting a Compact Flash Card.............................................13
3.6 Installing the 2.5” Hard Driver Disk (HDD).............................14
iii
Chapter 4: Award BIOS Setup.....................................................................16
4.1 Introduction..............................................................................16
4.2 Entering Setup.........................................................................17
4.3 Standard CMOS Setup.............................................................17
4.4 Advanced BIOS Features........................................................18
4.4.1 Virus Warning...........................................................................18
4.4.2 CPU Inetenal Cache................................................................18
4.4.3 Quick Power On Self Test.....................................................18
4.4.4 First/Second/Third/Boot Other Device..............................19
4.4.5 Boot Up Numlock Status.......................................................19
4.4.6 Gate A20 Option ......................................................................19
4.4.7 Typematic Rate (Chars/Sec).................................................19
4.4.8 Typematic Delay(Msec)..........................................................19
4.4.9 Security Option........................................................................19
4.5 Advanced Chipset Features....................................................20
4.5.1 CPU Frequency........................................................................20
4.5.2 CAS Latency.............................................................................20
4.5.3 Video Memory Size.................................................................21
4.5.4 Onboard Audio.........................................................................21
4.6 Integrated Peripherals.............................................................21
4.6.1 On-Chip IDE Channel 1..........................................................21
4.6.2. Master/Slave Drive PIO/UDMA Mode ................................22
4.6.3 IDE HDD Block Mode..............................................................22
4.6.4 KBC input clock.......................................................................22
4.6.7 Onboard Serial Port................................................................22
4.6.8 Serial Port-2 mode Select.....................................................22
4.6.9 Lan 1 Controller.......................................................................22
4.6.10 Onboard Lan Boot ROM......................................................23
4.7 Power Management Setup......................................................23
4.8 PnP/PCI Configurations..........................................................23
4.8.1 PNP OS Installed.....................................................................24
4.8.2 Reset Configuration Data......................................................24
4.8.3 Resources controlled by.......................................................24
4.8.4 PCI/VGA Palette Snoop .........................................................24
4.9 PC Health Status......................................................................24
4.10 Load Fail-Safe Default...........................................................25
4.11 Load Optimized Default.........................................................25
4.12 Password Setup.....................................................................25
iv
JetBox 8100 User Manual_HW_1.00
4.13 Save & Exit Setup..................................................................26
4.14 Exit Without Saving...............................................................26
Chapter 5: Appendix....................................................................................27
5.1 Revision History ......................................................................27
5.2 Table/Figure Index...................................................................27
v
Chapter 1: Overview
1.1 Introduction
The advantage of adopting Korenix JetBox series is ready-to-use. Korenix
is devoted to improve the usability of embedded communication computer
in industrial domain. Besides operating system (Linux/WinCE/WinXPe),
Korenix provides device drivers, protocol stacks, system utilities,
supporting services and daemons in one Compact Flash card to make
system integration simple. Further, Korenix provides application
development toolkits for users to build up their own applications easily.
JetBox 8100 is a high performance, compact and rugged embedded
computer. All-in-one device with small volume, fanless design and a
capability to withstand a wide range of temperatures is suitable for
industrial severe environment. It is equipped with AMD Geode LX800
(500MHz) processor and 256MB SDRAM (512MB Max.) and supports
Linux and WinCE5.0 to meet requirements of industrial PC applications.
For better expansibility, it carries 2 USB ports, 1 RS-232 ports and 1
RS-232/422/485 ports for versatile peripheral and interfaces and one
Compact Flash slot for system integration. It also supports 640*480 VGA
(1280*1024 Max.) and audio to give users much flexibility in industrial
applications. In addition, it is equipped with 1 RJ-45 ports and supports
daemons and web server to accommodate to the network communication
environment today.
With complete software solution and excellent hardware design, JetBox
series is the best choice of industrial communication computer.
1
JetBox 8100 User Manual_HW_1.00
1.1.1 Highly Robust Coating Construction
Fanless operation in steel housing. A special cushioned design that
absorbs vibtation to ensure maximum reliability under harsh
conditions
1.1.2 Highly Compact Size
With its maximum mounting wide of 44mm,the Jetbox 8100 can be
used in limited space critical conditions
1.1.3 Highly Scalable Performance with low power consumption
Scalable Low Voltage AMD Geode LX800 processor system to bring
high computing performance with low power consumption
1.1.4 Optimized Integration
yFew Parts, easy integration, easy maintenance to reduce
investment
ySystem are supplied ready to run
yLong life cycle support for product continuity
yWide range of power source
1.1.5 Wide Range of Power Source
Wide range of DC 12V~24V power source offers flexibility of power
input for various automation environments
2
JetBox 8100 User Manual_HW_1.00
1.2 Hardware Specifications
Model JetBox 8100
Processor AMD Geode LX800 500MHz
Chipset AMD Geode CS5536
System Memory SDRAM 256 MB ,Max.512MB (Optional)
VGA Up to 64MB sharing system memory
Ethernet Controller Realtek RTL 8100C, 10/100Based-TX RJ45
connector*1
Compact Flash slot Type II Compact Flash slot *1
Hard Driver Disk 2.5”HDD IDE slot *1
Serial Port COM1: RS232
COM2: RS232/RS422/RS485 (JP2/BIOS
select)
USB Two USB2.0 Compliant universal serial bus
port
Audio MIC input connector , Earphone connector
Keyboard/Mouse One PS/2 Port to support PS/2 Mouse and
PS/2 Keyboard
RTC Battery backup external RTC
Reset Button One
Power Button One , Power ON/OFF Button
LED Indicator PWR*1, HDD*1,ACT*1,LINK*1
Powe Input +12VDC~+24VDC
Power
Consumption 15W Max.
Mounting DIN Rail
Construction Sheet metal case
Dimensions 120.0mm(D)* 44.2mm(W)*123.0mm(H)
Operating
Temperature 5℉~158℉(-15℃~ 70℃), 5 to 95% RH(w/o
HD)
Storage
Temperature -4℉~176℉(-20℃~ 80℃), 5 to 95% RH(w/o
HD)
Net Weight 0.7 kg
EMC CE/FCC class A
Table 1-1 Hardware specifications
3
JetBox 8100 User Manual_HW_1.00
1.3 Dimension
120(REF) 44.2(REF)
123(REF)
36.35
9
-
+
Figure 1-2 Dimension
1.4 Packing List
yJetBox 8100
yPS/2 Keyboard/Mouse adapter cable
y2 pin power terminal block
y44-pin flat cable w/4 screws for fix 2.5”HD
yDin-Rail mounting kit w/3 screws
yQuick Installation Guide
yDocumentation and Software CD-ROM
4
