Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 1



3.5"

-SBC-KBL/SKL - QUICK INSTALLATION GUIDE

Thank you for purchasing the Kontron 3.5"-SBC-KBL/SKL embedded board. This document provides information to allow

you to quickly install this product.

Packing Checklist

1. Take the 3.5"-SBC-KBL/SKL out of the packing box and check if the unit is properly secure in the plastic bag.

2. Check the contents of the carton box: (*: optional)

3.5"-SBC-KBL/SKL embedded board

Quick Installation Guide

1x DC Jack Cable

1x SATA Cable*

1x SATA Power Cable*

COM Port Cable*

DIO Cable*

2-Port USB Cable*

Audio Cable*

Mini SIM Card Holder Kit*

Heatsink* (for 15 W TDP CPU)

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 2

Top Side Jumper and Internal Connector Locations

Jumper List

Item Designation Description

1 JP1 MPCIE1 Activity LED Pin Header

2 JP2 Panel & Backlight Power Selection for LVDS1

3 JP3 NGFF M.2 Activity LED Pin Header

4 JP4 Backlight Power Enable Selection for LVDS1

5 JP6 AT / ATX Power Mode and NGFF mSATA/mPCIe Selection

6 JP7 SIM Card and USB Power Selection

7 JP8 Flash Descriptor Security Override Selection

8 JP9 RTC Reset Selection

9 JP10 Clear ME Register

Internal Connector List

Item Designation Description

10 BAT1 RTC Power Input Wafer

11 FAN1 +12VDC CPU FAN Wafer

12 DIMM1 Primary DDR4 Memory SO-DIMM Socket

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 3

Item Designation Description

13 DIMM2 Secondary DDR4 Memory SO-DIMM Socket

14 MPCIE1 Full Size Mini-PCI Express v1.2 Socket

15 CON1 NGFF M.2 Key-B Socket

16 SATA1 Serial ATA Port-0 SATA Socket

17 SATA2 Serial ATA Port-0 SATA Socket

18 CN1 HDD Power Output Wafer

19 CN2 DC12V Power Input Wafer

20 CN3 P80 Header

21 CN4 SIM Interface Wafer for MPCIE1/NGFF M.2

22 CN5 Digital Input / Output Wafer

23 CN6 Serial Port 1 Wafer

24 CN7 Serial Port 2 Wafer

25 CN8 USB 2.0 Port DN5,6 Pin Header

26 CN9 Audio Input / Output Pin Header

27 CN10 Left Channel 3W Audio AMP Output Wafer

28 CN15 Right Channel 3W Audio AMP Output Wafer

29 FP1 Front Panel 1 Pin Header

30 FP2 Front Panel 2 Pin Header

Jumper Settings

MPCIE1 Activity LED Pin Header (JP1)

Jumper Position Description

1 LED+

2 LED-

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 4

Panel & Backlight Power Selection for LVDS1 (JP2)

Jumper 1 Position Description

Pin 1-3 Pin 3-5

X - Backlight Power = +12V

- X Backlight Power = +5V

Jumper 2 Position Description

Pin 2-4 Pin 4-6

X - Panel Power = +3,3V

- X Panel Power = +5V

“X” = Jumper set (short) and “-” = jumper not set (open)

NGFF M.2 Activity LED Pin Header (JP3)

Jumper Position Description

1 LED+

2 LED-

Backlight Power Enable Selection for LVDS1 (JP4)

Jumper 1 Position Description

Pin 1-3 Pin 3-5

X - Backlight Enable Voltage = +3.3V

- X Backlight Enable Voltage = +5V

Jumper 2 Position Description

Pin 2-4 Pin 4-6

X - Active High

- X Active Low

“X” = Jumper set (short) and “-” = jumper not set (open)

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 5

AT / ATX Power Mode & NGFF mSATA / mPCIe Selection (JP6)

Jumper 1 Position Description

Pin 1-3 Pin 3-5

X - ATX Mode

- X AT Mode

Jumper 2 Position Description

Pin 2-4 Pin 4-6

X - NGFF Select mSATA

- X NGFF Select mPCIe

“X” = Jumper set (short) and “-” = jumper not set (open)

SIM Card and USB Power Selection (JP7)

Jumper 1 Position Description

Pin 1-3 Pin 3-5

X - SIM Card to NGFF

- X SIM Card to mPCIe

Jumper 2 Position Description

Pin 2-4 Pin 4-6

X - S5 USB Power Support

- X S3 USB Power Support

“X” = Jumper set (short) and “-” = jumper not set (open)

Flash Descriptor Security Override Selection (JP8)

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 6

Jumper Position Description

Pin 1-2

X Enable

- Disabled

“X” = Jumper set (short) and “-” = jumper not set (open)

RTC Reset Selection (JP9)

Jumper Position Description

Pin 1-2

X Enable Clear CMOS RTC content

(board does not boot with the jumper in this position)

- Disabled (default position)

“X” = Jumper set (short) and “-” = jumper not set (open)

Clear ME Register (JP10)

Jumper Position Description

Pin 1-2

X Enable Clear ME

- Disabled

“X” = Jumper set (short) and “-” = jumper not set (open)

Kontron 3.5"-SBC-KBL/SKL - Quick Installation Guide - Version 2 - P/N: 0D20ECXSLU020100 // 7

Bottom Side Internal Connector Locations

Item Designation Description

1 CN16 LCD Panel Power Connector

2 LVDS1 LVDS Panel Connector

Real I/O Panel Connector Locations

Item Designation Description

1 HDMI1 HDMI Port-1 Connector

2 DP1 DisplayPort Port-1 Connector

3 CN12 GbE LAN1 RJ-45 Connector

4 CN11 GbE LAN2 RJ-45 Connector

5 CN13 USB3.0 Port-1,2 Type-A Connector

6 CN14 USB3.0 Port-3,4 Type-A Connector
