Konix DRAKKAR STYRI Manual de usuario
DRAKKAR STYRI RACING WHEEL
USER MANUAL
A
1. INTRODUCTION:
Thank you for purchasing the Drakkar Styri steering wheel designed for PC, it
is compatible with all of the PC games, with built-in motors which can generate
different vibration strength according to your status in the game (if the game sof-
tware supports vibration function). The shape is designed according to the racing
car wheels and in accordance with human ergonomics; you will not feel tired ea-
sily even if you operate it for hours. It makes the game even more realistic, more
maneuverability and more interesting.
2. FEATURES:
1. Compatible with Windows Vista/7/8/10
2. X-INPUT & D-INPUT dual modes, Default X-INPUT mode
3. Press and hold MODE for 3 seconds to switch between X-INPUT
and D-INPUT
4. 4 directional buttons with 8 ways (up, down, left, right and 45
degrees X 4)
5. 4 digital input buttons: 10/Start, 9/BACK, 11/LS, 12/RS
6. 8 programming buttons: Left wing, right wing, gear shift (LT/RT),
pedal of gasoline, pedal of brake, L3, R3
7. Three Stage Sensitivity optional for multi-demand with LEDs
indicating current setting
8. Six suction cups provide a very strong and long-term grip on
smooth surface
9. Both directions 270 degrees realistic rotation provides immersion
and enjoyment
10. Left/right wings and pedals have functions of gas; bring better
driving experience to you
11. Dual motors generate vibration feedback
12. Less Power-consumption, more Geo-friendly. Power source: USB 5V,
Operating current: 16mA (when motors are shut) 80mA (left motor)
75mA (right motor).
A
3. LAYOUT AND SPREADSHEET OF BUTTONS:
3.1 Layout of buttons
Left Wing LT/Y- Right Wing RT/Y+
MODE,
Back-lit Indicators
PROG,
Back-lit Indicators
Gear Shift
D-pad ABXY Functions Buttons
3.2 Layout of gearshift and Pedals Port
Pedals Port
LT/7
RT/8 Y/1
3.3 Spreadsheet of buttons
Type PC (X-INPUT) PC (D-INPUT)
A 3
B 2
X 4
Actions Buttons Y 1
RB 6
LB 5
RT 8
LT 7
RS 12
LS 11
D-PAD UP UP
DOWN DOWN
LEFT LEFT
RIGHT RIGHT
Functions Buttons START 10
BACK 9
←/→ ←/→
Left Wing LT Y-
Right Wing RT Y+
LT 7
RT 8
Y 1
Left Pedal LT Y-
Right Pedal RT Y+
X-Guide MODE
Gear Shift
MODE Press and hold for 3seconds to switch between
X-INPUT and D-INPUT
A
Gear Shift
A
4. FUNCTION INTRODUCTION:
4.1 Program Functions (without memory)
4.1.1 Introduction
1. Program source button: X/4, B/2, Y/1, A/3, LB/5, LT/7, RB/6, RT/8
2. Programmable button: Left Wing, Right Wing, Pedal of Gas, Pedal of Brake,
LS/11, RS/12, Gear Shift (LT/7,RT/8)
4.1.2 Program setup
1. Press Prog, Hold for 3 seconds until the green LED is on.
2. Press the programmable button, and the green LED starts blinking
3. Press program source button. The green LED is off. Program is set.
4.1.3 Clear single program
1. Press Prog, Hold for 3 seconds until the green LED is on
2. Press programmed button and the green LED starts blinking
3. Press programmed button again and the green LED is off.
Single programmed button is cleared
4.1.4 Clear all programs
1. Press Prog, Hold for 3 seconds until the green LED is on
2. Press START/10 and hold for 4 seconds. The green LED is off.
All of the programmed buttons are cleared. Default is restored
Note: All programs will be cleared after the wheel is power off, it means the
wheel does not have memory of program.
4.2 Wheel sensitivity adjustment
1. Press BACK/9+START/10, Hold for 3 seconds until green LED is on
2. Press BACK/9, Existing sensitivity will be displayed
3. Press BACK/9, Select sensitivity according to the circulation below:
Medium(GreenLEDash)
High (Green LED Flash quickly)
Low (Green LED Flash slowly)
4.3 The pedals in digital mode have analog functions:
Performance:Theharderthepedalispressed,thelargervalue,thehigherashing
5. FOR USE WITH PC:
5.1 Switch of modes
1. Default X-INPUT, Back lit Red LED is on
2. Press and hold MODE for3 seconds, D-INPUT will activated and Red LED is on.
5.2 D-input installation:
1. Download the drivers from the www.konix-interactive.com website.
Enter Option -> Controllers -> Dead Zone Adjust the range of dead zone, in order
to make the axis is within the range:
AxisPort
Action zone Dead zone Action zone
4. Motors keeps vibrating after entering game:
Enter Force Feedback and turn off or turn down Engine
Engine
5. Weak vibration after entering game;
Enter Force Feedback Turn up “STICK VOLUME”, “ROAD EFFECTS”
6.Difcultcalibratingontestingplatform
Please press “Default”, and “Set”.
6. TROUBLE SHOOTING:
Double click SETUP and follow on-screen instructions to complete
the driver installation.
2. Connect the wheel to your PC -> Start -> Control Panel -> Game controller,
the PC will detect “KX Drakkar Styri” automatically -> Properties.
5.3 Test
1. Enter Test interface to test buttons and axis functions
2. Enter Calibration interface to calibrate the axis
3. Enter Vibration interface to test axis and pedals
5.4 Driver Uninstall
1. Start -> Control Panel -> programs/Function
2. Find the driver you want to remove in the Interface” current installed
programs”. Click “Remove” and follow the instructions to get successful
uninstall.
A
1. If the racing wheel does not work after software/hardware is installed
successfully, please check if the wheel is connecting with the PC robustly.
Please restore the PC if it doesn’t work either.
2. No vibration while gaming (e.g, Need for Speed), Please re-enter after exiting
the game (Do not plug and unplug the USB port while playing). Please restore
the PC if it still does not work.
3. Some analog axis works automatically (e.g, Need for Speed), the wheel is not
calibratedorcalibrationisnotconrmed
7. PRECAUTIONS:
1. Please read through and familiarize the manual before using this racing wheel
2. Do not hit, drop or abuse it
3. Do not disassemble, modify or try to repair by yourself
4. Do not store it in place that is moist, hot or greasy
Note: before moving the wheel, please loose the biggest suction cup to prevent
damage to your wheel or table, see demo:
Foldable Pedals
ACC (Y+)Brake (Y-)
A
Z
1. INTRODUCTION :
Merci d’avoir acheté le volant Drakkar Styri conçu pour les PC. Il est compatible
avec tous les jeux PC et dispose de moteurs intégrés pouvant générer différentes
vibrations selon votre statut dans le jeu (si le logiciel de jeu prend en charge la fonc-
tion Vibration). La forme du volant reprend celle des voitures de course, sa concep-
tion a été pensée en fonction de l’ergonomie humaine. Vous ne vous sentirez pas
fatigué avant longtemps, même si vous l’utilisez pendant des heures. Cela rend le
jeu encore plus réaliste, plus maniable et plus intéressant.
2. CARACTÉRISTIQUES :
1. Compatible avec Windows XP/Vista/7/8/10
2. Deux modes X-INPUT et D-INPUT (mode X-INPUT par défaut)
3. Appuyez sur MODE pendant 3 secondes pour basculer entre les modes
X-INPUT et D-INPUT
4. 4 boutons directionnels de 8 façons
(haut, bas, gauche, droite et 45 degrés X 4)
5. 4 boutons d’entrée numérique :
10/Démarrage, 9/ARRIÈRE, 11/Côté gauche, 12/Côté droite
6. 8 boutons de programmation : aile gauche, aile droite, levier de vitesse
(TG/TD), pédale d’essence, pédale de frein, G3, D3
7. Sensibilité facultative en trois étapes pour multi-demande avec des
éclairages LED indiquant le réglage actuel
8. Six ventouses permettant une très forte adhérence de longue durée sur
surface lisse
9. Deux directions avec rotation réaliste à 270 degrés offrant immersion
et plaisir
10. Les ailes gauche/droite et les pédales possèdent des fonctions de gaz et
vous offrent une meilleure expérience de conduite
11. Deux moteurs génèrent un retour de vibration
12. Moins de consommation d’énergie, plus de géo-convivialité. Source
d’alimentation : USB 5 V, courant : 16 mA (lorsque les moteurs sont fermés),
80 mA (moteur gauche), 75 mA (moteur droit).
Z
3. DISPOSITION ET TABLEUR DE BOUTONS :
3.1 Disposition des boutons
Aile gauche TG/Y- Aile droite TD/ Y+
MODE, Indicateurs
rétroéclairés
PROG, indicateurs
rétro-éclairés
Changement
de vitesse
Croix directionnelle Boutons de fonctions ABXY
3.2 Disposition du changement de vitesse
et du port du pédalier
Port du pédalier
TG/7
TD/8 Y/1
