Firmware Updater Guide

magicolor 3730DN

A0VD-9900-01A

Contents i

Contents

1Updating the Firmware (for Windows) ............................................................ 1

System Requirements....................................................................................... 2

Starting the Firmware Updater ......................................................................... 3

2Updating the Firmware (for Macintosh) .......................................................... 7

System Requirements....................................................................................... 8

Starting the Firmware Updater ......................................................................... 9

Contentsii

1Updating the

Firmware

(for Windows)

System Requirements2

System Requirements

Computer:

– PC with a Pentium 2, 400 MHz or faster processor

(A Pentium 3, 500 MHz or faster processor is recommended.)

Operating system:

– 32bit

Microsoft Windows 7 Home Premium/Professional/Ultimate/

Enterprise, Windows Vista Home Basic/Home Premium/Ultimate/

Business/Enterprise, Windows XP Home Edition/Professional,

Windows 2000, Windows Server 2008, Windows Server 2003

– 64bit

Microsoft Windows 7 Home Premium/Professional/Ultimate/

Enterprise, Windows Vista Home Basic/Home Premium/Ultimate/

Business/Enterprise, Windows XP Professional, Windows Server

2008, Windows Server 2003

Available hard disk space:

– Approximately 20~26 MB

Memory:

– 128 MB or more

Interface:

– 10Base-T/100Base-TX Ethernet

– USB 2.0 (High Speed) compliant

Compatible printer:

– magicolor 3730DN

Starting the Firmware Updater 3

Starting the Firmware Updater

CAUTION

You must have administrator privileges in order to update the firmware.

CAUTION

Before starting the firmware updater, turn on the printer, and make sure

that it is correctly connected with a USB cable or network cable. In

addition, confirm that the printer driver is installed with a USB

connection or network connection.

CAUTION

Do not perform any of the following operations while updating the

firmware.

– Turn off the printer.

– Turn off the computer running the firmware updater.

– Exit the firmware updater.

– Send a print job to the printer from any other computer on the net-

work.

The following procedure describes how to update the controller firmware.

Follow the same procedure to update the engine firmware.

Starting the Firmware Updater4

1Connect the computer and the printer with a USB cable or network cable,

and turn on the power of the printer.

2Confirm that the printer driver is installed in the computer with a USB con-

nection or network connection.

3Print the configuration page from the printer control panel to check the

current firmware version.

" For details on printing the configuration page and using the printer

control panel, refer to the printer’s User’s Guide.

4Download the firmware updater from the Web site, and then decompress

it in any folder.

5Double-click the firmware updater (exe format).

" If the User Account Control window appears when installing on

Windows 7/Vista/Server 2008, click Allow button or Continue but-

ton.

6The Software End User License Agreement is displayed. Select “I accept

the terms of the licence agreement.”, and then click [OK] button.

Starting the Firmware Updater 5

7Confirm that the printer driver name of this printer is displayed in the

Driver List, and the connection form of the computer and the printer is dis-

played in the Port List. Then click [Start Download] button.

" If nothing is displayed in the Driver List and the Port List, the

printer driver is not correctly installed. Reinstall the printer driver.

" With a USB connection, USBXXX is displayed in the Port List.

8Click [OK] button to begin transferring the firmware.

The message window on the printer control panel changes into “CON-

TROLLER FW / UPDATING”.

" Do not turn off the printer while its firmware is being updated.

9The message window on the printer control panel changes into “CON-

TROLLER FW / DWLD COMPLETE” when the firmware update is com-

pleted.

Click button, and finish the firmware updater.

%10641..'4(9

72&#6+0)

%10641..'4(9

&9.&%1/2.'6'

Starting the Firmware Updater6

10 Turn off/on the power of the printer.

11 Print the configuration page from the printer control panel to check the

firmware version after the updating.
