Kohler Command PRO CH940 Manual de usuario

CH940-CH1000

Service Manual

KohlerEngines.com

IMPORTANT: Read all safety precautions and instructions carefully before operating equipment. Refer to operating

instruction of equipment that this engine powers.

Ensure engine is stopped and level before performing any maintenance or service.

62 690 01 Rev. C 1

2 Safety

3 Maintenance

5 Speciﬁcations

13 Tools and Aids

16 Troubleshooting

20 Air Cleaner/Intake

21 Fuel System

27 Governor System

28 Lubrication System

30 Electrical System

45 Disassembly/Inspection and Service

59 Reassembly

Safety

2 62 690 01 Rev. CKohlerEngines.com

SAFETY PRECAUTIONS

WARNING: A hazard that could result in death, serious injury, or substantial property damage.

CAUTION: A hazard that could result in minor personal injury or property damage.

NOTE: is used to notify people of important installation, operation, or maintenance information.

WARNING

Explosive Fuel can cause

ﬁres and severe burns.

Do not ﬁll fuel tank while

engine is hot or running.

Gasoline is extremely ﬂammable

and its vapors can explode if

ignited. Store gasoline only in

approved containers, in well

ventilated, unoccupied buildings,

away from sparks or ﬂames.

Spilled fuel could ignite if it comes

in contact with hot parts or sparks

from ignition. Never use gasoline

as a cleaning agent.

WARNING

Rotating Parts can cause

severe injury.

Stay away while engine

is in operation.

Keep hands, feet, hair, and

clothing away from all moving

parts to prevent injury. Never

operate engine with covers,

shrouds, or guards removed.

WARNING

Carbon Monoxide can

cause severe nausea,

fainting or death.

Avoid inhaling exhaust

fumes.

Engine exhaust gases contain

poisonous carbon monoxide.

Carbon monoxide is odorless,

colorless, and can cause death if

inhaled.

WARNING

Accidental Starts can

cause severe injury or

death.

Disconnect and ground

spark plug lead(s) before

servicing.

Before working on engine or

equipment, disable engine as

follows: 1) Disconnect spark plug

lead(s). 2) Disconnect negative (–)

battery cable from battery.

WARNING

Hot Parts can cause

severe burns.

Do not touch engine

while operating or just

after stopping.

Never operate engine with heat

shields or guards removed.

WARNING

Cleaning Solvents can

cause severe injury or

death.

Use only in well

ventilated areas away

from ignition sources.

Carburetor cleaners and solvents

are extremely ﬂammable. Follow

cleaner manufacturer’s warnings

and instructions on its proper and

safe use. Never use gasoline as a

cleaning agent.

CAUTION

Electrical Shock can

cause injury.

Do not touch wires while

engine is running.

CAUTION

Damaging Crankshaft

and Flywheel Can cause

personal injury.

Using improper procedures can

lead to broken fragments. Broken

fragments could be thrown from

engine. Always observe and use

precautions and procedures when

installing ﬂywheel.

CAUTION

Failure to utilize or

reassemble debris

screen as designed could

result in debris screen

failure and serious

personal injury.

Maintenance

362 690 01 Rev. C KohlerEngines.com

MAINTENANCE INSTRUCTIONS

WARNING

Before working on engine or equipment, disable engine as

follows: 1) Disconnect spark plug lead(s). 2) Disconnect

negative (–) battery cable from battery.

Accidental Starts can cause severe injury or

death.

Disconnect and ground spark plug lead(s)

before servicing.

Normal maintenance, replacement or repair of emission control devices and systems may be performed by any repair

establishment or individual; however, warranty repairs must be performed by a Kohler authorized dealer.

MAINTENANCE SCHEDULE

Weekly

●Check ﬁlter minder. Air Cleaner/Intake

Every 25 Hours or Annually¹

●Service/replace low-proﬁle precleaner. Air Cleaner/Intake

Every 150 Hours¹

●Replace low-proﬁle air cleaner element. Air Cleaner/Intake

●Change oil. Oil ﬁlter is recommended. Lubrication System

●Remove cooling shrouds and clean cooling areas. Air Cleaner/Intake

Every 150 Hours

●Check heavy-duty air cleaner element. Air Cleaner/Intake

●Replace fuel ﬁlter.

●Check oil cooler ﬁns, clean as necessary. Lubrication System

Every 300 Hours

●Change oil ﬁlter. Lubrication System

●Replace heavy-duty air cleaner element. Air Cleaner/Intake

Every 500 Hours²

●Have crankshaft splines lubricated.

Every 600 Hours

●Replace heavy-duty inner air cleaner element. Air Cleaner/Intake

●Replace spark plugs and set gap. Electrical System

1Perform these procedures more frequently under severe, dusty, dirty conditions.

2Have a Kohler authorized dealer perform this service.

REPAIRS/SERVICE PARTS

Kohler genuine service parts can be purchased from Kohler authorized dealers. To ﬁnd a local Kohler authorized

dealer visit KohlerEngines.com or call 1-800-544-2444 (U.S. and Canada).

Maintenance

4 62 690 01 Rev. CKohlerEngines.com

OIL RECOMMENDATIONS

We recommend use of Kohler oils for best performance.

Other high-quality detergent oils (including synthetic)

of API (American Petroleum Institute) service class SJ

or higher are acceptable. Select viscosity based on

air temperature at time of operation as shown in table

below.

FUEL RECOMMENDATIONS

WARNING

Explosive Fuel can cause ﬁres and severe

burns.

Do not ﬁll fuel tank while engine is hot or

running.

Gasoline is extremely ﬂammable and its vapors can

explode if ignited. Store gasoline only in approved

containers, in well ventilated, unoccupied buildings,

away from sparks or ﬂames. Spilled fuel could ignite

if it comes in contact with hot parts or sparks from

ignition. Never use gasoline as a cleaning agent.

NOTE: E15, E20 and E85 are NOT approved and

should NOT be used; effects of old, stale or

contaminated fuel are not warrantable.

Fuel must meet these requirements:

●Clean, fresh, unleaded gasoline.

●Octane rating of 87 (R+M)/2 or higher.

●Research Octane Number (RON) 90 octane minimum.

●Gasoline up to 10% ethyl alcohol, 90% unleaded is

acceptable.

●Methyl Tertiary Butyl Ether (MTBE) and unleaded

gasoline blend (max 15% MTBE by volume) are

approved.

●Do not add oil to gasoline.

●Do not overﬁll fuel tank.

●Do not use gasoline older than 30 days.

STORAGE

If engine will be out of service for 2 months or more

follow procedure below.

1. Add Kohler PRO Series fuel treatment or equivalent

to fuel tank. Run engine 2-3 minutes to get stabilized

fuel into fuel system (failures due to untreated fuel

are not warrantable).

2. Change oil while engine is still warm from operation.

Remove spark plug(s) and pour about 1 oz. of

engine oil into cylinder(s). Replace spark plug(s) and

crank engine slowly to distribute oil.

3. Disconnect negative (-) battery cable.

4. Store engine in a clean, dry place.

Speciﬁcations

562 690 01 Rev. C KohlerEngines.com

Dimensions in millimeters.

Inch equivalents shown in [ ].

Engine Dimensions with Heavy-Duty Air Cleaner

Speciﬁcations

6 62 690 01 Rev. CKohlerEngines.com

Dimensions in millimeters.

Inch equivalents shown in [ ].

Engine Dimensions with Low-Proﬁle Air Cleaner

Speciﬁcations

762 690 01 Rev. C KohlerEngines.com

ENGINE IDENTIFICATION NUMBERS

Kohler engine identiﬁcation numbers (model, speciﬁcation and serial) should be referenced for efﬁcient repair,

ordering correct parts, and engine replacement.

GENERAL SPECIFICATIONS3,6 CH940 CH960 CH980 CH1000

Bore 90 mm (3.54 in.)

Stroke 78.5 mm (3.1 in.)

Displacement 999 cc (61 cu. in.)

Oil Capacity (reﬁll) 2.7 L (2.9 U.S. qt.)

Maximum Angle of Operation (@ full oil level)425°

TORQUE SPECIFICATIONS3,5 CH940 CH960 CH980 CH1000

Blower Housing and Sheet Metal

M6 Screw

New, Untapped Hole (casting)

Used, Tapped Hole (casting)

New, Extruded Hole (sheet metal)

Used, Extruded Hole (sheet metal)

Mounting Clip (valley bafﬂe)

10.7 N·m (95 in. lb.)

7.3 N·m (65 in. lb.)

4.0 N·m (35 in. lb.)

2.0 N·m (18 in. lb.)

2.5 N·m (22 in. lb.)

Carburetor, Intake Manifold, and Air Cleaner

Intake Manifold Mounting Fastener (torque in 2 increments) ﬁrst to 16.9 N·m (150 in. lb.)

ﬁnally to 22.6 N·m (200 in. lb.)

Carburetor/Air Cleaner Mounting Nut 7.9 N·m (70 in. lb.)

Carburetor Fuel Bowl Screw 2.5 N·m (22 in. lb.) ± 0.3 N·m (3 in. lb.)

Air Cleaner Mounting Screw (into intake manifold) 9.9 N·m (88 in. lb.)

Closure Plate

Closure Plate Fastener 24.4 N·m (216 in. lb.)

Connecting Rod

Cap Fastener (torque in increments) 11.3 N·m (100 in. lb.)

Control Bracket

Mounting Screw (into intake manifold from air cleaner) 9.9 N·m (88 in. lb.)

3 Values are in Metric units. Values in parentheses are English equivalents.

4Exceeding maximum angle of operation may cause engine damage from insufﬁcient lubrication.

5Lubricate threads with engine oil prior to assembly.

6Any and all horsepower (hp) references by Kohler are Certiﬁed Power Ratings and per SAE J1940 & J1995 hp

standards. Details on Certiﬁed Power Ratings can be found at KohlerEngines.com.

Model. . . . . . . . . . . . . . . . . . . . . CH940

Command Engine

Horizontal Shaft

Numerical Designation

Speciﬁcation . . . . . . . . . . . . . . . CH940-0001

Serial . . . . . . . . . . . . . . . . . . . . . 3923500328

Year Manufactured Code Factory Code

Code Year

39 2009

40 2010

41 2011

Speciﬁcations

8 62 690 01 Rev. CKohlerEngines.com

TORQUE SPECIFICATIONS3,5 CH940 CH960 CH980 CH1000

Control Panel

M6 screw 10.7 N·m (95 in. lb.) into new holes

7.3 N·m (65 in. lb.) into used holes

M5 screws 6.2 N·m (55 in. lb.) into new holes

4.0 N·m (35 in. lb.) into used holes

Crankcase

Breather Cover Fastener 5.7 N·m (51 in. lb.)

Oil Drain Plug 21.4 N·m (16 ft. lb.)

Cylinder Head

Cylinder Head Fastener (torque in 2 increments)

Head Bolt ﬁrst to 22.6 N·m (200 in. lb.)

ﬁnally to 45.2 N·m (400 in. lb.)

Pipe Plug (3/4 in.) 28.25 N·m (250 in. lb.)

Rocker Arm Screw 14.6 N·m (130 in. lb.)

Debris Screen

Hex Stud 9.9 N·m (88 in. lb.)

Mounting Screw 9.9 N·m (88 in. lb.)

Front Drive Shaft Screw (into ﬂywheel) 24.4 N·m (216 in. lb.)

Fan/Flywheel

Fan Fastener 9.9 N·m (88 in. lb.)

Flywheel Retaining Screw 67.8 N·m (50 ft . lb.)

Governor

Governor Lever Nut 7.3 N·m (65 in. lb.)

Governor Yoke Mounting Screw 2.2 N·m (20 in. lb.)

Ignition

Spark Plug 27 N·m (20 ft. lb.)

Ignition Module Fastener 6.2 N·m (55 in. lb.) into new holes

4.0 N·m (35 in. lb.) into used holes

Rectiﬁer-Regulator Fastener 2.0 N·m (18 in. lb.)

Lifter Feed Chamber

Cover/Bafﬂe Screw 6.2 N·m (55 in. lb.) into new holes

4.0 N·m (35 in. lb.) into used holes

Mufﬂer

Retaining Nut 24.4 N·m (216 in. lb.)

M6 Screw 9.9 N·m (88 in. lb.)

M8 Screw 24.4 N·m (216 in. lb.)

Oil Cooler

Mounting Screws 2.2 N·m (20 in. lb.)

Oil Filter Adapter/Housing

Adapter/Housing Mounting Screw 24.4 N·m (216 in. lb.)

Oil Filter Nipple 18.0 N·m (159 in. lb.)

3 Values are in Metric units. Values in parentheses are English equivalents.

5Lubricate threads with engine oil prior to assembly.

Speciﬁcations

962 690 01 Rev. C KohlerEngines.com

TORQUE SPECIFICATIONS3,5 CH940 CH960 CH980 CH1000

Oil Pickup Screen

Mounting Screw 10.7 N·m (95 in. lb.) into new holes

7.3 N·m (65 in. lb.) into used holes

Oil Pickup Tube

Mounting Screw 10.7 N·m (95 in. lb.) into new holes

7.3 N·m (65 in. lb.) into used holes

Oil Pump

Mounting Screw 10.7 N·m (95 in. lb.) into new holes

6.7 N·m (60 in. lb.) into used holes

Oil SentryTM

Pressure Switch 10.1 N·m (90 in. lb.)

Reservoir (oil)

Mounting Screw 24.4 N·m (216 in. lb.)

Solenoid (starter)

Mounting Hardware 4.0-6.0 N·m (35-53 in. lb.)

Nut, Positive (+) Brush Lead 8.0-11.0 N·m (71-97 in. lb.)

Starter Assembly

Thru Bolt 5.6-9.0 N·m (49-79 in. lb.)

Mounting Screw 15.3 N·m (135 in. lb.)

Brush Holder Mounting Screw 2.5-3.3 N·m (22-29 in. lb.)

Stator

Mounting Screw 6.2 N·m (55 in. lb.)

Throttle/Choke Control Bracket

Fastener 9.9 N·m (88 in. lb.)

Valve Cover

Valve Cover Fastener 13.6 N·m (120 in. lb.)

CLEARANCE SPECIFICATIONS3CH940 CH960 CH980 CH1000

Camshaft

End Play 0.3/1.3 mm (0.011/0.051 in.)

Running Clearance 0.025/0.063 mm (0.0010/0.0025 in.)

Bore I.D.

New

Max. Wear Limit

20.000/20.025 mm (0.7874/0.7884 in.)

20.038 mm (0.7889 in.)

Bearing Surface O.D.

New

Max. Wear Limit

19.962/19.975 mm (0.7859/0.7864 in.)

19.959 mm (0.7858 in.)

Cam Lobe Proﬁle (minimum dimension, measured from base circle

to top of lobe)

Exhaust 35 mm (1.3779 in.)

Intake 34.1 mm

(1.3425 in.)

35 mm (1.3779 in.)

3 Values are in Metric units. Values in parentheses are English equivalents.

5Lubricate threads with engine oil prior to assembly.

Speciﬁcations

10 62 690 01 Rev. CKohlerEngines.com

CLEARANCE SPECIFICATIONS3CH940 CH960 CH980 CH1000

Connecting Rod

Crankpin End I.D. @ 70°F

New

Max. Wear Limit

44.030/44.037 mm (1.7334/1.7337 in.)

0.070 mm (0.0028 in.)

Connecting Rod-to-Crankpin Running Clearance

New

Max. Wear Limit

0.030/0.055 mm (0.0012/0.0022 in.)

0.070 mm (0.0028 in.)

Connecting Rod-to-Crankpin Side Clearance 0.30/0.59 mm (0.0118/0.0232 in.)

Connecting Rod-to-Piston Pin Running Clearance 0.015/0.028 mm (0.0006/0.0011 in.)

Piston Pin End I.D. @ 70°F

New

Max. Wear Limit

19.023/19.015 mm (0.7489/0.7486 in.)

19.036 mm (0.7494 in.)

Crankcase

Governor Cross Shaft Bore I.D.

New

Max. Wear Limit

8.025/8.050 mm (0.3159/0.3169 in.)

8.088 mm (0.3184 in.)

Crankshaft

End Play (free) 0.30/1.50 mm (0.011/0.059 in.)

Crankshaft Bore (in crankcase)

New, Without Main Bearing

With Main Bearing Installed

Max. Wear Limit

50.00/50.025 mm (1.9685/1.969 in.)

45.040/45.145 mm (1.7732/1.7773 in.)

45.158 mm (1.7778 in.)

Crankshaft to Sleeve Bearing (in crankcase) Running Clearance

New 0.040/0.167 mm (0.0015/0.0065 in.)

Crankshaft Bore (in closure plate)

New, Without Bearing 50.025/50.00 mm (1.9694/1.9685 in.)

Crankshaft to Sleeve Bearing (in closure plate) Running Clearance

New 0.040/0.167 mm (0.0015/0.0065 in.)

Closure Plate End Main Bearing Journal

O.D. - New

O.D. - Max. Wear Limit

Max. Taper

Max. Out-of-Round

44.978/45.00 mm (1.770/1.771 in.)

44.90 mm (1.767 in.)

0.022 mm (0.0009 in.)

0.025 mm (0.0010 in.)

Connecting Rod Journal

O.D. - New

O.D. - Max. Wear Limit

Max. Taper

Max. Out-of-Round

Width

43.982/44.000 mm (1.731/1.732 in.)

43.97 mm (1.731 in.)

0.018 mm (0.0007 in.)

0.025 mm (0.0010 in.)

53.00/53.09 mm (2.0866/2.0901 in.)

Crankshaft T.I.R.

PTO End, Crank in Engine

Entire Crank, in V-Blocks

0.279 mm (0.0110 in.)

0.10 mm (0.0039 in.)

Flywheel End Main Bearing Journal

O.D. - New

O.D. - Max. Wear Limit

Max. Taper

Max. Out-of-Round

44.978/45.00 mm (1.770/1.771 in.)

44.90 mm (1.767 in.)

0.022 mm (0.0009 in.)

0.025 mm (0.0010 in.)

Cylinder Bore

Cylinder Bore I.D.

New

Max. Wear Limit

Max. Taper

Max. Out-of-Round

90.000/90.025 mm (3.543/3.544 in.)

90.075 mm (3.546 in.)

0.013 mm (0.00051 in.)

3 Values are in Metric units. Values in parentheses are English equivalents.

Otros manuales para Command PRO CH940

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Motor de Kohler

Kohler

Kohler HD675 Manual de usuario

Kohler

Kohler KD 625/2 Manual de lista de piezas

Kohler

Kohler Courage SV710 Manual de usuario

Kohler

Kohler Command PRO ECH749 Manual de usuario

Kohler

Kohler 40EOZD Manual de usuario

Kohler

Kohler LOMBARDINI MARINE KDI 1903TCR-MP Manual de usuario

Kohler

Kohler Magnum M8 Manual de usuario

Kohler

Kohler Command PRO CH621 Manual de usuario

Kohler

Kohler KG2204T Manual de instrucciones

Kohler

Kohler K9J Manual de usuario

Kohler

Kohler Command Pro CH255 Manual de usuario

Kohler

Kohler KDI 3404 TCR Guía de configuración rápida

Kohler

Kohler KD15 500 Guía del usuario

Kohler

Kohler Command PRO EFI ECV850 Manual de usuario

Kohler

Kohler Magnum MV16 Manual de usuario

Kohler

Kohler Command Pro CV173 Manual de usuario

Kohler

Kohler KT715 Manual de usuario

Kohler

Kohler Command 6 HP Manual de usuario

Kohler

Kohler KDW 1603 Manual de usuario

Kohler

Kohler LOMBARDINI 9 LD 625-2 Manual de lista de piezas

Kohler

Kohler Command PRO CH260 Manual de usuario

Kohler

Kohler Command PRO CH270 Manual de usuario

Kohler

Kohler COMMAND CH18 Manual de usuario

Kohler

Kohler Magnum 16 HP Manual de usuario

Manuales populares de Motor de otras marcas

Rotax

Rotax 125 senior MAX evo Manual de usuario

MTD

MTD OHV Series Manual de usuario

Mercury

Mercury D4.2L D-Tronic Manual de usuario

Selve

Selve SE Plus-RC Series Manual de usuario

Perkins

Perkins 1206E-E66TA Manual de usuario

Skov

Skov DA 174 Manual

Rossi

Rossi TX11 Series Manual de usuario

Siemens

Siemens SIMOTICS T-1FW3 Hoja de instrucciones

AL-KO

AL-KO PRO 350 Manual de usuario

MTU

MTU 12 V 4000 Lx4 Manual de usuario

Nanni

Nanni N3.30 Manual de instrucciones

Nanni

Nanni N5.160 CR2 Manual de usuario

KSB

KSB SuPreme Series Instrucciones de instalación

Hiwin

Hiwin EM1 Series Manual de usuario

Rotax

Rotax 912 i series Instrucciones de funcionamiento

Siemens

Siemens SIMOTICS XP 1MB1 Manual de usuario

Bosch

Bosch Rexroth 70 Series Manual de usuario

Wacker Neuson

Wacker Neuson WM 130 Instrucciones de funcionamiento
