Kogan KAFHDSLDBELA Manual de usuario
Overview
Component
Description
peaker
udio output
ens
deo capture
frared LED
dditional light in low-light conditions
ght Sensor
ght sensor
dicator light
atus Indicator light shows the doorbell’s status
oorbell button
ou will receive notification from the mobile app when it's pressed
icrophone
etects sound for the mobile App
2
Component
Description
E Label
roduct label
eset
y pressing the reset button on the back of the device for more than 3 seconds,
you will reset the device. You will hear a sound and see the indicator light
blinking red, confirming the reset
arm button
amper alarm
SB Port
onnect to charge the doorbell
ower Switch
ower OFF/ON
Installation
Method 1
Step 1: Stick the double-sided 3m stickers on the bracket.
3
Step 2: Tear off the protective film on the 3M sticker, apply it on a smooth wall surface at the appropriate
height. Hang the device on the bracket from top down lining up the hole at back of device. Tighten the
screw on the bottom of the unit to the bracket.
Method 2
If you want to install the device on a rough wall (such as concrete, brick or a wooden surface), use screws
to fix the bracket. This should only be completed by someone who qualified in this type of maintenance.
1. Mount the bracket on the wall at the appropriate height and mark the location of the screw holes.
Drill the holes and fasten the mount to the wall with the screws.
2. Hang the device on the bracket from the top down lining up the hole at back of device. Insert the
bottom screw.
4
Install the Application
Download the “Kogan Smarter Home” app from the Play Store (Android) or App Store (iOS).
Register
If you do not have a Kogan Smarter Home account, register or sign in with a verification code sent by
SMS.
To register
1. Tap to enter registration page.
2. The system automatically recognises your country / area. You can also select your country code
manually. Enter your mobile phone number/ email address and tap “Next”.
3. If you choose the mobile phone number option, then enter the verification code in the message
sent to you by SMS. Set a password as prompted and press “Confirm” to finish your registration.
Add Device Through Network
1. Power the SmarterHome device on and follow the product-specific instructions to enter the
Wi-Fi-connect mode.
2. Open Kogan SmarterHome app and tap “+” in the upper right to add a new device through the
network.
3. Ensure the device’s indicator light rapidly flashes and tap “Confirm light is rapidly flashing”.
4. Select Wi-Fi network (note: network must be 2.4GHz band) and enter the password. The device
will commence the pairing process(QR Code Net-pairing or Smart Configuration are optional) and
connect to the app.
QR code pairing :
5
Smart configuration:
5. After successfully configuring the devices, the device will be shown on the home page. Tap to
enter its control page.
Note
6
• When device is online, it can be controlled.
• When device is offline, it displays “Offline” and cannot be remotely powered on.
Google Home Control
Note: You will need to have set up a Google Home account prior to linking your Kogan SmarterHome
device.
1. Select “Menu” and then “Home Control”.
2. In the “Home Control” screen, select the + icon in the bottom right.
3. A list will appear showing actions and a search function to access more apps: from here, install
the SmarterHome app.
4. Log into your SmarterHome account with your email address or mobile number.
5. Once linked, it will show the devices linked to your account: you can assign them to rooms. You
will be prompted to authorise apps to sync.
6. Click “Done” and then it will give you a list of commands available.
7. When successfully linked, you will see it on your “Home Control” screen at the bottom of the app
screen. You can now control your Kogan SmarterHome devices through Google Home.For
example, you can talk to Google with “ Hey google,show me the “device name”
7
Alexa
Note: You will need to have set up an Alexa account prior to linking your Kogan SmarterHome device.
1. Select “Menu” and then “Skills”.
2. Search for the app and enable it.
3. Log into your SmarterHome account with your email address or mobile number.
4. Select “Discover Devices” and the app will begin searching.
5. When successfully linked, you will see a list of connected Kogan SmarterHome devices. You can
now control your Kogan SmarterHome devices through Alexa with your voice. For example, you
can talk to Alexa with“Alexa, show me the “device name”
8
Operation
1. Open the waterproof cover on the back of the device.
2. Switch it from [OFF] to [ON] and then put the cover on.
9
LED Indicator
No.
LED status
Device status
1
Fast blinking blue LED (5 times per second)
Trying to connect to Wi-Fi
2
Slow blinking red LED (2 times per 3 seconds)
Ready or reset to successfully configure
3
Slow blinking blue LED (1 time per 3 seconds)
Connecting to service
4
Blue and Red LED are off
Sleep mode or off-line
5
Fast blinking blue and red
Firmware upgrade
6
Bright blue LED
Networking is successful and working
properly or watch live video
Charging Your Doorbell
• Loosen the screw at the bottom of the doorbell and remove the doorbell from bracket. You
will hear the alarm sound for approximately 1 minute.
10
