Kodak ADVANTIX KD40 Manual de usuario

KD40

CAMERA

Kodak

MODE

ON/OFF

Equipment subject to minor appearance and specification changes.

Camera Identification

ON/OFF

MODE

234567

1011

( )

Camera Identification

14 15

( )

F I L M T I P

21 22 23 24 25

26 27 28

3031

ENGLISH

Congratulations!And thank you for buying a KODAK Camera.

Your new compact, 35 mm camera with motorized film advance

and auto-film rewind, makes taking pictures easy. The camera

uses any DX/DXN, 35 mm color or black-and-white print film with

a speed of ISO 100, 200, 400, or 1000.

For warranty purposes, please keep your sales receipt as

proof of the date of purchase.

Contents

Camera Identification ......................................................... 7

Specifications .................................................................... 8

Attaching the Camera Strap............................................... 9

Loading the Battery ............................................................ 9

Loading The Film ............................................................. 11

Taking Pictures................................................................. 14

Taking Flash Pictures ....................................................... 21

Unloading the Film ........................................................... 26

Caring for Your Camera .................................................. 27

Troubleshooting .............................................................. 28

Camera Identification

1Shutter Button

2On/Off Button

3LCD Panel

4Mode-Selection

Button

5Rewind Button

6Self-Timer Button

7Viewfinder

8Flash

9Film-Door Latch

10 Lens Cover/Lens

11 Red-Eye-

Reduction Lamp

12 Self-Timer Lamp

13 Light Sensor

14 Panoramic Switch

15 Viewfinder

Eyepiece

16 Film Window

17 Battery Door

18 Strap Post

19 TripodSocket

20 Film Door

21 Film-Load Mark

22 FilmTake-Up

Spool

23 DX-Code Sensors

24 Film Chamber

25 Film Spindle

LCD Panel

26 Self-Timer

Indicator

27 Picture Counter

28 Infinity-Focus

Indicator

29 Fill-Flash/Flash-

Charging Indicator

30 Flash-Off Indicator

31 Battery Symbol

32 Red-Eye-

Reduction Indicator

Specifications

Type: Compact, 35 mm camera

LCD Panel: Display indicators for red-eye reduction, fill-flash/flash-charging,

flash-off, infinity-focus, self-timer, and the frame number and

battery symbol

Lens: 28 mm, 3-element hybrid

Viewfinder: Reverse-Galilean with panoramic masking in panoramic mode

Film Speed: 2-step DX for ISO 100/200 and ISO 400/1000

Focus Range: Daylight: 1.2 m to infinity

Flash Unit: Electronic with ISO 100/21˚, guide number of 8 m;

flash automatically turns on at low-light levels

Aperture: Flash:

/4.5; Daylight:

/7.0

Shutter: 1/125 sec

Power Source: One 3-volt lithium KODAK K123LA(or equivalent) Battery

Dimensions: 123.5 x 68.8 x 32.7 mm

Weight: 170 g

Attaching the

Camera Strap

Thread the short loop of the strap

under the Strap Post (18); pull the

long loop through the short loop

and pull it tight.

Loading the Battery

This camera uses a 3-volt lithium

KODAK K123LA(or equivalent)

Battery that supplies power for all

camera operations.

NOTE: This camera automatically

turns off after approximately

3 minutes to conserve battery

energy.

Battery Tips

• Keep a spare battery with you

at all times. Lithium batteries

perform consistently until

they suddenly die.

• Read and follow all warnings

and instructions supplied by the

battery manufacturer.

• Keep batteries away from

children.

• Do not try to take apart,

recharge or short circuit the

battery, or subject it to high

temperature or fire.

• Store batteries in their original

packaging prior to use.

Low-Battery Indicator

It’s time to replace the battery

when—

• the Battery

Symbol (31)

appears on the LCD Panel (3).

• the battery

symbol on the

LCD panel

“blinks.”

• none of the indicators appear

on the LCD panel.
