Kodak Advantix 3700ix Manual de usuario

3700ix/3800ix

Camera

Look for this logo to be certain that the film

you buy is made for this camera.

Look for this logo to select a certified

photofinisher for developing your film and to

assure that you get all the features of the

Advanced Photo System.

Partially

Exposed

Fully

Exposed

Unexposed

Processed Negatives

Film Status Indicator (FSI)

A highlighted indicator advances

from one symbol to another to

identify the status of the film inside

the cassette.

(1) (2)

(3)

(4)

(5)

(6)

(8)

(9)

(7)

(16)

(15) (10)

(13)

(14)

SELECT

ENTER

(11)

(12)

(18)

(19)

(20)

(17)

EXP

LEFT

OPEN

LCD

(a) (b) (c)

LCD

(d)

(21)

(24) (23)

(26)

(27)

ISO

FILL

(28)

OFF

(25)

(22)

LCD

(e)

(f)

456

ENGLISH

Need help with your camera or more information about the new Advanced

Photo System? Call Kodak (United States only) toll free from 8:00 a.m. to

8:00 p.m. (Eastern time) Monday through Friday at 1 (800) 242-2424. The

toll free number (in Canada only) from 8:30 a.m. to 5:00 p.m. (Eastern time)

Monday through Friday is 1 (800) 465-6325; please ask for ext. 36100.

For warranty purposes, please keep your sales receipt as proof of the date

of purchase.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

NOTE: Your model camera has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits provide reasonable protection against

interference in residential use. The camera generates, uses and can radiate radio frequency energy

and, if not used in accordance with the instructions, may cause interference to radio communica-

tions. There is no guarantee that interference will not occur. If this camera does cause interference to

radio or television reception, which can be determined by turning the camera off and on, you may

reduce the interference by the following:

— Reorient or relocate the receiving antenna.

— Increase the separation between the camera and the receiver.

— Consult the dealer or an experienced radio/television technician for help.

Changes or modifications not approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

CAMERA IDENTIFICATION

See inside cover flaps of manual for camera diagrams.

(1) Shutter Button

(2) Lens Cover/Flash

(3) Print-Size Selector

(4) Self-Timer/Focus-Ranging Assist

(5) Meter-Cell Window

(6) Battery Door

(7) Viewfinder

(8) Lens

(9) Focus-Ranging Sensors

(10) LCD Panel

(11) Menu Button

(12) Select/Flash Button

(13) Enter/Self-Timer Button

(14) Rewind Button

(15) Viewfinder Eyepiece

(16) Focus/Flash Lamp

(17) Tripod Socket

(18) Film-Door Latch

(19) Film Door

(20) Strap Post

(21) Date & Time/ISO Film-Speed

Display

(22) Battery Symbol

(23) Self-Timer Indicator

(24) Auto-Flash Indicator

(25) Film-Presence Indicator

(26) Fill-Flash Indicator

(27) Frame Counter/No Film in

Camera Indicator

(28) Off-Flash Indicator

BATTERY

This camera uses a 3-volt lithium KODAK KCR 2 (or equivalent) Battery that

supplies power for all camera operations. This camera automatically turns off

after 1 minute.

Battery Indicator

When the battery symbol (22) “blinks,” you will need to replace the battery soon. When

the battery symbol is solid (non-blinking) and the shutter button does not operate,

replace the battery immediately.

Battery Tips:

•Keep a spare battery with you at all times. Lithium batteries perform

consistently until they suddenly die.

• Read and follow all warnings and instructions supplied by the battery manufacturer.

• Keep battery away from children.

• Do not attempt to disassemble, recharge or short circuit the battery, or subject it to

high temperature or fire.

• Store battery in its original packaging prior to use.

LOADING THE FILM

1. Slide the film-door latch (18) and insert the film cassette completely into the film

chamber ➌. Do not force the film cassette into the film chamber.

2. Close the film door (19) to start the auto-film advance. The LCD panel (10) will

show the total number of exposures (b). After you close the safety-interlock film

door, you cannot open the film door until the film is completely rewound into

the film cassette.

SETTING THE DATEAND TIME

With this camera, you can record the date and time of each exposure directly onto the film.

The information appears on the back of your prints when processed. It features a clock and

automatic calendar that includes leap years.

1. Press the menu button (11) to choose date. You must press this button to activate the

date and time function.

2. Press the hold the select/flash button (12) to view and change the “blinking” month (d).

3. Press the enter/self-timer button (13) to store the selected month and move to the next

blinking date option (follow steps 2 and 3 to complete your selection.)

4. Repeat steps 1-3 to choose and set time.

NOTE: If you don’t press the select/flash button within a minute, the camera turns off

and returns to the picture-taking mode.

Choosing Optional Date and Time Formats

(mm, dd, yy / dd, mm, yy, / yy, mm, dd and 12/24 hour)

1. Press the menu button (11) to choose date. You must press this button to activate the

date and time function.

2. Press and hold for 3 seconds the enter/self-timer button (13) until desired date format

appears. (See SETTING THE DATE AND TIME, steps 2–3 above to set date.)

3. Press the menu button (11) to choose time.

4. Press and hold the enter/self-timer button (13) until desired time format appears. (See

SETTING THE DATE AND TIME, steps 2–3 above to set time.)

NOTE: If you don’t press the select/flash button within a minute, the camera turns off

and returns to the picture-taking mode.

TAKING PICTURES

You can take Classic (C), HDTV (H), and Panoramic (P) pictures on the same film

cassette (see following table for Typical Print Sizes). Your photo-processing

cost will be based on the format size(s) that you use to expose the film.

1. Lift the lens cover/flash (2), ➍completely up.

2. Move the print-size selector (3), ➎to desired format.

3. Look through the viewfinder eyepiece (15) and place the auto-focus circle (f) on

the subject. For a sharp picture, stand at least 2 ft (0.60 m) from your subject.

4. Press the shutter button (1), ➏to take a picture.

Typical Print Sizes

Classic

31/2x 5" or 4 x 6"

(88.9 x 127 mm or

102 x 152 mm)

Group & Wide (HDTV)

31/2x 6" or 4 x 7"

(88.9 x 152 mm or

102 x 178 mm)

Panoramic

31/2x 10" to 4 x 111/2"

(88.9 x 254 mm to

102 x 292.7 mm)

Using the Focus Lock

This camera automatically focuses on whatever is within the auto-focus circle of the

viewfinder eyepiece (15). To get a sharp photograph, make sure the auto-focus circle

is on your main subject. If you want to take a picture with the subject positioned

outside of the auto-focus circle, use the focus lock as follows:

1. Place the auto-focus circle (f) on the subject that you want focused in the picture.

2. Partially depress and hold the shutter button (1) until the focus/flash lamp (16)

glows green to lock in the focus position.

3. While still depressing the shutter button, move the camera until your subject is

where you want it within the viewfinder.

4. Press the shutter button completely down to take the picture.

Special Focusing Situations

Some subjects or scenes, such as those described below, are difficult for the auto-

focus system to detect correctly; even though the focus lamp may glow green, the

focus/exposure may not be correct. To insure proper focus in the following situations,

first lock the focus on another object at the same distance from you as your main

subject, then recompose your picture and press the shutter button.

• Subject is near a very bright area or object such as a table lamp(s).

• A very bright- or low-contrast area fills the center of the auto-focus circle of the

viewfinder.
