Kobalt 10011 Manual de usuario
1
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m - 8 p.m., EST,
Monday - Sunday.
ATTACH YOUR RECEIPT HERE
ITEM #2462438
MODEL #10011
9-DRAWER
MOBILE
WORKBENCH
Español p. 12
KOBALT™ is a registered trademark
of LF, LLC. All rights reserved.
VR20060
2
PRODUCT SPECIFICATIONS
TABLE OF CONTENTS
COMPONENTS SPECIFICATIONS
Maximum drawer capacity
Maximum wood top capacity
Maximum total capacity
Maximum output of power strip
USB Current
100 lbs.
100 lbs.
1200 lbs.
1875 watts
5V DC 2.1A
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................4
Safety Information............................................................................................................................5
Preparation ....................................................................................................................................6
Assembly Instructions......................................................................................................................7
Operating Instructions ....................................................................................................................9
Care and Maintenance ..................................................................................................................10
Warranty .......................................................................................................................................10
Replacement Parts List ................................................................................................................11
PACKAGE CONTENTS
3
A
B
C
D
E
A
B
C
D
E
1
2
1
2
2
Tool chest
Cord storage bracket
Cabinet handle
Swivel caster with brake
Fixed caster
PART DESCRIPTION QUANTITY
HARDWARE CONTENTS (shown actual size)
4
M6 x 20 mm
Bolt
Qty. 8+1
M8 x 25 mm
Bolt
Qty. 16+2
Lock
(Preassembled to chest)
Qty. 1
Key
(Preassembled to lock
mechanism)
Qty. 2
Washer
Qty. 16+2
AA BB DD
EE FF
Spring
Washer
Qty. 16+2
CC
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or operate this
product. Failure to follow may result in serious injury. Save all warnings and instructions for future
reference.
5
• Do not stand or step on this product. You may fall which may cause personal injury or product
damage.
• When locking the product, close the drawers completely in order for the lock bar to work properly.
• Lock wheels when the product is not being moved
• Secure this product properly before moving it with a forklift.
• Do not attach or mount this product to a vehicle. This may cause personal injury or product
damage.
• Do not exceed the maximum drawer weight, wood top or total product weight, including contents.
Always balance the loads to avoid tipping. Place the heavier weights on the bottom drawers when
possible.
• Be careful when opening more than one drawer. The product may become unstable and tip,
which may also cause personal injury or product damage.
• Keep the product on level surfaces. The product may become unstable and tip if stored or moved
on an unlevel surface, which may cause personal injury or product damage.
• Secure all items and lock all drawers before rolling this product. Only roll the product short
distances by using the handle provided.
• Two people are needed to safely move this unit.
• Do not store liquids in the unit unless they are secured in an approved container.
• Keep children and bystanders away while loading, unloading, and moving the product.
• Always use common sense and be cautious when using this product. Do not modify this product
in any way.
• Follow all below information for extension cord
Do not insert extension cord through hole without grommet in place.
Only use a three-wire extension cord with all three prongs intact. Never remove the round
grounding prong.
Extension cord must be connected to a 125Volt GFCI protected outlet with proper ground. If GFCI
outlet is not available, use an extension cord with GFCI protection built in.
Check the insulation and plugs of extension cord before using. Do NOT use cord if it is worn or
damaged.
Do not overload extension cord.
Remove extension cord from the hole before moving or transporting storage chest.
Do not connect extension cord to outlet that also supplies critical safety equipment with power.
Make sure the power supply cord is unplugged before any servicing or cleaning.
CAUTION
WARNING
SAFETY INFORMATION
6
• Follow all below information to avoid electrical shock hazard
Do not plug cord into outlet with wet hands.
Do not use this tool chest near a bathtub, a shower, or a swimming pool.
Chest plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earth (grounded) chest power strips.
Unmodified plugs and matching outlets will reduce the risk of electric shock.
Avoid body contact with earthed or grounded surfaces. There is an increased risk of
electric shock if your body is earthed or grounded
• Refer all below information for FCC rules
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 20 minutes (does not include unpacking time)
Tools Required for Assembly (included): 10 mm Wrench
Tools Required for Assembly (not included): Adjustable wrench
PREPARATION
ASSEMBLY INSTRUCTIONS
7
Hardware Used
AA x 4
M6 x 20 mm Bolt
AA x 4
M6 x 20 mm Bolt
A
A
B
1. Attach the cabinet handle (C) to the
tool chest (A) using M6 x 20 mm bolts
(AA) and tighten with supplied 10mm
wrench.
Note: The cabinet handle (C) can be
attached to either side of the tool chest (A),
but must match the end where the swivel
casters with brake (D) will be installed. The
holes in tool chest (A) are tapped and do
not require nuts.
Hardware Used
2. Attach the cord storage brackets (B) to
the tool chest (A) holes with two
M6 x 20 mm bolts (AA) per bracket,
and tighten with supplied 10mm
wrench.
Note: Orient the brackets with one pointed left
and the other pointed right so that the power
outlet cord can be wrapped around the
brackets for storage.
1
2
AA
AA
C
AA
AC
AA
AB
ASSEMBLY INSTRUCTIONS
8
Hardware Used
3. Ensure all cabinet drawers are securely
locked into place using the lock (EE)
and key (FF) on the tool chest (A). Lay
the tool chest (A) on its back using the
cardboard package materials to protect
the finish. Mount the two swivel casters
with brake (D) to the tool chest (A)
using M8 x 25 mm bolts (BB), spring
washer (CC) and washer (DD). Repeat
this process for the fixed casters (E) on
the opposite side of the tool chest (A).
Return the tool chest (A) to its upright
position.
BB x 16
M8 x 25 mm Bolt DD x 16
Washer
CC x 16
Spring Washer
Note: Two people may be required to
complete this installation. The swivel casters
with brake (D) must be installed on the end of
the tool chest (A) with the cabinet handle (C).
Do not over tighten the screws.
3D
E
CC
BB
DD
D
A
9
OPERATING INSTRUCTIONS
1. Using the caster brakes
To lock the swivel casters, step
down on the levers marked with
ON. To unlock casters, push
down on the levers marked with
OFF.
Note: Be sure to lock both casters to
prevent cabinet from rolling or swiveling.
2. Removing the drawers
Fully empty and extend the drawer.
Depending on the side, either lift or
lower the release lever on both sides
so the slides can ride over the stops.
Pull the drawer outward until it is
released from the slides.
3. Re-inserting the drawers
Pull the slides and slide carrier out
until fully extended. Hold the slide on
the tool chest (A) while aligning it
with the slide on the drawer. Slightly
insert one side and repeat for the
other side. Slowly push the drawer
until it is fully closed to engage the
slide. Open and close the drawer to
verify proper operation.
1
2
3
OFF
ON
A
10
CARE AND MAINTENANCE
3-YEAR HASSLE-FREE WARRANTY
• Keep your chest in good repair by adopting a regular maintenance program.
• The use of drawer liners(included) is recommended to protect the finish inside the drawers and
make the drawers easier to clean.
• Grease the casters annually using high quality bearing grease.
• Lubricate the slides semi-annually with general purpose grease or equivalent.
• Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and
water.
• Remove grease and oil with a standard nonflammable cleaning fluid.
For 3 years from the date of purchase, this product is warranted for the original purchaser to
be free from defects in material and workmanship. This guarantee does not cover damage
due to abuse, normal wear, improper maintenance, neglect, unauthorized repair/alteration, or
expendable parts and accessories expected to become unusable after a reasonable period
of use.
If you think your product meets the above guarantee criteria, please call 1-888-3KOBALT, 8
a.m. – 8 p.m., EST, Monday – Sunday, or return the item to the place of purchase with a copy
of the original sales receipt. The distributor will, at its option, repair or replace the product.
This warranty gives you specific legal rights, and you may also have other rights that vary
from state to state.
