Installation and Operation Guide
KMD-5220
Input Module
For use with KMD-5210
883-019-05C
KMC Controls
Revision C2
Important notices ©2013, KMC Controls, Inc.
WinControl, NetSensor, and the KMC logo are registered trademarks of KMC
Controls, Inc.
TotalControl, BACstage, and FullBAC are trademarks of KMC Controls, Inc.
All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any
form by any means without the written permission of KMC Controls, Inc.
Printed in U.S.A.
Disclaimer The material in this manual is for information purposes only. The contents and
the product it describes are subject to change without notice. KMC Controls, Inc.
makes no representations or warranties with respect to this manual. In no event
shall KMC Controls, Inc. be liable for any damages, direct or incidental, arising
out of or related to the use of this manual.
KMC Controls
P. O . B o x 4 9 7
19476 Industrial Drive
New Paris, IN 46553
U.S.A.
TEL: 1.574.831.5250
FAX: 1.574.831.5252
E-mail: [email protected]
KMD–5220 Installation and Operation
Revision C 3
Contents
Section 1
Introduction
Specifications ........................................................................................................................ 5
Accessories ............................................................................................................................ 7
Safety considerations ..........................................................................................................8
Section 2
Installation
Mounting .............................................................................................................................. 9
Planning for input modules ............................................................................................... 9
Module installation ........................................................................................................... 10
Connecting inputs ............................................................................................................. 11
Section 3
Operation
Status LED .......................................................................................................................... 13
Auxiliary power fuse ........................................................................................................ 14
Power On/Off .................................................................................................................... 14
Maintenance ....................................................................................................................... 14
KMC Controls
Revision C4
Revision C 5
SECTION 1
Introduction
This section provides an introduction to the KMD-5220 Input
Module. You will also find Safety Considerations included in this
section. Review this material in its entirety before installing or
operating the module.
The KMD-5220 Input Module is an auxiliary device for the KMD-5210 LAN
Controller. The Input Module takes up to 16 separate inputs and processes the
information for input to the LAN Controller. The module can process active,
passive, current loop or pulse inputs.
The module also provides a fused, auxiliary power terminals for connecting up
to 6 external transducers.
The KMD-5220 Input Module is designed to accept digital or analog inputs from
active and passive sensor and control devices and process those inputs for use
by the KMD-5210 LAN Controller.
Specifications Input
Universal inputs 16
Key features Each input software selectable for analog or digital
signals. Standard and custom units of measure.
Pull-up resistors for switch contacts and other
unpowered equipment.
Connector Removable screw terminal block, wire size
14–22 AWG
Pull–up resistors Selected by moveable jumper for 1KΩ, 10KΩ
4-20mA or none.
Input impedance 1KΩor 10KΩfor 1KΩor 10KΩpullup
250Ωfor 4–20 mA
100KΩwithout jumper
Overvoltage protection 24 volts AC, continuous
Input range 0–5 volts DC
Weight 16 ounces (454 grams)
Indicators Status LED flashes when card is accessed
Ambient Limits
Operating 0 to 120°F (–18 to 49°C)
Shipping –40 to 140°F (–40 to 60°C)
Humidity 0–95% RH, non-condensing
KMC Controls
Revision C
Introduction
Specifications
6
Regulatory UL 916 Energy Management Equipment listed
CE compliant
FCC Class B, Part 15, Subpart B
SASO PCP Registration KSA R-103263
Dimensions
Table 1-1 Dimensions
A B C D E F Height (not shown)
4.50 in. 9.00 in. 4.00 in. 0.25 in. 6.00 in. 1.50 in. 0.98 in.
114 mm 229 mm 102 mm 6 mm 152 mm 38 mm 25 mm
A
B
C
E
D
F
KMD–5220 Installation and Operation
Revision C
Introduction
Accessories
7
Accessories
Ribbon cables
KMD-5660 6 inch (15 cm) ribbon cable
KMD-5668 9 inch (23 cm) ribbon cable
KMD-5661 14 inch (36 cm) ribbon cable
KMD-5662 19 inch (48 cm) ribbon cable
KMD-5663 24 inch (61 cm) ribbon cable
KMC Controls
Revision C
Introduction
Safety considerations
8
Safety
considerations KMC Controls assumes the responsibility for providing you a safe product and
safety guidelines during its use. Safety means protection to all individuals who
install, operate, and service the equipment as well as protection of the
equipment itself. To promote safety, we use hazard alert labeling in this manual.
Follow the associated guidelines to avoid hazards.
Danger
Danger represents the most severe hazard alert. Bodily harm or death will
occur if danger guidelines are not followed.
Warning
Warning represents hazards that could result in severe injury or death.
Caution
Caution indicates potential personal injury or equipment or property damage
if instructions are not followed.
Note
Notes provide additional information that is important.
Detail
Provides programing tips and shortcuts that may save time.
KMD–5220 Installation and Operation
Revision C
Installation
Mounting
9
SECTION 2
Installation
This section provides important instructions and guidelines for
installing the KMD-5220 Input Module. Carefully review this
information before installing a KMD-5220 module.
Mounting Mount KMD-5220 input modules and the KMD-5210 to which they are
connected inside of a metal enclosure. KMC Controls recommends using a UL-
approved Enclosed Energy Management Equipment Panel such as a KMC
model HCO–1034, HCO–1035 or HCO–1036. Use the two mounting holes on
each side of the module to fasten it securely to a flat surface with #6 or #8
hardware. See Dimensions on page 6 for mounting hole locations and
dimensions. To maintain RF emissions specifications, use either shielded
connecting cables or enclose all cables in conduit.
Planning for
input modules To connect inputs devices to a KMD-5210 controller, use one or more KMD-5220
input modules. The KMD-5210 controller includes eight universal I/O ports for
up to eight KMD-5220 input modules, eight KMD-5221 output modules or any
combination of up to eight modules.
Each module connects to the controller using a flat ribbon cable. Connect the
first KMD-5220 input module to connector I/O Card 1; continue adding input
modules from left to right.
Illustration 2-1 Input module connections
KMC Controls
Revision C
Installation
Module installation
10
Module
installation 1. Position and mount the modules near the KMD-5210 to which it will
connect. Input modules connect at position I/O Card #1.
2. Connect the ribbon cable to the KMD-5210 LAN Controller. Estimate the
required cable length and select from one of the cables from KMC Controls.
See Ribbon cables on page 7 in the Accessories section.
Note
Observe the orientation of the cable header. If the pin 1 edge is reversed, the
controller will not communicate with the module.
3. Connect the other end of the ribbon cable to the input module. You may
find it necessary to fold the cable to properly route it to the module.
To accommodate turns, fold the cable gently to change direction. To make a fold,
overlay the cable at a right angle and press gently until the cable holds the fold
as shown in Illustration 2-3.
Caution
Do not crimp the cable in a tight fold. This may result in separation of cable
strands and result in unreliable operation of the module.
4. Connect input devices to the modules.
Illustration 2-2 Ribbon cable orientation
Illustration 2-3 Ribbon cable fold
Pin 1 edge
(Red)
I/O port
connection Input/Output card
connection
Fold gently
Pin 1 edge
(Red) Fold back
