KDA AMPLIFIERS

DSP MENU USER GUIDE

TABLE OF CONTENTS

SECTION 1: ACCESSING THE DSP MENU

Via Network Router (Recommended) 3

Via Direct Connection 4

Via Smartphone or Tablet 5

SECTION 2: DSP MENU PAGES

Home Page 6

General Page 8

Input Page 9

EQ Page 10

Output Page 11

SECTION 3: ADDITIONAL RESOURCES

Product Information 12

KDA AMPLIFIERS – DSP MENU USER GUIDE2

SECTION 1: ACCESSING THE DSP MENU

KDA AMPLIFIERS – DSP MENU USER GUIDE

VIA DIRECT CONNECTION

1. Connect a crossover cable (required) from the ethernet port on the KDA amplifier totheethernet port on your computer.

2. Open a web browseron yourMacorPC. Chrome orFirefox are recommended.

3. Enter the model name of the amplifier in thewebbrowserin either of the following formats:

http://kda500

http://kda1000

4. Hit enter. The Klipsch KDA DSP Menu will open in the browser window.

SECTION 1: ACCESSING THE DSP MENU

KDA AMPLIFIERS – DSP MENU USER GUIDE

VIA SMARTPHONE OR TABLET

1. Connect an ethernet cable from the ethernet port ontheKDA amplifier to anethernet port on the wireless router in DHCP mode. This is usually the default

router setting,butconsult yourrouter’s user manual to confirm this setting.

2. Connect your smartphone or tablet tothe same router via Wi-Fi.

3. Using your router’s set upsoftware oran IP scanner(Fing IP Scanner app is recommended foriOS orAndroid and Advanced IP Scanner is recommended for

Windows devices) toidentify the IP address of the KDA amplifier.

4. Open a web browseron yourdevice.SafariorChrome are recommended. Enter the IPaddress of theKDA amplifier into the browser menu. Hit Ent e r.

5. The Klipsch KDA DSP Menu will open in the browser window.

SECTION 2: DSP MENU PAGES

KDA AMPLIFIERS – DSP MENU USER GUIDE

OUTPUT LEVEL

We recommend settingthese to

unity gain (0dB), as most

volume levels will be controlled

at the source component.

OUTPUT LEVEL METERS

Indicates outputclip level.

SECTION 2: DSP MENU PAGES

KDA AMPLIFIERS – DSP MENU USER GUIDE7

The following pages are

password protected.

USERNAME:

admin

PASSWORD:

admin

This can be changed on the GENERAL

settings page.

KDA AMPLIFIERS – DSP MENU USER GUIDE

SECTION 2: DSP MENU PAGES

“FLASH AMP LED” COMMAND

When activated,this button will flash

the front LEDs on the amplifier youare

connected to.This is helpfulin

situations when multiple amplifiers are

racked.

POWER CONFIGURATION

POWER MODE:

Always On -Stays onuntil hardpower

switch is turned off.

External Trigger-Senses input trigger

from 12V trigger input on back panel

Auto On -Amplifier auto detects signal

from input source

AUTO ON THRESHOLD: Sets sensitivity

to input signalfor auto turn-on.

TURN ON DELAY:Delays turn onfrom

initial signal detection -useful for

specific power sequencing

AMPLIFIER NAME

Customize amplifier name.

KDA AMPLIFIERS – DSP MENU USER GUIDE

SECTION 2: DSP MENU PAGES

OUTPUT CHANNELNAME

User customizable,

auto-populates to other menupages.

INPUT / SOURCE SELECT

Selects whichinput should beused with the

output channel. 1+2 or 2+3 represent stereo

channels summed to mono ouput.

VOLUME SETTINGS

VOLUME OFFSET:

Input volume trim -useful to balance volume

variancesbetweendifferent inputs source

types.

TURN ON VOLUME:

Dictatesthe volume levelat which the

channelwillpoweron aftera powercycle.

MAXIMUM VOLUME:

Dictatesmaximumvolumelevel -useful in

areas where loud volume is not preferred..

KDA AMPLIFIERS – DSP MENU USER GUIDE

SECTION 2: DSP MENU PAGES

OUTPUT CHANNEL

Select whichoutput channel toedit.

SHELVING

Specialized EQ allows userto boost orcut

high or low frequencies with ease.

CROSSOVER

Set High Or LowPass slope and frequency.

PARAMETRIC EQ

5-band fine-tuning EQallows user toadjust

frequency, filter width (Q), and boost/cut.

*Digital Domain –settings are completely

bypassed when in “neutral mode”.

PHASE INVERT

Invert outputsignalphase (0°/ 180°).
