COOKTOP, BURNER AND GRATE PARTS

For Models: KGCS105GBL2, KGCS105GWH2, KGCS105GAL2, KGCS105GBT2, KGCS105GSS2

(Black) (White) (Almond) (Biscuit) (Stainless Steel)

12−99 Litho in U.S.A. (RS) Part No.8177463

30" GAS COOKTOP

COOKTOP, BURNER AND GRATE PARTS

For Models: KGCS105GBL2, KGCS105GWH2, KGCS105GAL2, KGCS105GBT2, KGCS105GSS2

(Black) (White) (Almond) (Biscuit) (Stainless Steel)

8177463

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Cooktop

3191246 White

3191245 Black

3191247 Almond

3191294 Biscuit

3191248 Stainless Steel

3193090 Seal, Cooktop

2 Collar, Knob

3192165 White

3192164 Black

3192166 Almond

3192167 Biscuit

4 Nameplate

3191516 White

3191514 Black

3191517 Almond

3191920 Biscuit

6 Cap, (RF)

3191729 White

3191728 Black

3191730 Biscuit

3192486 Use w/Stainless

Steel Model

7 Cap, (LR)

3191732 White

3191731 Black

3191733 Biscuit

3192487 Use w/Stainless

Steel Model

8 Cap, (RR)

3191735 White

3191734 Black

3191736 Biscuit

3192488 Use w/Stainless

Steel Model

9 Cap, (LF)

3191738 White

3191737 Black

3191739 Biscuit

3192489 Use w/Stainless

Steel Model

10 Grate, Burner

3191486 White

3191485 Black

3191487 Biscuit

3192485 Use w/Stainless

Steel Model

11 Grate, Filler

3191278 White

3191277 Black

3191279 Biscuit

3192484 Use w/Stainless

Steel Model

12 Knob, Control (4)

3191923 White

3191922 Black

3191924 Almond

3191925 Biscuit

13 9754215 Ignitor

14 Orifice

3192528 Right Front

3192523 Left Rear

3192524 Right Rear

3192525 Left Front

15 Holder, Orifice

9754182 Right Front

9754186 Left Rear

9754187 Right Rear

9754188 Left Front

16 Head, Burner

8273216 Right Front

8273215 Left Rear

8273214 Right Rear

9754181 Left Front

18 4449809 Screw

20 3368921 Screw

21 3192720 Pad, Grate

BURNER BOX, GAS VALVES, AND SWITCHES

For Models: KGCS105GBL2, KGCS105GWH2, KGCS105GAL2, KGCS105GBT2, KGCS105GSS2

(Black) (White) (Almond) (Biscuit) (Stainless Steel)

8177463

BURNER BOX, GAS VALVES, AND SWITCHES

PARTS NOT ILLUSTRATED

For Models: KGCS105GBL2, KGCS105GWH2, KGCS105GAL2, KGCS105GBT2, KGCS105GSS2

(Black) (White) (Almond) (Biscuit) (Stainless Steel)

8177463

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 3191557 Rail, Burner

2 3191315 Pipe, Manifold

3 3191292 Valve, Gas Burner

Burner, (RF)

4 3191387 Seal, Shaft

5 3191293 Valve, Gas Burner

(RR & LR)

6 3192157 Valve, Gas

Burner (LF)

7 3192083 Rail, Center

8 307630 Bolt, Gas Valve

9 3177991 Screw

10 3192491 Bracket, Mainfold

11 3196160 Screw

12 3191334 Harness & Switches

14 3191324 Tubing, Gas

Burner (RF)

15 3191326 Tubing, Gas

Burner (LF)

16 3191325 Tubing, Gas

Burner (RR)

17 3191327 Tubing, Gas

Burner (LR)

18 3191462 Shield, Heat (2)

21 3177120 Regulator, Pressure

22 4455261 Burner Box

27 8053421 Module Spark

28 4455260 Bracket, Spark

Module

LITERATURE PARTS

LIT3191827

Installation

Instructions

LIT3193071

Use & Care Guide

LIT3192098

Wiring Diagram

LIT3191638

Tips−Safer Cooking

LIT3192742

LP Conversion

Instructions

Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

3192231 Cord, Power

4173634 Bushing

3179557 Screw

3183401 Bracket, Mounting

4167077 Tinnerman Nut

Miscellaneous

3188310 Hardware, Mounting

3192741 Conversion Kit

Natural Gas To L.P.

WIRING HARNESS PARTS

3192229 Harness,

Ignitor 15" (2)

3192230 Harness,

Ignitor 28" (2)
