COOKTOP PARTS

For Models: KECD866RSS05

(Stainless)

11−08 Litho in U.S.A. (amd)(bay) Part No. W10240141 Rev. A

36" ELECTRIC

BUILT−IN

DOWNDRAFT COOKTOP

COOKTOP PARTS

For Models: KECD866RSS05

(Stainless)

W10240141

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8286240 Installation

Instructions

8286428 Wiring Diagram

W10162163

Use & Care Guide

Safe Cooking Tips

9762761 English

W10065852

French

2 8286949 Cooktop, Glass &

Bracket Assembly

3 3196537 Screw

4 3177991 Screw

5 Element, Surface

8523698 LR 1200W

8285846 LF 900/1800/2500W

8285842 RR 1000/2000W

8523697 RF 1500W

6 3191387 Seal, Switch (4)

7 8285810 Box, Burner

8 3183956 Seal, Switch Cover

W10169758

Shield, Vent

10 3190656 Drip Bowl

11 4455354 Bracket, Mounting

Control

12 311865 Screw

13 4456836 Switch, Speed

Control

14 Switch, Infinite

3191049 LR & RF

8286070 LF

4456027 RR

15 8285469 Seal, Infinite

Switch

16 3192439 Seal, Limiter (4)

17 Rail, Element

8285933 Right

8286054 Left

8286096BL

Knob, Control

8286097BL

Knob, Blower

Switch

20 8285875 Grille, Air

21 3192530 Filter, Grease

W10142242

Frame, Cooktop

23 9759094 Spring,

Locator (8)

W10137040

Gasket, Vent

Shield

25 8286055 Light, Hot Surface

Indicator

26 3193094 Plate, Cover

BLOWER UNIT PARTS

For Models: KECD866RSS05

(Stainless)

W10240141

Illus. Part

No. No. DESCRIPTION

W10169759

Bracket, Vent

Shield

2 3192403 Bracket, Blower

Mounting

3 3196537 Screw

4 9760484 Ring, Inlet

5 9760485 Screen, Inlet

6 9760483 Adapter, Vent

W10109930

Blower Motor Asm.

(Includes Fan Asm)

OPTIONAL PARTS

For Models: KECD866RSS05

(Stainless)

W10240141

Illus. Part

No. No. DESCRIPTION

FOLLOWING PARTS

NOT ILLUSTRATED

Miscellaneous

4455917 Bracket, Support

3400093 Screw

8286642 Tape, Form

FOLLOWING PARTS

NOT ILLUSTRATED

WIRING HARNESS PARTS

8286420 Harness, Wire

(Ceran Downdraft)

4456028 Jumper, Wire

4456859 Harness, Wire

(Blower/Switch)

98997 Clip

9760671 Strain Relief

8286423 Conduit, Downdraft
