COOKTOP PARTS

For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2

(Black) (White) (Almond)

5−96 Litho in U.S.A. (rmb) Part No. 885211

30" ELECTRIC

BUILT−IN

COOKTOP

COOKTOP PARTS

For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2

(Black) (White) (Almond)

885211

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 Trim Ring, Cooktop

3187744 Black

3187745 White

3187746 Almond

2 Cooktop, Glass

3188255 Black

3188256 White

3188893 Almond

4 3188101 Bracket, Switch

Mounting

6 3189165 Spring Locator (8)

246119 Screw (8)

7 Switch, Infinite

4454541 Use W/2400W

Left Rear Burner

4454540 Use W/2100W

Right Rear Burner

4454539 Use W/1400W

Right Front Burner

4454539 Use W/1200 W

Left Front Burner

8 3183956 Seal, Switch Shaft

311865 Screw

9 4454437 Light, Indicator

10 Knob, Control (4)

9750372FF

Black

9750372FW

White

9750372FT

Almond

11 3188754 Box, Burner

13 3188533 Grommet

4159456 Screw

15 3182435 Seal, Switch (4)

16 Switch, Limiter

3190248 Use W/3196428

Element

3190253 Use W/3189894

Element

3190252 Use W/3189896

Element

3190251 Use W/3189897

Element

18 3188257 Plate, Backer

19 Seal, Silicone

3185589 Small (2)

3185590 Large (2)

20 3187753 Shield, Heat

4159456 Screw

21 3188852 Seal, Silicone

22 3189753 Lamp, Hot

Surface Indicator

4168863 Screw

23 3189152 Bracket, Stiffening

4159456 Screw

25 Element, Surface

(Includes # 16)

3196428 1200W Left Front

3189894 1400W Right Front

3189896 2100W Right Rear

3189897 2400W Left Rear

29 3188844 Shield, Heat

4159456 Screw

30 3189174 Bracket

31 3188102 Shield, Heat

32 3188158 Plate, Interior

4159456 Screw

33 3189159 Plate, End

4159456 Screw

34 3189036 Plate Louver

4159456 Screw

35 3189273 Cover, Conduit

WIRING HARNESS PARTS

For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2

(Black) (White) (Almond)

885211

Illus. Part

No. No. DESCRIPTION

1 3189757 Wiring Harness

Surface Unit

2 3179589 Tie, Wire

MISCELLANEOUS PARTS

For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2

(Black) (White) (Almond)

885211

Illus. Part

No. No. DESCRIPTION

FOLLOWING PARTS

NOT ILLUSTRATED

LITERATURE PARTS

LIT3189330

Installation

Instructions

3190372 Wiring Diagram

LIT4454475

Use & Care Guide

Miscellaneous

3172515 Hardware, Mounting

FOLLOWING PARTS

NOT ILLUSTRATED

SPLICING WIRES−−25FT.

LENGTH

242828 Wire, Black

12 Ga. 150 C

242820 Wire, Black

14 Ga. 150 C

242822 Wire, Blue

14 Ga. 150 C

242830 Wire, Brown

14 Ga. 200 C

242823 Wire, Green

14 Ga. 150 C

242824 Wire, Orange

14 Ga. 150 C

242829 Wire, Red

12 Ga. 150 C

242825 Wire, Red

14 Ga. 150 C

242831 Wire, Red

14 Ga. 200 C

242826 Wire, White

14 Ga. 150 C

242827 Wire, Yellow

14 Ga. 150 C

242832 Wire, Yellow

14 Ga. 200 C

ACCESSORY PARTS

3184477 Cleaner, Glass

3183488 Scraper, Glass
