KitchenAid KSBC2F1 Series Manual de usuario

KSBC2F1XX

Cord cleat

(not shown)

PARTS AND FEATURES

PARTS AND ACCESSORIES

Ingredient

cap with

measuring

cup

Flex Edge

tamper

Lid

Talon™

blade

Base

On/off

switch

(not shown)

Start/Stop toggle switch

Pulse toggle switch

Control

dial

Open handle

for easy

stackability

Removable blender

jar pad

Blender jar

Status indicator light

Power cord

socket and

removable

power cord

(not shown)

Power cord

socket and

removable

Motor horsepower for the blender motor was measured using a dynamometer, a machine

that laboratories routinely use to measure the mechanical power of motors. Our 3.5 peak

horsepower (HP) motor reference reects the horsepower output of the motor itself and

not the Blender’s horsepower output in the blender jar. As with any blender, the power

output in the blender jar is not the same as the horsepower of the motor itself. This

motor delivers 2.45 peak HP in the blender jar, enabling your Blender to deliver robust

power for all your recipes.

ENGLISH

COMMERCIAL BLENDER SAFETY | 3

COMMERCIAL BLENDER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put Blender in water

or other liquid.

3. Close supervision is necessary when any appliance is used by or

near children.

4. Unplug from outlet when not in use, before putting on or taking off parts,

and before cleaning.

5. Avoid contact with moving parts.

6. Do not operate the Blender with a damaged cord or plug or after appliance

malfunctions, or is dropped or damaged in any manner. Return appliance

to the nearest Authorized Service Center for examination, repair, or electrical

or mechanical adjustment. If the supply cord or plug is damaged, it must be

replaced by a special cord or assembly available from the manufacturer or

service agent.

7. Do not use outdoors.

8. Do not let cord hang over edge of table or counter.

4 | COMMERCIAL BLENDER SAFETY

COMMERCIAL BLENDER SAFETY

9. Keep hands and utensils out of container while blending to reduce the risk

of severe injury to persons or damage to the Blender. A spatula or scraper

other than the provided Flex Edge tamper may be used, but must be used

only when the Blender is not running.

10. Blades are sharp. Handle carefully.

11. The use of attachments, including canning blender jars, not recommended

by KitchenAid may cause a risk of injury to persons.

12. Do not use appliance for other than intended use.

13. Always operate Blender with cover in place.

14. When blending hot liquids or ingredients, ingredient-measuring cup should

remain in place over the lid opening. Always start on lowest speed and

slowly ramp to desired speed when blending hot liquids or ingredients.

SAVE THESE INSTRUCTIONS

This product is designed for commercial use.

ELECTRICAL REQUIREMENTS

Voltage: 120 V

Frequency: 60 HZ

Amps: 15.0 A

NOTE: If the plug does not fit in the

outlet, contact a qualified electrician. Do

not modify the plug in any way. Do not

use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualied

electrician or serviceman install an outlet

near the appliance.

ENGLISH

USING THE COMMERCIAL BLENDER | 5

USING THE COMMERCIAL BLENDER

The Blender has a preset recipe program: Coulis Cycle. It also features Variable Speeds

and Pulse functions that allow you to customize your blending for any recipe you make.

To clean the Blender: Quick pulses of power and high speeds work to clean the blender

jar with just 2 cups of water and a drop of dish soap.

BLENDER FUNCTION GUIDE

SETTING DESCRIPTION BLENDING TIME

(IN MIN:SEC)

COULIS

Blends ﬂuid gels into a smooth mixture. A series of pulses

and speeds run before the unit gradually ramps up to full

power before it ﬁnishes with a slow speed to allow air to

escape from the ﬂuid. For best results, cut or crumble gel

into 1/2'' cubes before blending. Limit gel to 500-1000

grams. Do not exceed 1000 grams in the jar. You may need

to use the tamper for thicker ﬂuid gels.

< 3 minutes

VARIABLE

SPEEDS

When the Start/Stop switch is pressed, the Blender will run

continuously until the Start/Stop switch is pressed again,

or after 6 minutes have elapse.

N/A

:30 When the :30 time is selected, the Blender will gradually

ramp up to full power and run for 30 seconds total. :30

:45 When the :45 time is selected, the Blender will gradually

ramp up to full power and run for 45 seconds total. :45

:60 When the :60 time is selected, the Blender will gradually

ramp up to full power and run for 60 seconds total. :60

6 | USING THE COMMERCIAL BLENDER

USING THE COMMERCIAL BLENDER

Before ﬁrst use

Before using your Blender for the rst

time, wipe the blender base with a warm

damp cloth, then wipe clean with a damp

cloth. Dry with a soft cloth. Wash the

blender jar, lid, and ingredient cup in warm,

sudsy water (see the “Care and cleaning”

section). Rinse parts and wipe dry.

Before using the Blender, be sure the

countertop beneath the Blender and

surrounding areas are dry and clean.

Be sure the power switch on the back

of the blender base is in the OFF

(O) position and the cord is also fully

plugged into the back of the Blender.

Then, plug the Blender into

a grounded 3 prong outlet.

The main power switch is on the

back of the blender base. Flip the

POWER switch to the ON (I) position.

The status indicator light above the

Start toggle button will begin to

flash, indicating that the Blender is in

Standby mode. The Blender is now

ready to operate.

PREPARING THE COMMERCIAL BLENDER FOR USE

NOTE: The cord cleat is not to be used

as a handle; the cord cleat is designed to

wrap the power cord around it for

storage only.

ENGLISH

USING THE COMMERCIAL BLENDER | 7

USING THE COMMERCIAL BLENDER

Flip the START/STOP toggle switch

up or down to begin operation of the

Blender. The status indicator light will

now be solid.

Turn the control dial to your desired

speed, time, or program. See the

“Blender function guide” for more

information.

ASSEMBLING AND RUNNING THE COMMERCIAL BLENDER

NOTE: To avoid spills, do not fill blender

jar past the top-most measurement mark,

especially when blending liquids.

Put the items to blend into the

blender jar. Add liquids first, then

soft foods, then leafy greens, and

ice or frozen items last.

Make sure that the lid is fully secured

on the blender jar; next, place the

blender jar on the base, making sure

that it is fully aligned on the jar pad.

NOTE: If you select a preprogrammed

cycle, you will need to ip the START/

STOP toggle to begin operation.

8 | USING THE COMMERCIAL BLENDER

Use the Flex Edge tamper accessory

as needed for optimal blending

performance. Remove the ingredient-

measuring cap only, and leave the

lid in place. Stir or press contents

down towards the blade. When you

are finished, replace the ingredient-

measuring cap in the blender jar lid

before resuming blending.

If desired, use the Pulse function for

a momentary boost of speed while

blending on the variable speed

settings.

Press and hold the PULSE toggle

switch up for a faster pulse, or down

for a slower pulse.

After blending, flip the START/STOP

toggle switch up or down. Allow the

Blender to come to a complete stop

before removing the lid and pouring

your blended ingredients.

If the Blender remains in standby

mode for 28 minutes with no

activity, the Blender will enter sleep

mode. To get out of sleep mode,

press the START/STOP switch once

to bring into standby mode. Then,

press START/STOP once more to

start the Blender.

USING THE COMMERCIAL BLENDER

NOTE: The Pulse function may also

be used on its own as a separate

blending function while the Blender

is in standby mode.

ENGLISH

CARE AND CLEANING | 9

To clean the blender base and cord:

Unplug the Blender before cleaning.

Wipe the base and the cord with a

warm, damp cloth; wipe clean with a

damp cloth, and dry with a soft cloth.

Make sure to clean the blender jar,

lid, and ingredient cap after each

use. Remove any remaining contents

from the blender jar. Fill the blender

jar with 2 cups of warm water and

1 drop of liquid detergent. Place the

lid on the blender jar, and make sure

the blender jar is fully in place on the

blender base.

CARE AND CLEANING

CLEANING THE BLENDER AND ACCESSORIES

Clean the Blender thoroughly after every use.

NOTE: To avoid damaging the Blender, do not immerse the blender base

or cord in water. To avoid scratching the Blender, do not use abrasive cleansers

or scouring pads.

10 | CARE AND CLEANING

CARE AND CLEANING

SANITIZING THE BLENDER

1. Remove any remaining contents from the blender jar.

2. Prepare a 200 ppm sodium hypochlorite solution* using 1.75 L of hot water in the

blender jar. Place the lid on the blender jar, and make sure the blender jar is fully in

place on the blender base.

3. Run the Blender on the High Speed setting for 35 seconds. Flip the START/STOP

toggle switch up or down to start the Blender.

4. Turn off the Blender and let the sanitizing mix sit in the blender jar for an

additional 2 minutes.

5. Pour out the sanitizing solution mix. Do not rinse the blender jar.

6. Place the lid on the blender jar. Make sure the empty blender jar is fully in place on

the blender base. Run the empty Blender for an additional 10 seconds. Do not rinse

the jar after sanitizing.

7. Allow the blender jar to air dry.

*To prepare a 200 ppm sodium hypochlorite solution: use 6.67 mL household bleach (with a 5.25% sodium

hypochlorite concentration) in 1.75 L of hot water.

Rotate the control dial to 30 seconds.

Flip the START/STOP toggle switch

up or down. When the timer finishes,

pour out the soapy water, and rinse

the blender jar with warm water.

Wash the blender jar, jar pad, lid, Flex

Edge tamper, and ingredient cap by

hand with a damp cloth and warm

soapy water; rinse with warm water

and dry with a soft cloth.

Tabla de contenidos

Idiomas:

Otros manuales de Licuadora de KitchenAid

KitchenAid

KitchenAid 5KSB13 A Series Manual de usuario

KitchenAid

KitchenAid KSB1575 Manual de usuario

KitchenAid

KitchenAid KSBR200 Manual de usuario

KitchenAid

KitchenAid 5KSB6061 Manual de usuario

KitchenAid

KitchenAid KSB540 Manual de usuario

KitchenAid

KitchenAid 7KSB40 Series Manual de usuario

KitchenAid

KitchenAid 5KHB3581ECA Manual de usuario

KitchenAid

KitchenAid K150 Series Manual de usuario

KitchenAid

KitchenAid 5KSB7068 Manual de usuario

KitchenAid

KitchenAid KSB585CR Guía rápida

KitchenAid

KitchenAid 5KSB1585 Manual de usuario

KitchenAid

KitchenAid 5KHBV53Z Manual de usuario

KitchenAid

KitchenAid KSB60 series Manual de usuario

KitchenAid

KitchenAid KFP750BW - 12 Cup Food Processor Manual de usuario

KitchenAid

KitchenAid KSB540WH0 Manual de usuario

KitchenAid

KitchenAid 5KSB1565 Guía de instalación

KitchenAid

KitchenAid 5KSB5080 Manual de usuario

KitchenAid

KitchenAid KHB1231 Manual de usuario

KitchenAid

KitchenAid KPCB348SOB1 Manual de usuario

KitchenAid

KitchenAid KSB354WH0 Manual de usuario

KitchenAid

KitchenAid KSB6060FG Manual de usuario

KitchenAid

KitchenAid KSB1575 Manual de usuario

KitchenAid

KitchenAid 5KSB40 Series Manual de usuario

KitchenAid

KitchenAid KCB148 Manual de usuario

Manuales populares de Licuadora de otras marcas

ROTOR

ROTOR 1125.201 Manual de usuario

Braun

Braun Multiquick 5 Vario series Manual de usuario

ARENDO

ARENDO MIRA 305424 Manual de usuario

CHEF-BUILT

CHEF-BUILT CCB-3500 Manual de usuario

Viconte

Viconte VC-4406 Manual de usuario

Oster

Oster BLSTAB-CB0 Manual de usuario

HOFFEN

HOFFEN MC-3005 Manual de usuario

Black & Decker

Black & Decker BLC18750DM Manual de usuario

Sunbeam

Sunbeam 4182 Manual de usuario

Bialetti

Bialetti FMX35 Manual de usuario

Black & Decker

Black & Decker BL8000 Manual de usuario

Duronic

Duronic BL530 Manual de usuario

Exquisit

Exquisit MS 3002 wes Manual de usuario

Lumme

Lumme LU-KP1891A Manual de usuario

Binatone

Binatone HB-735 Manual de usuario

Moulinex

Moulinex LM936E10 Manual de usuario

Oster

Oster VERSA Manual de instalación y operación

Ninja

Ninja NN210Q Manual de usuario
