1 Read the entire Installation Instructions prior to beginning the installation of the part.

2 Make sure the vehicle is completelycleanand dryin the area(s) the part is to be installed.

3 Ensure the vehicle is properlyprotected in the area(s) that the accessory is to be installed.

4 NEVER place toolson painted surfaces, seating surfaces, dash pad, console or floor carpet/mats.

5 Alwayswear appropriate personal protective equipment, including gloves, safety glasses, etc., whenrequired.

6 Record radio presets prior to disconnecting battery power, if needed.

7 Ensure the transportationfuse is set to "ON" before starting the install.

8 Roll down the driver's window and adjust the power seats(if applicable) prior to disconnecting batterypower, if needed.

Vehicle Model

D9062 ADUP0

Difficultystated above reflects the minimum level of

expertise required to install the accessory:

( B )

Mirror, Auto-dim with HL4 Comp.

(A) Customer

Denotes cautions to be taken to avoid

vehicle and component damage

Denotes cautions to be taken to avoid

physical injury or electronic component

damage

Language

English

11/23/2015

Basic Required Tools

Denotes important information to be

reviewed during the step

Denotes specific tools that are necessary

to complete a step

T20 Torx Driver

Ratchet

Slotted Screwdriver

T20 Torx Socket

Notes to the installer:

10mm Socket

Nylon Panel Removal

Tool

#2 Phillips Screwdriver

Torque Wrench

Side Cutters

Pliers

Tape Measure

Denotes quality processes to be checked

prior to moving to the next step

Denotes personal protective equipment (PPEs) that

may be required for a step. Examples of safety

equipment icons noted below:

Denotes warnings that may lead toserious

physical injury or vehicle damage

Part No.

Model Year

Copy OEM Logo Here (→)

2017~

D9062 ADU00

Difficulty:

Note:

Rev. Date

Accessory:

Sportage

(B) Dealer Technician

Instructional Symbols / Definitions

M10 T20

T20

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 1 of 17

Genuine Accessories

No.

Hardware Kit Contents

1 1 1 6 3

9 1 1

* Indicates extra components intentionally included in kit as spares.

Follow instructions for proper placement of each component.

Radio Presets - record customer preset frequencies if disconnecting battery power

FM10

Kit Overview

Mirror, Auto-dimming w/ HL4 & Compass

Qty

Description

Hardware Kit

Harness

A-Pillar Tether Clip

(85815 C1000 - White)

Wire Cover

AM1

AM2

FM7

Wire Ties*

Quick Ref. Guide

FM6

FM8

Installation Instruction

FM1

FM2

AM5

T-Taps*

FM5

SAT5

AM4

Hardware Total

FM4

SAT4

Foam Tape*

SAT1

SAT2

SAT3

FM9

FM3

AM3

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 2 of 17

Genuine Accessories

Wires may be solid color, or striped (tracer). The first color in the description Whendisconnecting the wires, grasp the connectors, not the wires.

indicates the base color of the wire; the second indicates the stripe.

Example: Example:

Solid color wire Striped Wire Correct

Incorrect

Connector diagrams show the harness side view, unless noted. The wire pin When locking connectors, listen for an audible "click" indicating the connectors

numbers are shown from the wire harness side, not the connector side.

are securely locked.

Example:

1. Place the T-tap on the vehicle wire 2. Using pliers, close and crimp T-tap around the vehicle wire.

** Extreme care must be takento ensure the male spade is inserted into the T-tap properly

3. Insert accessory harness wire withmale spade terminal into the opening in T-tap.

Special Instructions

Electrical Connection Procedure

Wire Appearance

Disconnecting Connectors

Connector Diagrams

Connecting Connectors

T-Tap Install Procedure

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 3 of 17

Genuine Accessories

1. With A-pill trim partially pulled away, reach behind trim panel and cut

tether clip, as shown above.

Side Cutters

WARNING: Shock Hazard! Do not touch vehicle's negative battery

terminal to vehicle's positive battery terminal. Serious injury and damage

to the vehicle may occur.

1. Ensure the correct part is being installed. Verify the part number on

the installationorders with the part number on the kit boxlabel.

2. Write down allpre-set radio stations (if applicable).

3. Disconnect and isolate vehicle's negative battery cable.

CAUTION: Ensure care is taken to prevent damage to the A-pillar trim

panel, wire harness, sunroof drain tube, and side-curtain airbag.

1. Partially remove the A-pillar trim panelby pulling the top out towards

the vehicle passenger-side, until the A-pillar tether clip catches.

Nylon Panel Removal Tool

1. Carefully pullthe front of the driver-side door sealback to allow

removal of the A-pillar trim panel

CAUTION: If needed, use a flashlight to light behind the A-pillar trim to

avoid damaging any vehicle component with the cutting too. DO NOT cut

anything other thanthe A-pillar tether clip.

Ratchet and 10mm Socket

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 4 of 17

Genuine Accessories

Pliers

1. Continue removing the A-pillar trim panelby pulling the top out toward

the passenger side of the vehicle, until remaining one (1) clip is

released.

CAUTION: Do no scratch or damage the A-pillar trim panel.

1. Using a Phillips screwdriver, remove screw as shown above.

2. Grasp the clip, and slide toward the bottom of the A-pillar trim, then pullthe

piece out of the trim panel.

1. Using pliers, pull the remaining portion of the A-pillar tether clip out of

the A-pillar, and discard.

CAUTION: Do not damage A-pillar trim panel or headliner.

WARNING: Always use a new tether clip when re-installing the

A-pillar trim panel. Failure to use a new clip may result in serious injury or

death in the event the airbag deploys.

Do not damage the A-pillar trim panel or tether clips.

#2 Phillips Screwdriver

1. Place a new tether clip in the A-pillar trim panelby aligning the slot on

the trim panel with the tether clip.

2. Slide the clip upward untilit locksin place.

3. Re-install the retaining plug and screw, removed in the previous steps.

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 5 of 17

Genuine Accessories

#2 Phillips Screwdriver

T20 Torx Driver

CAUTION: Take care to avoid damaging the mirror mount,

windshield, and headliner.

1. Using a T20 TorxDriver, loosen the screw on the mirror mount.

2. Gently pull the mirror upwards ina parallel direction to the windshield.

DO NOT pull the mirror awayfrom the windshield.

1. Remove the fuse panel cover, and set aside.

1. Reach through the fuse panel opening and push the DashSide Panel out,

by dislodging the five (5) clips.

2. Remove the DashSide Panel and set aside.

1. Open sunglass holder in the overhead console, exposing two (2)

Philips screws, and with a #2 Philips screwdriver, remove them.

2. Remove the overhead console by pulling downward starting from

the side closest to the windshield. Continue rocking side-to-side,

until the console comes free of the retaining hooks.

3. Disconnect anyelectrical connectors and place the console aside.

Nylon Panel Removal Tool

CAUTION: Do not damage headliner or overhead console.

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 6 of 17

Genuine Accessories

WARNING: Do not over-tighten the screw. Over tightening the

screw will not properly secure the mirror, and could cause the

mirror to break loose and injure the occupants inan accident.

CAUTION: Ensure the mirror harness is not pinched between

the mount and the windshield button.

1. Carefully pullharnesslead extending out from the mirror, through

the grove inthe top side of the mount.

2. Slide the new mirror over the windshield button. Hold the harness

away from the windshield when sliding the mirror over the button.

#2 Philips Screwdriver

#2 Philips Screwdriver & Nylon Panel Removal Tool

CAUTION: Do not scratch the lower dash trim panel.

Do not damage wires or connectors in the panel.

Do not break the hidden tab behind the driver's kick panel.

CAUTION: Do not scratch lower dash trim panel.

1. Torque the screw to 1.76 N-m (0.18 kgf-m, 1.3 lb-ft).

1. Using a screwdriver, remove the three (3) Philips screws from the

outside surface of the lower dash trim panel.

1. Remove one (1) Philips screw from lower right corner of lower dash

trim panel.

2. Disconnect the OBDII connector from the dash panel.

3. Using the Nylon Panel Removal Tool, release the one (1) locking tab on

the dash panel.

4. Starting at the upper right side of the panel, pullthe panel outward

releasing the clips, moving right to left.

T20 Torx Bit & Torque Wrench

Phillips Screws

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 7 of 17

Genuine Accessories

1. Wrap one (1) foam tape around the mirror harness connector, as shown.

1. Plug the 5-pin connector from the provided one (1) mirror harnessinto

the harness lead extending out from the mirror.

CAUTION: Ensure 5-pin connector is securely installed.

Nylon Panel Removal Tool

1. Begin tucking the mirror harness between the headliner and the

roof. Stop after the foam-taped harnessconnector ishidden

under the headliner.

1. Slide the provided one (1) wire cover over the mirror harness lead,

and click it into the top surface of the mirror base.

2. Extend the upper wire cover until it hooks onto the headliner.

Ensure the cover is vertical.

CAUTION: Use caution when working with the headliner to

prevent creases or damage. Make sure hands are clean.

CAUTION: Ensure cover "forks" are properly seated into mirror

and headliner.

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 8 of 17

Genuine Accessories

1. Hold the mirror harnessagainst the headliner and wrap one (1) foam

tape around the harness where it meetsthe corner of the A-pillar.

2. Wrap one (1) foam tape on the harness between the two previously

installed foam tapes.

3. Tuck the harness with the wrapped foam tape into the headliner

acrossfrom the mirror to the A-pillar.

1. Route mirror harness downthe A-pillar into the dash, toward engine

side of fuse panel.

NOTE: Ensure wire harness is routed away from the side curtain

airbag, and sunroof draintube, if equipped.

2. Secure mirror harness near the vehicle harness clips, and above the

electrical connector at the bottom of the A-pillar, with four (4) wire ties.

3. Trim the excess wire tie length.

CAUTION: Use caution when working with the headliner to prevent

creases or damage.

CAUTION: DO NOT secure to airbag inflator.

DO NOT secure to sunroof drain tube, if equipped.

Tape Measure

1. Pull mirror harness wires apart approximately 300mm (12in), as shown.

Tape Measure & Nylon Panel Removal Tool

Side Cutters

CAUTION: Ensure harness does not catchon vehicle component, or is

damaged during the routing.

CAUTION: DO NOT use a razor blade or any other sharp tool to

separate the wires. Ensure wire is not damaged during

separation.

1. Route mirror harness through dash, on the engine-side of the

junction block.

2. Route mirror harness below the junction block, pulling the 3 terminals

toward the driver's seat.

Foam Tape

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 9 of 17

Genuine Accessories

Pliers

1. Locate Connector C (38 pinconnector) onthe front side of the

junction block (furthest side from the engine).

1. Locate Pin 23 (BROWN wire) of Connector C.

1. Attach one (1) T-tap to the wire at Pin 23 (Brown wire).

Use Pliers to snap the T-tap together.

Refer to the Electrical ConnectionProcedure at the beginning of the

instructions for more details.

1. Insert male spade terminal of the mirror harness (Black w/ White wire)

into the T-tap connector (Brown wire), for switched ignitionpower.

Refer to the Electrical ConnectionProcedure at the beginning of the

instructions for more details.

CAUTION: Ensure the correct wire is identified.

NOTE: Factory wire colors are subject to change at any time.

Refer to the pin number to correctly identify the circuit.

CAUTION: Ensure that the wire is in the slot of the T-tap, and that both

halves of the T-tap are snapped together properly.

CAUTION: Ensure the male spade connector is fully inserted into the wire

tape. Check that the spade did not "miss" the female slot. Check that the

males spade is not visible on either side of the female connector.

Connector C

Pin 23

Brown

Pin 20

Pin 19

T-Tap on

Pin23

Brown

Black w/

White wire

connected

*550-0670-000*

550-0670-000 Rev. 004 Revision Date

11/23/2015

Page 10 of 17

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios para automóviles de Kia

Kia

Kia 66582ADE00 Manual de usuario

Kia

Kia C6F46 AC200 Manual de usuario

Kia

Kia Rear Seat Entertainment System Manual de usuario

Kia

Kia Sorento 2022 Manual de usuario

Kia

Kia D4211ADE00AL Manual de usuario

Kia

Kia Optima Manual de lista de piezas

Kia

Kia Bluetooth Phone System 2010 Manual de usuario

Kia

Kia F1211ADE00AL Manual de usuario

Kia

Kia E8300-4D000 Manual de usuario

Kia

Kia B2211ADE00AL Manual de usuario

Kia

Kia 3W211ADE00ME Manual de usuario

Kia

Kia Front Mudguard Kit Manual de usuario

Kia

Kia B2210ADE00AL Manual de usuario

Kia

Kia 66701ADE00 Manual de usuario

Kia

Kia F1620ADE00CP Manual de usuario

Kia

Kia E8300-4D050 Manual de usuario

Kia

Kia Sorento Manual de instrucciones

Kia

Kia Sportage Manual de lista de piezas

Kia

Kia UVO FORTE Manual de usuario

Kia

Kia BLUETOOTH phone system Manual de usuario

Kia

Kia F1211ADE00ST Manual de usuario

Kia

Kia C5211ADE01 Manual de usuario

Manuales populares de Accesorios para automóviles de otras marcas

James Baroud

James Baroud Odyssey Manual de usuario

Motorola

Motorola i50sx Manual de usuario

Yakima

Yakima 9MM STANDARD BIKE MOUNT Manual de usuario

Feniex

Feniex T3 Manual de usuario

Renault

Renault 77 11 423 180 Manual de usuario

Brink

Brink 756843 Manual de usuario

Whispbar

Whispbar K085W Manual de usuario

v.link

v.link CI-VL2-PC-HSD Manual de usuario

Viking

Viking Stack-Rack Guía de configuración rápida

Aries

Aries 203015 Manual de usuario

Choetech

Choetech AT0005 Manual de usuario

ZZ2

ZZ2 ZZAIR-PRO Manual de usuario

Holman

Holman 4A80L Manual de usuario

Thule

Thule 2075 Manual de usuario

Motorola

Motorola T325 Manual de usuario

TAUBENREUTHER

TAUBENREUTHER 16-3950 Guía de instalación

DV8

DV8 FBJL-02 Manual de usuario

Prorack

Prorack K1163 Manual de usuario
