Keysight 16442B Test Fixture

User’s Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation into

a foreign language) without prior agreement

and written consent from Keysight Technolo-

gies as governed by United States and inter-

national copyright laws.

Manual Part Number

16442-90100

Edition

Edition 1, December 2002

Edition 2, July 2006

Edition 3, August 2014

Printed in Malaysia

Published by:

Keysight Technologies Japan K.K.

9-1, Takakura-cho, Hachioji-shi, Tokyo

192-8550 Japan

Warranty

The material contained in this docu-

ment is provided “as is,” and is subject

to being changed, without notice, in

future editions. Further, to the maxi-

mum extent permitted by applicable

law, Keysight disclaims all warranties,

either express or implied, with regard

to this manual and any information con-

tained herein, including but not limited

to the implied warranties of merchant-

ability and fitness for a particular pur-

pose. Keysight shall not be liable for

errors or for incidental or consequential

damages in connection with the fur-

nishing, use, or performance of this

document or of any information con-

tained herein. Should Keysight and the

user have a separate written agreement

with warranty terms covering the mate-

rial in this document that conflict with

these terms, the warranty terms in the

separate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a license

and may be used or copied only in accor-

dance with the terms of such license.

Restricted Rights Legend

If software is for use in the performance of a

U.S. Government prime contract or subcon-

tract, Software is delivered and licensed as

“Commercial computer software” as defined

in DFAR 252.227-7014 (June 1995), or as a

“commercial item” as defined in FAR 2.101(a)

or as “Restricted computer software” as

defined in FAR 52.227-19 (June 1987) or any

equivalent agency regulation or contract

clause. Use, duplication or disclosure of

Software is subject to Keysight Technologies’

standard commercial license terms, and

non-DOD Departments and Agencies of the

U.S. Government will receive no greater than

Restricted Rights as defined in FAR

52.227-19(c)(1-2) (June 1987). U.S. Govern-

ment users will receive no greater than Lim-

ited Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015 (b)(2)

(November 1995), as applicable in any tech-

nical data.

Declaration of Conformity

To get the latest version of the declaration of

conformity, go to http://www.key-

sight.com/go/conformity and type in the

product number in the Search field.

Latest Information

To get the latest firmware/software/elec-

tronic manuals/support information, go to

www.keysight.com and type in the product

number in the Search field at the top of the

page.

PRELIMINARY

Safety Summary

The following general safety precautions must be observed during all phases of

operation, service, and repair of this instrument. Failure to comply with these precautions

or with specific warnings elsewhere in this manual may impair the protections provided

by the equipment. In addition, it violates safety standards of design, manufacture, and

intended use of the instrument. Keysight Technologies assumes no liability for

customer’s failure to comply with these requirements.

•GROUND THE INSTRUMENT

This is Safety Class I instrument. To minimize shock hazard, the instrument chassis

and cabinet must be connected to an electrical ground. The power terminal and the

power cable must meet International Electrotechnical Commission (IEC) safety

standards.

•DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE

Do not operate the instrument in the presence of flammable gases or fumes.

Operation of any electrical instrument in such an environment constitutes a definite

safety hazard.

•KEEP AWAY FROM LIVE CIRCUITS

Operation personnel must not remove instrument covers. Component replacement

and internal adjustments must be made by qualified maintenance personnel. Do not

replace components with power cable connected. Under certain conditions,

dangerous voltages may exist even with the power cable removed. To avoid injuries,

always disconnect power and discharge circuits before touching them.

•DO NOT SERVICE OR ADJUST ALONE

Do not attempt internal service or adjustment unless another person, capable of

rendering first aid and resuscitation, is present.

•DO NOT SUBSTITUTE PARTS OR MODIFY INSTRUMENT

Because of the danger of introducing additional hazards, do not install substitute

parts or perform any unauthorized modification to the instrument. Return the

instrument to a Keysight Technologies Sales and Service Office for services and repair

to ensure that safety features are maintained.

•DANGEROUS PROCEDURE WARNINGS

Warnings, such as example below, precede potentially dangerous procedures

throughout this manual. Instructions contained in the warnings must be followed.

WARNING Dangerous Voltage, capable of causing death, are present in this instrument. Use

extreme caution when handling, testing, and adjusting.

Safety Symbols

The general definitions of safety symbols used on equipment or in manuals are listed

below.

Instruction manual symbol. The equipment will be marked with this symbol when it is

necessary for the user to refer to the instruction manual.

Hazardous voltage and potential for electrical shock. Do not touch terminals that have

this symbol when the equipment is on.

Protective conductor terminal. For protection against electrical shock in case of a fault.

Used with field wiring terminals to indicate the terminal which must be connected to

ground before operating equipment.

Frame or chassis terminal. A connection to the frame (chassis) of the equipment which

normally includes all exposed metal structures.

Grounded terminal which indicates the earth potential.

Direct current.

Alternating current.

On supply.

Off supply.

Standby supply. The equipment will be marked with this symbol is not completely

disconnected from AC mains when power switch is in the standby position.

IEC Measurement Category I

WARNING The warning sign denotes a hazard. It calls attention to a procedure, practice, condition

or the like, which, if not correctly performed or adhered to, could result in injury or

death to personal.

CAUTION The caution sign denotes a hazard. It calls attention to an operating procedure, practice,

condition or the like, which, if not correctly performed or adhered to, could result in

damage to or destruction of part or all of the equipment.



CAT I

Product Stewardship

Waste Electrical and Electronic Equipment (WEEE)

The crossed out wheeled bin symbol indicates that separate collection for waste electric

and electronic equipment (WEEE) is required, as obligated by the EU DIRECTIVE and other

National legislation.

Please refer to http://keysight.com/go/takeback to understand your Trade in options with

Keysight in addition to product takeback instructions.

User's Guide

2 Keysight 16442B User’s Guide, Edition 3

User's Guide

Keysight 16442B test fixture (B1500A-A5F) is designed for testing electronic

devices. You mount the suitable socket module on the 16442B, which allows you to

easily connect various devices (DUTs) to measurement units.

The 16442B has thirteen channels:

• Six source/monitor unit (SMU) channels

Up to three channels can be connected to SMUs by Kelvin connections.

• Two voltage source unit (VSU) channels

• Two voltage monitor unit (VMU) channels

• Two pulse generator unit (PGU) channels

• One ground unit (GNDU) channel

This manual contains the following sections:

•“Introduction”

•“Operation”

•“Installation”

•“Maintenance”

•“Specifications”

•“Options”

Keysight 16442B User’s Guide, Edition 3 3

User's Guide

Introduction

Keysight 16442B test fixture (B1500A-A5F) contains the following accessories:

Description Keysight

Part Number Quantity

Test fixture 16442-60011 1

Stabilizer set (with flathead screws) 16442-60002 1

Carrying case for socket modules 16442-60142 1

Miniature banana to pin plug connection cable

(black)

16442-61600 4

Miniature banana to pin plug connection cable

(red)

16442-61601 4

Miniature banana to pin plug connection cable

(blue)

16442-61602 4

Pin plug to pin plug connection cable (black) 16442-61603 3

Pin plug to pin plug connection cable (red) 16442-61604 3

Pin plug to pin plug connection cable (blue) 16442-61605 3

4 Keysight 16442B User’s Guide, Edition 3

User's Guide

Introduction

NOTE Inspecting the 16442B upon Receiving

When the 16442B test fixture (B1500A-A5F) arrives at your site, make sure that

nothing is missing or damaged. Unpack the carton, then check the contents against

figure and table above. For details about furnished and optional accessories, refer to

“Specifications”.

If anything is missing or damaged, contact your nearest Keysight Technologies sales

office.

Miniature banana to miniature clip connection

cable (black)

16442-61606 3

Miniature banana to miniature clip connection

cable (red)

16442-61607 3

Miniature banana to miniature clip connection

cable (blue)

16442-61608 3

Miniature banana to miniature banana connection

cable (black)

16442-61609 3

Miniature banana to miniature banana connection

cable (red)

16442-61610 3

Miniature banana to miniature banana connection

cable (blue)

16442-61611 3

Blank PTFE

board 16058-60004 1

Dual-in-line package socket module (28-pin) 16088-60042 1

Universal socket module, 0.075 inch pitch 16442-60051 1

Universal socket module, 0.05 inch pitch 16442-60052 1

Connection pin set (10 ea.) 16088-60013 2

User’s Guide (this document) 16442-90100 1

Description Keysight

Part Number Quantity
