N9032B

IQ Streaming

Option ST1 and ST2

Keysight X-Series Signal Analyzer

INSTALLATION NOTE

Notices

The information contained in this document is subject to change without notice.

Keysight Technologies makes no warranty of any kind with regard to this material, including but

not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Keysight Technologies shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or use of this material.

Manual Part Number

N9032-90010

Edition

Edition 1, May 2023

Supersedes: None

Printed in USA

Published by:

Keysight Technologies, Inc.

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Installation Note N9032-90010 3

Option ST1 and ST2 – IQ Streaming

This document provides detailed instructions for the installation of the IQ Streaming upgrades

for the N9032B PXA Signal Analyzer with Option 544/550, or Option 508/513/526, with serial

prefix ≥MY/SG6319.

Please be sure to read this entire document before attempting to perform this upgrade. Then, be

sure to perform the steps in this procedure in the order that they are listed so that the installation

will complete properly, and the instrument will function as desired when completed.

Compatibility

This instrument option requires that the instrument has firmware version A.34.00 or newer. If the

instrument being upgraded does not currently meet this requirement the following procedure

includes a step to update it.

Instrument Calibration

The validity of any existing calibration that the instrument being upgraded may have will not be

affected by the installation of this upgrade.

Products Affected: PXA N9032B

Option 544/550 all serial prefix

Option 508/513/526 serial prefix ≥MY/SG6319

To Be Performed By: (X) Keysight Service Center

( ) Advanced User

()User

Estimated Installation Time:

Estimated Adjustment Time:

Estimated Verification Time:

2.0 Hours

0.0 Hours

1.0 Hours

4Installation Note N9032-90010

Option ST1 and ST2 – IQ Streaming

What you will find in this document

ESD Information............................................................................................................ page 5

Upgrade Contents......................................................................................................... page 7

Tools Required............................................................................................................... page 8

Initial Instrument Functionality Check ........................................................................ page 8

Instrument Software Revision Check .......................................................................... page 8

Upgrade Instructions.................................................................................................... page 9

Hardware Disassembly............................................................................................ page 9

ODI Cable Installation........................................................................................... page 13

Hardware Assembly.............................................................................................. page 20

Instrument Button Up .......................................................................................... page 24

Rear Panel Labels ................................................................................................. page 27

Instrument Software Installation ......................................................................... page 28

License Key Retrieval and Installation ................................................................ page 28

Adjustments and Performance Verification.............................................................. page 29

Manual Procedures Required............................................................................... page 29

Automated Utilities Required............................................................................... page 29

Automated Adjustments Required ...................................................................... page 29

Automated Performance Testing Required ......................................................... page 29

ODI Loopback Test..................................................................................................... page 30

Installation Note N9032-90010 5

Option ST1 and ST2 – IQ Streaming

ESD Information

Protection from Electrostatic Discharge

Electrostatic discharge (ESD) can damage or destroy electronic components. All work on electronic

assemblies should be performed at a static-safe workstation. Figure 1 shows an example of a

static-safe workstation using two types of ESD protection:

— Conductive table-mat and wrist-strap combination.

— Conductive floor-mat and heel-strap combination.

Both types, when used together, provide a significant level of ESD protection. Of the two, only the

table-mat and wrist-strap combination provides adequate ESD protection when used alone. To

ensure user safety, the static-safe accessories must provide at least 1 megohm of isolation from

ground.

Figure 1 Example of a Static-Safe Workstation

These techniques for a static-safe workstation should not be used when working on circuitry

with a voltage potential greater than 500 volts.

6Installation Note N9032-90010

Option ST1 and ST2 – IQ Streaming

Handling of Electronic Components and ESD

The possibility of unseen damage caused by ESD is present whenever components are transported,

stored, or used. The risk of ESD damage can be greatly reduced by paying close attention to how all

components are handled.

— Perform work on all components at a static-safe workstation.

— Keep static-generating materials at least one meter away from all components.

— Store or transport components in static-shielding containers.

Test Equipment Usage and ESD

— Before connecting any coaxial cable to an analyzer connector, momentarily short the center and

outer conductors of the cable together.

— Personnel should be grounded with a 1 megohm resistor-isolated wrist-strap before touching

the center pin of any connector and before removing any assembly from the analyzer.

— Be sure that all analyzers are properly earth-grounded to prevent build-up of static charge.

For Additional Information about ESD

For more information about preventing ESD damage, contact the Electrical Over

Stress/Electrostatic Discharge (EOS/ESD) Association, Inc. The ESD standards developed by this

agency are sanctioned by the American National Standards Institute (ANSI).

Always handle printed circuit board assemblies by the edges. This will reduce the possibility of

ESD damage to components and prevent contamination of exposed plating.

Installation Note N9032-90010 7

Option ST1 and ST2 – IQ Streaming

Upgrade Contents

Table 1 Upgrade Contents

Part Number Description Quantity

0515-0372 Screw-Machine w/Crest-Cup-Con-Washer Pan-HD Torx-T10 M3X0.5 8mm-LG 2

0515-0666 Screw-Machine w/Crest-Cup-Washer Pan-HD Torx-T10 M3X0.5 18mm-LG 1

0515-1946 Screw-Machine w/Patch Lock 90-DEG-flat-HD Torx-T10 M3X0.5 6mm-LG 18

0515-2332 Screw-Machine w/Patch-Lock Pan-HD Torx-T10 M3X0.5 6mm-LG 4

0515-5208 Screw-Machine w/Patch-Lock Flat-HD Torx-T6 M2X0.4 4mm-LG 1

1005-1388 Fiber Optic Adapter MPO-Shutter Female-Female flange-mount 1

1400-0082 Screw Mount Cable Clamp 4

1400-0249 Nylon Cable Tie 2

1400-1254 Adhesive Cable Clip 2

9030-0000 License Entitlement Certificate 1

M8121-60004 Connector-Fiber Optic Multimode MPO-Loopback 1

M8121-61614 Cable AY, Patch cord, ODI, F-F, 24 fiber, Type C, 3 M lg 1

M9484-80048 Label, FDA Laser 1

N9032-61000 Cable Assembly, Optical FireFly TX/RX 1

N9041-20154 Heatsink, FireFly 1

N9041-20181 Insertion Tool, FireFly 1

8Installation Note N9032-90010

Option ST1 and ST2 – IQ Streaming

Tools Required

—Torx Driver T-10

—Torx Driver T-20

—Multi-Bit Torque Driver

—5/8” Nut Driver

—5/16” Wrench

Initial Instrument Functionality Check

Power on the instrument and allow it to complete its boot up process. Verify that there are no

instrument messages that would indicate that there is an issue with either the instrument hardware

or software. If there are any issues, investigate and fix the problem before continuing with this

upgrade.

Instrument Software Revision Check

While the instrument is still powered on check to see what version of the instrument software is

installed. To do so press System, Show System and look on the System Information screen for the

Instrument S/W Revision. Record the software revision below.

Instrument S/W Revision Installed: __________

Installation Note N9032-90010 9

Option ST1 and ST2 – IQ Streaming

Upgrade Instructions

Hardware Disassembly

Dress Cover Removal

1. Turn the instrument off and disconnect the power cord.

2. Referring to Figure 2, remove the two screws (1) that attach the strap handle (2) from both

sides and remove the strap handles.

Figure 2 Dress Cover Removal

3. Remove the four rear feet (4) by removing the four screws (3) and washers that attach them.

4. Remove the four bottom feet (6) by first removing the locking keys and then lifting the tabs

and sliding the foot toward the tabs.

5. Carefully slide the dress cover (5) off the instrument.

10 Installation Note N9032-90010

Option ST1 and ST2 – IQ Streaming

Top Brace Removal

6. Referring to Figure 3, remove the sixteen flathead screws (2) and twelve panhead screws (3)

attaching the top brace (1) to the instrument and set it aside. The sixteen flathead screws can

be discarded, and they will be replaced with new ones.

Figure 3 Remove Top Brace

Blank Plate Removal

7. Referring to Figure 4, remove the two panhead screws (1) securing the blank plate (2) to the

rear panel and discard the plate.

Figure 4 Remove Blank Plate
