Keysight N8262A Manual de usuario

Keysight N8262A

P-Series Modular Power Meter

and Power Sensors

Configuration Guide

02 | Keysight | N8262A P-Series Modular Power Meter and Power Sensors – Configuration Guide

Introduction

This configuration guide describes standard configurations, options and compatible

accessories. Contact your local Keysight Technologies, Inc. representative for additional

information.

P-Series modular power meter

The P-Series modular power meter provides peak, average, peak-to-average ratio power

measurements, time-gated and free run modes, as well as pulse parameters measurements

such as rise time, fall time, pulse width, pulse period, PRI, PRF, time to positive and negative

occurrences.

The P-Series modular power meter is compatible with the 8480, E-Series (except E9320

range) and P-Series power sensors. The P-Series modular power meter has a different sensor

input connector than the EPM and EPM-P Series power meter, so it is necessary to use

adapter cables. These adapter cables come in three different lengths. When using the 8480 or

E-Series (except E9320 range) sensors, refer to the Cable Accessories section in this guide. For

additional information, refer to the Literature reference section.

The standard P-Series modular power meter includes:

– P-Series modular power meter unit

– Certificate of calibration

– Documentation CD-ROM

– Keysight Instrument Control DVD

– IO Libraries Suite

– Command Expert

– BenchVue Software Platform

– 30-day free trial of BenchVue Power Meter/Sensor Control and Analysis app

– N8262A P-Series Modular Power Meter Installation Guide

– Power cord

P-Series wideband power sensors

The P-Series wideband power sensors are designed specifically for operation with the P-Series

modular power meter for wide bandwidth power and time measurements. These sensors are

the only Keysight power sensors that have their cable permanently wired (hard-wired) into

sensor. This provides better wide bandwidth specifications compared to a removable cable.

Refer to the Sensor Cable Lengths section in this guide for part number and cable length

information.

The standard P-Series power sensors include:

– Power sensor 50 MHz to 18 GHz, order N1921A

– Power sensor 50 MHz to 40 GHz, order N1922A

– Documentation CD-ROM

03 | Keysight | N8262A P-Series Modular Power Meter and Power Sensors – Configuration Guide

Compatibility

Power sensor compatibility

The P-Series modular power meter is compatible with all current 8480, E-Series (except E9320

range) and P-Series power sensors. You may also refer to the Cable Accessories section for

power sensors compatibility.

P-Series modular power meter accessories

Standard accessories available, for example, rack mount kit.

Table 1. Standard accessories.

Accessory part number Description

N8262A-908 Rack mount kit (one instrument)

N8262A-909 Rack mount kit (two instruments)

34111A Transit case

34120A Soft carrying case

04 | Keysight | N8262A P-Series Modular Power Meter and Power Sensors – Configuration Guide

Calibration option

The P-Series modular power meter and sensors are available with:

– Option N8262A-A6J (ISO17025 compliance calibration test data including measurement

uncertainties)

– Option N8262A-1A7 (ANSI Z540 compliance calibration test data including measurement

uncertainties)

Cable Accessories

Power sensor adapters for use with 8480 and E-Series (except E9320 range) power sensors:

Table 2. Cable accessories for use with 8480 and E-Series (except E9320 range) power sensors.

Accessory part number Description

N1917A P-Series meter cable adaptor, 1.5 m (5 ft)

N1917B P-Series meter cable adaptor, 3 m (10 ft)

N1917C P-Series meter cable adaptor, 10 m (31 ft)

Software Accessories

BenchVue Software Power Meter/Sensor Control and Analysis app

The N8262A power meter is supported by the Keysight BenchVue software, BV0007B Power

Meter/Sensor Control and Analysis app. The BV0007B app extends the capability of the

N8262A P-Series modular power meter. It provides comprehensive power measurements,

flexible display formats, 15 point pulse parameters characterization, multi-channel

operations, limit and alert, recording and playback, and other features. For more information,

www.keysight.com/find/BenchVue

P-Series Wideband Power Sensor Cable Lengths

Three fixed cable length options are available for the P-Series modular power sensors at 1.5 m,

3.0 m and 10 m.

Option 105 is the standard (default) option.

Table 3. P-Series wideband power sensor cable lengths.

Accessories part number Description

N1921A-105

N1922A-105

Fixed 1.5 m (5 ft) cable length

N1921A-106

N1922A-106

Fixed 3.0 m (10 ft) cable length

N1921A-107

N1922A-107

Fixed 10 m (31 ft) cable length

05 | Keysight | N8262A P-Series Modular Power Meter and Power Sensors – Configuration Guide

Service and support options

The P-Series modular power meters and sensors are supplied with a one year customer return

repair service as standard. For extended initial service to three years, refer to Table 4.

Table 4. Service and support options.

Option Description

R1282A Return-to-Keysight – calibration plan

–R-50C-011-3 Keysight Calibration Upfront Support Plan 3 years coverage

Documentation

The P-Series modular power meter is furnished with a CD-ROM which contains the Installation

Guide, User’s Guide, Programming Guide and Service Guide. The following table provides

option numbers and part numbers for printed documentation.

Table 5. Documentation.

Option Documentation

N8262A-0BK Additional English language manual set (User’s Guide, p/n N8262-90001 and

Programming Guide, p/n N8262-90008)

N8262A-0BF English language Programming Guide, p/n N8262-90008

N8262A-0BW English language Service Guide, p/n N8262-90004

N8262A-ABJ Japanese language User’s Guide, p/n N8262-90003

N1921A-0B1

N1922A-0B1

Additional English language manual set, Operating and Service Manual, p/n

N1920-90007

Literature References

Publication title Publication number

N8262A P-Series Modular Power Meter and Power Sensors - Technical Overview 5989-6606EN

N8262A P-Series Modular Power Meter and Power Sensors - Data Sheet 5989-6605EN

N1911A/N1912A P-Series Power Meters and N1921A/N1922A Wideband Power

Sensors - Data Sheet

5989-2471EN

E4416A/E4417A EPM-P Series Power Meters and E-Series E9320 Peak and Average

Power Sensors – Data Sheet

5980-1469E

EPM Series Power Meters E-Series and 8480 Series Power Sensors - Data Sheet 5965-6382E

Fundamentals of RF and Microwave Power Measurements (Part 1) - Application Note 5988-9213EN

Fundamentals of RF and Microwave Power Measurements (Part 2) - Application Note 5988-9214EN

Fundamentals of RF and Microwave Power Measurements (Part 3) - Application Note 5988-9215EN

Fundamentals of RF and Microwave Power Measurements (Part 4) - Application Note 5988-9216EN

4 Steps for Making Better Power Measurements - Application Note 5965-8167E

Choosing the Right Power Meter and Sensor - Application Note 5968-7150E

06 | Keysight | N8262A P-Series Modular Power Meter and Power Sensors – Configuration Guide

This information is subject to change without notice.

Published in USA, September 11, 2017

5989-6608EN
