Keysight Y1217A Rack Mount Rail Kit

Installation Note

This installation note contains procedures for installing the Y1217A Rack Mount

Rail Kit for the Keysight M9018A 18-slot PXIe Chassis in a Keysight rack.

Parts List

The parts included with each rack mount adapter option and the support rail are

shown in the following table (note that not all parts listed are available as

field-replaceable parts):

General Rack Mounting Guidelines

In rack mounting the chassis, follow these guidelines:

1Always begin installing the chassis and heavy instruments at the bottom of

the rack and work up. This maintains a lower center of gravity and reduces the

possibility of the rack tipping.

2Anti-tipping feet, if available with the rack, should always be extended.

3The heaviest instrument or chassis should always be mounted at the bottom

of the rack.

4For maximum cooling and optimum rack thermal efficiency, place the

instrument or chassis with the greatest power consumption towards the top of

the rack. This promotes efficient cooling since heat rises when placed nearer

to the top of the rack, high power instruments will not unnecessarily heat

other instruments. However, in doing this, do not violate the guideline that

the heaviest instruments should be placed at the bottom of the rack.

5If instruments or modules in the chassis are consuming maximum power, 1U

of rack space is required for ventilation below the M9018A chassis.

This kit is optional to the Y1215B and Y1216A Rack Mount Kits. This kit is

designed for Keysight racks and may not fit non-Keysight racks.

Part Number Description Quantity

M9018-00110 Support Rails 2

0590-0804 Channel Nuts (4 for support rail-to-rack) 4

2680-0278 Support Rail-to-Rack Screws - 10-32 x 0.5 Pan Head Torx T25 4

All manuals and user guides at all-guides.com

all-guides.com

2 Keysight Y1217A Rack Mount Rail Kit Installation Note

Keysight Y1217A Rack Mount Rail Kit Installation Note Procedure

Procedure

Tools Required: #2 Phillips screwdriver, T25 Torx screwdriver

Figure 1 Removing the Chassis Feet

1Install any rack mount kits, such as the Y1215B Flush Mount Kit or the

Y1216A Recessed Mount Kit, or the Y1218A Cable Tray Kit prior to installing

the M9018A chassis in the rack.

2Refer to Figure 1 below. Remove the side handles and handle covers from

both sides of the M9018A PXIe chassis.

3On M9018A chassis with serial number TW54XXXXX and later, two additional

screws must be removed (one on each side of the chassis). Refer to Figure 1.

Note that earlier chassis did not have these screws.

4Remove the four chassis feet by pulling out the small rubber insert on each

foot and then removing the Phillips screw that attaches the foot to the

chassis.See Figure 1.

5Refer to Figure 2. Slide channel nuts over the rack holes to be used by the

support rails. The rails must be positioned behind the bottom channel nuts

installed for the Y1215B Flush Mount Adapter Kit or the Y1216A Recessed

Rack Mount Kit.

Do not stand the chassis on its side; the side handles may cause

the chassis to tip over.

Remove the

rubber plug and

then remove the

Phillips screw

inside

Remove the side

handles and covers

Remove these screws on both

sides of the chassis if indicated.

See Step 2 above.

All manuals and user guides at all-guides.com

Keysight Y1217A Rack Mount Rail Kit Installation Note 3

Procedure Keysight Y1217A Rack Mount Rail Kit Installation Note

6Attach the support rails (with inner flange pointing downward) to the rack’s

inside vertical columns. Use four channel nuts and the four 10-32 x 0.5 T25

Torx pan head screws as shown in Figure 2.

7Set the chassis onto the support rails. 

8Set the M9018A chassis onto the support rails. 

9Slide the M9018A chassis into the rack until the rack mount front handle

flanges are against the rack’s vertical columns. Secure the chassis to the rack

using the adapter dress screws provided with the rack flange kit. 

Figure 2 Center Holes of Rack, Attaching Channel Nuts

Important: Install support

rails with inner flange

pointing downward

Channel nuts on

rack’s inside

vertical rails

To prevent injury during rack mounting, the chassis should

be empty and two people should lift it into the rack.

If the rack will be moved excessively or over long distances, you

should use a strap to secure the chassis to the rack slides.

All manuals and user guides at all-guides.com

This information is subject to change without notice.

Edition 3 September 2014

*Y1217-90001*

Y1217-90001
