English
Install ClicBot App Advices Precautions
It supports iOS 10.0,
Android 5.0 and above.
You can search "ClicBot
App" in App Store/
Android app store or
scan the QR code below
to download it.
For the Operation
Manual and the FAQs,
please refer to the
ClicBot Space Travel
Guide. Please refer to
the User’s Manual for
information of ClicBot,
including module
specifications, assembly,
usage, connection
settings, battery
recharging, security &
privacy, after-sale
services, and FAQs.
1.Contains small parts. Not suitable for children under 3 years old;
2.Contains precision parts. Prevent it from high drop;
3.Not fireproof.
4.Not waterproof.
5.Keep the golden "po-go" pins away from metal;
6.Do not directly or indirectly connect two or more Brain
together;
7.Do not remove or replace the built-in battery; please contact our
after-sales service team for repairs in case of battery damage;
8.Please use the charger recommended only (output voltage
recommended: DC 5V/2A);
9.Do not play with it while charging;
10.Do not rotate ClicBot when the movement function is locked;
11.Do not touch the moving ClicBot;
12.ClicBot should be recycled to prevent environment pollution;
13.This package contains important information, please keep it
properly.
2
English English
Contents
3
4
5
6
7
8
8
9
10
11
12
13
14
14
15
16
Suction Cup
Distance Sensor
Grasper
Assembly
Holder
Battery Capacity and Charging
Security and Privacy
Security and Privacy
17
17
17
18
19
20
21
RF Specification
User Privacy
After-Sales Service
FAQs
FAQs
Warranty description
Warranty Card
Contents
Introduction
Brain
Joint
Skeleton
Wheel
Mount
Locker
Smart Foot
3
English English
Introduction
ClicBot is an intelligent robot for kids with built-in educational and
entertaining functions.
ClicBot is of unique modular design that is easy to assemble and
disassemble, and allows the creation of varied imaginative robots as
building bricks. ClicBot is more than just a robot or a toy, it is the
companion of children. It has a big blinking eye, like a curious kid
looking around. ClicBot is able to interact with you. If it recognizes you,
it will greet you warmly. When you pet its head, it will play cute; If you
block its way, it will take detours curiously. The ClicBot App also
provides various functions and applications, such as galloping racing
robots, cute animal robots, climbing robots, bionic walking robots,
satisfying children's every imagination of robots.
ClicBot is designed to help children shaping the future. The ClicBot
App has two creative tools: motion script or graphical programming.
With motion script, users can easily control the movement and
direction of ClicBot remotely, through directly adjusting the posture of
the robot in turn, or pushing the robot to move in all directions like a
toy car. For more intermediate and advanced actions, users can use
the drag & drop graphical programming feature to create a wider
variety of amazing programs and actions. To help children fully exert
their ideas and creativity, ClicBot App will continue to update the
STEAM videos under its ClicBot CollegeAcademy function, so as to
better guide children on how to build, program, and play with different
robotic creations. Additionally, users can also upload their works to
the ClicBot App Community for sharing with others.
Introduction
4
English English
Brain
The Brain is the master control and power supply unit of the ClicBot. It
uses an ARM-A7 processor and includes a rechargeable polymer
lithium battery with a capacity of 1550mAh. The eye of the ClicBot is
a 2.1-inch rotational, circular touch screen. Visual sensors, gesture
sensors and camera lights are located at the upper-left corner. There
are three touch sensors located on the upper, left, and right side of
the Brain respectively; two connectors are located on the upper and
bottom rear side. The Brain also contains such functional modules as
accelerometer, gyroscope, microphone, loudspeaker, and Wi-Fi
module.
Brain
Specification of Modules
Size
Weight
66.7*66.5*124.8 mm
275g
2.1”
-24° - +24°
Touch sensors
Microphone
Loudspeaker
WiFi
Battery
Charge port
Connector
1550mAh
USB-C
Upper and bottom
rear side
Upper, left and right side
Support volume detection
Single track
2.4 G/5G
Touch screen size
Screen rotate angle
Gesture recognition
sensors
Camera
2-megapixel
Support face
detection &
recognition, motion
detection
Recognition
distance 5m
8 gestures can be
recognized at a
distance of 20cm
Microphone
Type-C charge port
Power button
Gesture sensors
Camera light
Camera
Touch sensors
Power supply light
Touch screen
5
English English
Joint
Joint is used for integrated motion.
It is a high-precision servo system, in which contains a DC geared
motor, and sensors such as angular rate/angle position sensors.
There are four connectors, two in each hemisphere. Each connector
has a status indicator showing the connection and update status.
Connection Status
ăLight onȹConnected
correctly
ăFlashingȹWaiting for
module connection
ăFlashing quicklyȹWrong
connection
Update Status
ăLight onȹUpdated
successfully
ăFlashingȹModule needs
updating
Joint
Specification of Modules
Size
Weight
55 mm (diameter）65 g
2.64 W
216° /s
Motor rated power
Two each in the upper
and lower hemisphere
Maximum rotation
speed
Connection light
*Status of Joint’s indicator
6
English English
Skeleton
The Skeleton, “bone” of the ClicBot, is used for connecting limbs of
the robot. There are two connectors, locating at the top and bottom
of the Skeleton. Two strip status indicators are located on the front,
which show the connection and update status.
The color of Skeleton’s indicator can be changed via graphical
programming.
light strip
Specification of Modules
Size
Weight
Connector
position
37.8*37*120 mm
50 g
Upper and
bottom rear side
Connection Status
ăLight onȹConnected correctly
ăFlashingȹWaiting for module
connection
ăFlashing quicklyȹWrong
connection
Update Status
ăLight onȹUpdated successfully
ăFlashingȹModule needs updating
*Status of Skeleton’s indicator
ID
7
English English
Wheel Wheel
Wheel is a functional actuator module used for vehicle setups. The
Wheels includes a DC geared motor and a magnetic speed sensor,
with a maximum rotation speed of 4.5
rounds-per-second. It also has a status indicator near the main
connector, showing the connection and update status.
Connection Status
ăLight onȹConnected
correctly
ăFlashingȹWaiting for
module connection
ăFlashing quicklyȹWrong
connection
Update Status
ăLight onȹUpdated
successfully
ăFlashingȹModule needs
updating
Specification of Modules
Weight
Wheel diameter 83.8 mm
130g
2.4W
4.5 rounds / second
Motor rated power
1
Maximum rotation
Connector position
*Status of Wheel’s indicator
8
English English
Mount Locker
The Mount can be used to fix your ClicBot to a table with Mount
Stickers.
The Locker is used to reinforce connections between two modules.
It can be used for connecting modules when additional Lockers
are required.
Step1
Place the Locker
between
modules
Step2
Rotate the
Locker
Step3
Rotate until the Locker
is aligned with the
locking baselines
Please use the Mount stickers provided by KEYi Tech to ensure
firm adhesion.
Specification of Modules
Weight
Size 75.3*75.3*45.8 mm
60g
Weight
Size 47*36*15.4 mm
60g
