OPERATING INSTRUCTIONS

The Experts in Digital Video Technology and Solutions.

HD View 8

8-channel VGA Distribution Amplifier

Model KD-RGBDA8

The HD View 8TM is an 8-channel VGA Distribution Amplifier. It is the logical

choice for artifact-free distribution of your VGA signals. If you have VGA

(RGBHV) signals from any HDTV multimedia or computer source you can

feed up to eight or more VGA monitors.

The Experts in Digital Video Technology and Solutions.

HD View 8TM / Model KD-RGBDA8

Safety Instructions – Please be sure to follow these

instructions for safe operation of your unit

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided

for your safety. If the provided plug does not fit into your outlet, consult an electrician

for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs, con-

venience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by the manufacturer

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or

sold with the apparatus. When a cart is used, use caution when moving the

cart/apparatus combination to avoid injury from tip-over.

Unplug this apparatus during lightning storms or when unused for long periods of

time.

Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is dam-

aged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been

dropped.

HD View 8TM Operating Instructions

Page 2 of 8

The Experts in Digital Video Technology and Solutions.

Page 3 of 8

HD View 8TM Operating Instructions

HD View 8TMModel # KD-RGBDA8

Key Digital

“HD View 8TM”(Model KD-RGBDA8) is an 8-channel VGA Distribution Amplifier. It

is the logical choice for artifact-free distribution of your VGA signals. If you have VGA (RGBHV)

signals from any HDTV multimedia or computer source that you need to feed to up to eight

or more VGA monitors,HD View8 does the job with a bandwidth of 300 MHz on cable runs

up to 300 feet long. All HDTV formats are accepted, like 480i, 480p, 720p, and 1080i/540p;

plus all VESA formats from 640x480 to 1600x1200, with refresh rates from 50 Hz to 80 Hz. An

added benefit is the ability to "daisy-chain" (cascading) multiple units. As long as you termi-

nate at the end of your input cable run, you can readily cascade three or more HD View8 DA’s

and drive a wall of 32 or more VGA monitors, all with crystal-clear clarity.

General Information

• Enables RGBHV signal distribution from any HDTV multimedia or computer source to VGA-

based monitors

• Many formats accepted: all SD and HD formats: 480i, 480p, 720p, 1080i/540p and VESA-

based PC formats: from 640x480 to 1600x1200

• Refresh rates 50 Hz to 80 Hz

• One unit can drive up to 8 monitors

• The HD View 8TM can be cascaded to other HD View 8TM units to drive as many outputs as

desired from one source

• Each output can drive up to 300 feet each with equal-length VGA cables

Signal Properties

• RGB Video

• Bandwidth -3 dB at 300 MHz, linear-phase passband

• Unity-gain, 0.7 volt p-p, terminated to 75 ohms

• H and V sync TTL type 5 volts p-p

Input

• One DB15 VGA connector for connecting the “source” signal to the HD View 8TM for

distribution to the output.

Loop Through

• One DB15 VGA connector for connecting the “source” signal to an additional HD View 8TM

for distribution to additional video displays.

Outputs

• Eight DB15 female connector for connecting the HD View 8TM to the outputs.

The Experts in Digital Video Technology and Solutions.

HD View 8TM Operating Instructions

Page 4 of 8

The Experts in Digital Video Technology and Solutions.

Mechanical

• Easy to install and integrate

• Cables attach to only one side of the unit

• all video inputs and outputs have DB15 (VGA) female connectors

• The 1U-high unit may be oriented horizontally, or mounted vertically on a wall

• Size: 12 3/16" x 5 1/8" x 1 13/16"

• Weight: 5.5 lbs.

• Enclosure type: Metal (no vents)

• Input Power: External power supply provided, 110-240V AC, 50-60 Hz, 0.9 A

Modes of Operation

The HD View 8TM can be configured for two different modes of operation.

1) 75 Ohm termination mode for stand alone distribution applications or as the terminating

unit at the end of a “daisy-chain” of HD View 8TM units. This is the factory default mode

of operation.

2) High Impedance Loop through mode for “daisy-chaining”. This mode must always be

used when connecting to an additional HD View 8TM unit.

Product Hookup

After unpacking the unit make sure to make all connections before plugging in the power

adapter.

The HD View 8TM will receive virtually any RGBHV signal from a HDTV multimedia or comput-

er source and distribute to VGA based monitors. A typical hookup will consist of a “source”

device which should be hooked up to the DB15 input. Formats accepted include all SD and

HD formats: 480i, 480p, 720p, 1080i/540p and VESA-based PC formats from 640x480 to

1600x1200 with refresh rates 50 Hz to 80 Hz. After hooking up the “Source” device to the

marked input connector, the HD View 8TM will distribute this source up to 8 monitors that are

hooked up to the output DB15 connectors. If you need to distribute the “source” to more

than 8 monitors, you can “daisy-chain” the HD View 8TM to another HD View 8TM by using the

High Impedance loop through mode of operation. When using a daisy chain of HD View 8TMs,

you need to connect the loop-through DB15 connector on the first unit to the DB-15 input

connector of the next unit in the chain. Use also need to set the mode of operation as noted

in the next paragraph of this manual.

Page 5 of 8

HD View 8TM Operating Instructions

Setting the Mode of Operation

The HD View 8TM should come from the factory set for single use (terminated or non daisy

chain) operation. The four DIP switches on the side of the unit are used to set the mode of

operation.

Mode One (factory default)

For single use, the switches should all be set in the On (Up) position. (75 Ohm termination

mode)

Mode Two

If you are using the HD View in the daisy chain mode, all switches should be set in the Off

(Down) position (High Impedance Loop mode). Please note that the last unit in the daisy

chain should have its switches set in the On (Up) position (75 Ohm termination mode).

Power Supply Hook Up

After making sure that all hook ups are secure and the settings for the mode of operation is

correct, you need to connect the AC to DC wall power converter. Thus converter has a multi-

pin plug that fits into the connector panel of the HD View 8TM. Please make sure that the ori-

entation of the plug is correct to avoid bending the pins on the plug. After attaching the plug

to the HD View 8TM connect the AC plug into a 115 volt wall outlet.

Operation

Once power has been applied, use a reliable “Source” to test your connections . Since the

HD View 8TM is a powered device it will produce a minimal amount of heat, therefore it is

recommended to leave enough room around the unit to dissipate this heat.

If, after properly connecting all of the devices in the system, the unit fails to properly distribute

the “Source” signal, please check the following:

No power to the unit.

Make sure that the external power supply is properly connected to a standard 115V

household outlet. For added safety and protection it is always recommended to

use a good quality surge protector. Check to make sure that the power connector is

properly inserted into the HD View 8TM.Unplug the adapter from the wall and verify that the

cable is not cut or interrupted anywhere. If the HD View 8TM is still not functioning properly,

please contact Key Digital

technical support hotline at (888) 258-2028 or send an e-mail to

tech@keydigital.com.

HD View 8TM Operating Instructions

Page 6 of 8

The Experts in Digital Video Technology and Solutions.

HOW TO CONTACT KEY DIGITAL®

Repairs and Warranty Service:

Should your HD View 8TM require warranty service, please contact Key Digital®to obtain a

Returned Materials Authorization (RMA) number

Please contact us at either:

1-914-667-9700

email [email protected]

Technical Support:

For technical questions about using our products, please contact us at either:

1-914-667-9700 or Toll-free 1-888-258-2028

email [email protected]

Customer Support

For customer support questions about using our products, please contact us at either:

1-914-667-9700

email [email protected]

WARRANTY

All Key Digital®products are built to high manufacturing standards and should provide years of

trouble-free operation. They are backed by a limited two-year parts and labor warranty.

September 2004

Page 7 of 8

HD View 8TM Operating Instructions

The Experts in Digital Video Technology and Solutions.

Web :: www.keydigital.com

Phone :: 914-667-9700 Fax :: 914-668-8666

Key Digital

, led by digital video pioneer Mike Tsinberg,

develops and manufactures high quality, cutting-edge

technology solutions for virtually all applications where

high quality video imaging is important. Our products are

used by professional broadcasters, corporations, custom

installers, home theater retailers, and consumers.

HD View 8TM Operating Instructions
