Kenmore KH-7E01-SSTP Manual de usuario
Carbon Infrared Heater
with Tripod
Use & Care Guide
Manual de Uso y Cuidado
English / Español
CALENTADOR INFRARROJO DE CARBONO
CON TRÍPODE
Models / Modelos :KH-7E01-SSTP & KH-7E01-BKTP
If you have any questions, please call 1-888-287-0735,
between 8:00 a.m. to 5:00 p.m. PST, or visit us at Kenmoreheaters.com
Si tiene alguna pregunta, llame al 1-888-287-0735,
de 8:00 a. m. a 5:00 p. m. PST, o visítenos en Kenmoreheaters.com
Kenmore and the Kenmore logo are registered trademarks of Transform SR Brands LLC and are used under license
by Permasteel, 100 Exchange Place, Pomona, CA 91768.
Kenmore y el logotipo de Kenmore son marcas comerciales registradas de Transform SR Brands LLC y se usan
bajo licencia de Permasteel, 100 Exchange Place, Pomona, CA 91768.
WARNING
Combustion by-products produced when using this
contain chemicals known to the State of California to
cause cancer, birth defects, and other reproductive
harm. For more information go to
www.P65Warnings.ca.gov
Wash your hands after handling this product.
CALIFORNIA PROPOSITION:
Product Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Incorrect Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assembly & Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TABLE OF CONTENTS
3
4-5
6
7-9
10-12
13-21
22-23
24
25
2
3
WARRANTY
4
LIMITED WARRANTY
WITH PROOF OF SALE: the following warranty coverage applies when this appliance is correctly installed,
operated and maintained according to all supplied instructions. Note: Consumer is responsible for shipping &
handling of all warranty replacement parts.
FOR ONE (1) YEAR FROM THE DATE OF ORIGINAL PURCHASE: from the date of sale this heater is
warranted against defects in material or workmanship, consumer will receive free replacement parts with proof
of purchase, consumer is responsible for shipping & handling cost.
All warranty coverage excludes paint loss, discoloration or surface rusting, which are either expendable parts
that can wear out from normal use within the warranty period, or are conditions that can be the result or
normal use, accident or improper maintenance.
All warranty coverage is void if this appliance is ever used for other than private household purposes.
For warranty coverage details or to obtain replacement parts, visit the web page: Kenmoreheaters.com
This warranty covers ONLY defects in material and workmanship, and will NOT pay for:
1. Service calls to correct appliance installation, or to repair problems with house fuses, circuit breakers,
house wiring, and plumbing or gas supply systems resulting from such installation.
2. Service to an appliance if the model and serial plate is missing, altered, or cannot easily be determined to
have the appropriate certification logo.
3. Expendable items that can wear out from normal use within the warranty period, including but not limited
to batteries, screw-in base light bulbs and surface coatings or finishes.
4. A service technician to clean or maintain this appliance, or to instruct the user in correct appliance
installation, operation and maintenance.
5. Damage to or failure of this appliance resulting from installation, including installation that was not in
accord with electrical, gas or plumbing codes.
6. Damage to or failure of this appliance, including discoloration or surface rust, if it is not correctly operated
and maintained according to all supplied instructions.
7. Damage to or failure of this appliance, including discoloration or surface rust, resulting from accident,
alteration, abuse, misuse or use for other than its intended purpose.
8. Damage to or failure of this appliance, including discoloration or surface rust, caused by the use of
detergents, cleaners, chemicals or utensils other than those recommended in all instructions supplied with
the product.
9. Damage to or failure of this appliance resulting from natural or other catastrophe, such as flood, fire or
storm.
10. Damage to or failure of parts or systems resulting from unauthorized modifications made to this appliance.
Disclaimer of implied warranties; limitation of remedies
Customer’s sole and exclusive remedy under this limited warranty shall be product replacement parts as
provided herein. Implied warranties, including warranties of merchantability or fitness for a particular purpose,
are limited to 1 year on the heater. Seller shall not be liable for incidental or consequential damages. Some
states and provinces do not allow the exclusion or limitation or incidental or consequential damages, or
limitation on the duration of implied warranties of merchantability or fitness, so these exclusions or limitations
may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which varies from state to state.
The Kenmore brand is used under license. Direct all claims for warranty service to: 1-888-287-0735.
Exclusions for commercial use.
Permasteel Inc, Pomona, CA 91768.
IMPORTANT SAFETY INSTRUCTIONS
4
WARNING
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.
We cannot be liable for any damage caused by the failure to observe these instructions.
READ CAREFULLY –This infrared heater has been designed for safe operation. However, if it is not installed,
maintained, or operated correctly, it may be dangerous and cause injury. To reduce the risk of fire, electrical
shock, or personal injury, please follow the procedures below. Please save these instructions for future use.
1. Read all instructions before using this heater.
2. Remove the unit from its packaging and check to make sure it is in good condition before using it.
3. Do not let children play with parts of packaging (such as plastic bags).
4. Check the household voltage to ensure it matches the heater’s rated specification.
5. Check the power cord and plug carefully before use, to make sure that they are not damaged.
6. Before unplugging the power cord, be sure to turn off the power.When turning on the heater, be sure
your hands are dry to prevent electric shock.
7. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the
sides and rear.
8. Extreme caution is necessary when the heater is being used near children.
9. Do not leave the heater unattended for long periods of time while in operation.
10. To protect against electric shock, do not immerse cord or plug in water or any other liquid.
11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause an
electric shock, fire or damage to the heater.
12. Always unplug the heater when not in use.
13. Connect to properly grounded outlets only.
14. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
15. Do not allow the cord to overhang the countertop where it can be easily pulled by children.
16. Do not put fingers or foreign objects into the heater while in operation.
17. Do not leave the appliance unattended when in use.
18. This heater is not intended for use in bathrooms, laundry and similar indoor locations. Never put heater
where it may fall into a bathtub or other water container.
19. No liability can be accepted for any damage caused by non compliance with these instructions or any
other improper use or mishandling.
20. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge unless they have been given supervision or
instruction” to “unless they are supervised or given instruction concerning the use of the appliance by a
person responsible for their safety. Children and vulnerable people should be supervised to ensure they
do not play with the appliance.
21. Use this heater only as described in this manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to people.
IMPORTANT SAFETY INSTRUCTIONS
5
WARNING
Recommended primarily for indoor or
sheltered outdoor use only. DO NOT
expose to rain or moisture.
Do not operate any heater with a damaged cord or plug or if the heater malfunctions, has been
dropped or damaged in any manner. Disconnect power from the service panel and have the heater
inspected by a reputable electrician before reusing. If you have any reason to believe that the
electrical cord or plug on your heater is damaged, do not attempt to operate the heater. Similarly, if
the heater itself has been dropped or damaged in any way, immediately disconnect the power and
have it inspected by a professional before using it again. Operation of a damaged or malfunctioning
unit is extremely dangerous and could lead to fire or serious injury.
Do not run cord under carpeting. Do not cover the cord with throw rugs, runners, or similar coverings.
Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will
not be tripped over.
To disconnect heater, turn controls to OFF, then remove the plug from outlet.
To prevent overheating of this appliance, keep the air inlets and outlets clean and free of anything that
may cause blockage. Check all inlets and outlets from time to time to ensure it is clear of any dirt or
dust accumulation. DO NOT COVER.
A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored.
Parts of the heater may exceed 392°F (200 °C). Contact with the heating tube, reflector, or metal
parts near the heating tube, may cause severe BURNS. To avoid burns, do not let bare skin touch hot
surface.
NEVER place hands under the heating elements. ALWAYS allow heating element to cool at least 10
minutes before touching the heating tube or adjacent parts.
This product contains recyclable materials. Do not dispose of this product as unsorted municipal
waste. Please contact your local municipality for the nearest collection point.
22.
23.
24.
25.
26.
27.
28.
29.
6
PRODUCT SPECIFICATIONS
Model KH-7E01-SSTP / KH-7E01-BKTP
Voltage (V) 120V AC
Wattage (W) 1500
Hertz (Hz) 60
Dimensions (W x H x D) 33.30 x 6.29 x 4.92 in
84.6 x 16 x 12.5 cm
Weight 6.17 lb. (2.8 kg)
INTRODUCTION
The carbon infrared heater produces instant and comfortable heat like the sun. These robust and weatherproof
heaters are designed for domestic heating applications within indoor and outdoor areas.
This heater is for use on 120 volts. The cord has a plug as shown in (A) in Figure 68.1. An adapter as shown at (C)
is available for connecting three-blade grounding-type plugs to two-slot receptacles. The green grounding lug
extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box.
The adapter should not be used if a three-slot grounded receptacle is available.
(Figure 68.1: Grounding Methods)
7
WARNING INCORRECT PLACEMENT
WARNING: To reduce the risk of fire
Caution: Keep combustible
materials, such as furniture, pillows,
curtains at least 3 feet (0.9m) from
the front of the heater and keep
them away from the sides and
rear.
Caution: Hot surface, do NOT
touch.
Caution: Do NOT use with an
extension cord or relocatable
power tap (outlet/power strip).
Caution: Do NOT cover with
any objects such as blanket on
the heater.
8
Correct Installation Position -01
Note: Mounted angle with 30°-45°
WALL
WALL
WARNING INCORRECT PLACEMENT
9
Correct Installation Position -02
Note: Heater should be wall or ceiling mounted under wall protected
environments, keep at least 3 feet (0.9 m) away from any combustible objects.
WALL WALL
Note: Do not cover.
WALL WALL
WARNING INCORRECT PLACEMENT
1. Heater
1 pc
2. Tile Protection Grid
1 pc
3. Tripod
1 pc
10
PARTS LIST
Key Description Qty Part Number
1Heater (SS) 1KH-7E01-TP-01
2Tilt Protection Grid 1KH-7E01-TP-02
3Tripod 1KH-7E01-TP-03
Please make sure all parts are there
before beginning assembly.
If you are missing hardware or have
damaged parts after unpacking heater,
call 1-888-287-0735.
Or Visit us at Kenmoreheaters.com
Manual 1KH-7E01-TP-M
Not Pictured
