Ken A Vision Video Flex 7600 Manual de usuario

Image Sensor

KAV 1/4" CCD

Pixel Count

ACT 512(H x 581(V

Frame Rate

Yes up to 30 fps

Field of View

9.25" X 7.5" / 23.5cm X 19cm

OSD

Yes Controlled by software buttons

Output Resolution

Yes 640 x 480

Output

Yes S-Video, USB 2.0

RS232

Yes via computer

USB Connection

Yes 2.0

USB Cable

Yes 6' / 1.8 meters

Operating

Temperature

Yes Minus 10°C – 45°C

Lighting

Yes

Minimal greater than 3 lux NO ACCESSORY LIGHTS REQUIRED

Power Source

Yes DC 12V = 100-240V

Cross Platform OS Yes Windows XP, 7/LINUX/MAC

UVC Driverless Yes Plug-n-play

MSI support Yes installation, maintenance, and removal of software via Microsoft server

Advance Imaging Yes via Applied Vision 4 Software

Average Set up time Yes less than 5 minutes for 1 – 1,000 units using MSI for Cross platform software installations

Free Updates Yes For the life of the product on software and hardware

Detailed Specifications (January 2012

Video Flex®

7600

Camera

IWB* Compliant Yes Interactive White Board Compliant for most current boards

Viewing Angle Yes

180° ball and socket head

Focal Distance

Yes 1/4" (0.6cm to Infinity

Goose Neck

Yes 25" / 65cm

Lens

Yes 8mm

Digital Zoom Yes Controlled by software buttons up to 16x

Focus

Yes

Manual

White Balance Yes Auto or manual controlled by software buttons

Color/B&W Yes Black and White controlled by software buttons

Gamma Adjustment Yes Auto or manual controlled by software buttons

Negative/Positive Yes Controlled by software buttons & buttons on base

Image Rotation Yes 360° in both directions controlled by software buttons

Capture/Freeze Yes Freeze image via software button

Audio Recording Yes Synchronized recording via software buttons

Image Compression Yes JPEG

Annotation Yes in software or working with Interactive Whiteboard interfaces

Light Control Yes Low Light achieved through CMOS and varied through software with Memory Control

Controls

Ken-A-Vision Mfg. Co., Inc.

www.ken-a-vision.com soultions@ken-a-vision.com

Specifications are subject to change without notice.

1 of 2

Video Flex®

7600

Applied Vision 4

Software

Full Screen Yes desktop enabled icon and single click software button via software

Image Compression Yes Software Enabled JPEG

Split Screen Yes Software

Multiple Camera

Support

Yes 8 running simultaneously processor speed required

Time Lapse Recording Yes Both Image and Video playback

Drawing Yes Multiple pallet tools

Video Playback Yes Through varied programs

Document Orientation Yes Single Click software button

Distance Learning Yes Single Click software button UVC compliant

Auto Format Image Yes 16:9 format and/or 4:3 fomat auto or manual select by software

Export to MS Office Yes Drop down to MS Word or EXCEL

Size 7" x 7" x 28" / 18cm x 18cm x 72cm

Weight 10lbs / 4.55kgs

Microscope Adapters

Built-in 34.5, 28mm

Carrying Case Molded plastic with aluminum frame; Folding handle and locking latch

Optional Upgrades USB extension cable (VVC16USB ; VGA Converter (V-VGACON

Certifications CE, CSA, RoHS, Weee, ISO 9001 - 2000

Warranty 5 Years

Other Information

*Interactive Whiteboard

Ken-A-Vision Mfg. Co., Inc.

www.ken-a-vision.com soultions@ken-a-vision.com

Specifications are subject to change without notice.

2 of 2
