Ken A Vision Visualisers & Document Cameras Guía de instalación

Visualisers &

Document Cameras

For 65 years, Ken-A-Vision has created

innovative and award-winning products.

Corporate Headquarters

Ken-A-Vision Mfg. Co., Inc.

5615 Raytown Road

Kansas City, MO 64133, USA

Tel: +1-816-353-4787

Fax: +1-816-358-5072

[email protected]

International Ofce

Ken-A-Vision International GmbH

Alte Bohle 33

D-50321 Brühl, Germany

Tel: +49-2232-28197

Fax: +49-2232-200897

[email protected]

www.ken-a-vision.com

“At Ken-A-Vision, I’m not just a number on

an assembly line; I’m part of a team. A team

that cares about each and every product we

make. You might know our products like the

Digital Vision View™ (7890UM) are easy to

use, powerful, and exible, but I want everyone

to know that every unit we build has three inspections

before it heads out the door.

I take great pride in what I do, and the attention to

detail is what I enjoy most about my job. I make

sure each and every camera I assemble is the

best it can possibly be. It’s easy to stand behind

a product like ours when you know it’s great and

you know the customer is getting a well-made

product that will work from day one.”

Marina Pacheco, Camera Production

Ken-A-Vision employee since 2002

A leader in digital presentation solutions, visualisers, document cameras,

microscopes and applications software, Ken-A-Vision®provides high quality,

cost-effective products. For 65 years, Ken-A-Vision has created innovative

products for the global market such as the FlexCam®, Vision ViewerTM,

and the Video Flex®camera lines. Based in Kansas City, Missouri, U.S.A.,

Ken-A-Vision helps students see more, do more and learn more. For more

information, visit www.ken-a-vision.com or contact [email protected].

Visualisers &

Document Cameras

ISO

9001:

2000

This is just a sample of the Ken-A-Vision certications. Contact Ken-A-Vision for more information

Ken-A-Vision®

Camera Table of Contents

FlexCam®2 - 910-171-200 2-3

Vision ViewerTM Colors 4-5

Auto Focus Vision ViewerTM - 7880 6

Digital Vision ViewerTM - 7890UM 7

Vision ViewerTM - 7890B 8

iCam Digital - 910-171-102 9

Digital Video Flex®- 7200UM 10

Video Flex®- 7600 11

CeilingDocCam - 910-171-066 12-13

Aqua Flex - 1475 14

USB Extension Cable - VVC16USB 14

USB Adapter - VFUSBAD2 15

VGA Converter - V-VGACON 15

Applied VisionTM 4 Software 16-17

FlexCam®2

910-171-200

2 www.ken-a-vision.com

A cutting-edge

document camera

with HD resolution at

an affordable price.

910-171-200

Available

January 2011

3.2 megapixel camera

LED lights

Flat metal stand

for stability

Sturdy, exible neck

does not sag

Audio connection

USB digital output

Comes with Applied

VisionTM Software

Features

www.ken-a-vision.com 3

This innovative and sleek document camera has a stable at stand that offers

more usable surface area by virtually disappearing under documents or books. The 3.2

megapixel camera head is coated in textured over-molded rubber, making it easy to grip

and adjust on a exible, sturdy neck that retains its position without sagging. Controls are

readily accessible directly on the camera head.

Vision ViewerTM Colors

Available in an assortment of colors to match

your school colors or to assign different colors

to specific classrooms, the Vision Viewer

document camera is easy to use and nearly

indestructible. A pre-attached USB cable offers

simple plug-and-play use and all controls are

handled through your computer mouse.

Small, dynamic base with

no confusing buttons

Available in assorted colors

Factory-installed USB cable

Sturdy, exible neck

Compatible with interactive

whiteboards

Free software upgrades

Features

4 www.ken-a-vision.com

www.ken-a-vision.com 5

Superior image quality

in real time that is even

more affordable.

7880

Auto Focus Vision ViewerTM

7880

The Auto Focus Vision Viewer is a great solution for showing documents or printed

materials as the auto focus feature helps to quickly bring the page materials into view.

Say goodbye to other document display methods with this easy-to-use camera.

Auto focus camera head

Wide angle (16:9) camera view

Small, dynamic base with no

confusing buttons

Factory-installed USB cable

Sturdy, exible neck does not sag

Compatible with interactive

whiteboards

Free software upgrades

Unlimited site licenses

Features

6 www.ken-a-vision.com

7890UM

Digital Vision Viewer

7890UM

A classroom basic in black,

the Digital Vision Viewer is

perfect for science-related

use, as it offers manual focus so

you can decide what elements

are in focus. An included

eyepiece adapter ts into the

camera head to attach it to the

eyepiece of a microscope.

Manual focus

camera head

Camera captures up to

30 frames per second

Small, dynamic base with

no confusing buttons

Factory-installed USB cable

Sturdy, exible neck

does not sag

Compatible with interactive

whiteboards

Free software upgrades

Unlimited site licenses

Features

www.ken-a-vision.com 7

7890B

Vision ViewerTM

7890B

A classroom basic in black, the

Vision Viewer is perfect for

science-related use, as it offers

manual focus so you can decide

what elements are in focus. An

included eyepiece adapter ts into

the camera head to attach it to the

eyepiece of a microscope.

Manual focus

camera head

Direct connection

to projector

Small, dynamic base with

no confusing buttons

Sturdy, exible neck

does not sag

Features

8 www.ken-a-vision.com
