Information Sheet
KEF Audio (UK), Eccleston Road,T
ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com
KEF America, 10 Timber Lane, Marlboro, New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com
GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de
Amotorised dipole surround sound
speaker,the CiFDT combines genuinely
unobtrusive installation with the ability to
create stunningly realistic background
effects. Lying flush with the wall when not
in use, a sophisticated flat panel driver
moves into position when switched on,
radiating higher frequencies equallyfront
and back to diffuse the sound evenly
throughout the room, while low frequency
effects are being faithfully reproduced by
the integral 130mm (5”) bass driver.
Acoustically, the two technologies
complement each other perfectly to
generate a richlydetailed ambient
soundfield; aesthetically, the appearance
couldn’t be more discreet.
As an architectural audio solution,
it’s imaginative, impeccably engineered and
incredibly satisfying.
Features and Benefits:
Purpose built for flush mounting into walls
,
the CiFDT combines 100W power
handling and 86dB sensitivity.
A110mm x
180mm (4
1⁄3
”x7”) Flat panel with a
130mm
(
5
”)
bass driver.
Will require an additional 12 volt supply.
The bezel and grille can be painted or
covered by fabric to match the interior décor.
Installation
13
5
2
4
67
500Hz 1kHz
2kHz 4kHz
8kHz 16kHz
Polar graphs
Frequency / Power response, Input impedance
Directivity Index / Beamwidth
Specifications
Architectural specifications:
The
CiFDT
comprises a
110mm x 180mm
(4
1⁄3
”x7”) Flat panel with a
130mm (
5
”)
bass driver
.Performance should meet or
exceed the following criteria: frequency
response 1 metre on-axis with swept
sinewave shall be 80Hz to 20kHz, sensitivity
shall be at least 86dB for 2.83V@1m. The
impedance and maximum power shall be
100W at 8 ohms. The
CiFDT
is best suited
for high quality music and home theatre
applications where hi-fi performance is
required, such as:
·Multi Room systems.
·Home Theatre systems.
Frequency range 80Hz - 20kHz
Sensitivity (2.83v @ 1m) 86dB
Rec. amplifier power 20 - 100W
Nominal Impedance 8Ω(min. 3.2Ω)
Crossover Frequency 180Hz
Enclosure material Steel
T
erminals terminal blocks up to Ø2.5 mm (0.1”)
conductor
Dimensions (H x WxD) 248 x 248 x 103 mm, 9.75 x 9.75 x 4 in.
Net weight 1.5kg (3.3lbs)
