KEF Uni-Q Ci3-80QT Manual
The most elegant design solution to the
perennial problem of where to place the
all-important front speakers in a high-end
home theatre installation, the motorised
Ci3-80QT purrs down into position from
the ceiling. With a 75mm (3”) Uni-Q®
array flanked by a pair of long-throw bass
drivers of the same size, it combines
Uni-Q’s exceptionally wide dispersion
characteristics with fluent and accurate
response right across the frequency range.
Whispered or shouted, on-screen
dialogue and vocals become transparently
clear, subtly nuanced and as perfectly
located as the speakers themselves.
Features and Benefits:
Purpose built for flush mounting into
ceilings the
Ci3-80QT is
the latest addition
to the KEF Uni-Q Custom Installation
series.
The 3-way, Ci3-80QT combines
100W power handling and 87dB sensitivity
and
consists of a polypropylene cone LF
driver with the HF unit mounted between
two matched size LF units.
Will require an additional 12 volt supply.
The bezel and grill can be painted to match
the interior décor.
KEF Audio (UK), Eccleston Road,T
ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com
KEF America, 10
Timber Lane,Marlboro,New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com
GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de
Information Sheet
Polar graphs
Directivity Index / Beamwidth
Frequency / Power response, Input impedance
Specifications
Installation
Architectural specifications:
The
Ci3-80QT
comprises a Uni-Q®array
with a
coincident mounted, twin
neodymium magnet, 15mm (3⁄5”) aluminium
dome,high-frequency unit
,a 75mm
polypropylene midrange unit and two
75mm bass drivers. Performance should
meet or exceed the following criteria:
frequency response 1 metre on-axis with
swept sinewave shall be 87Hz to 27kHz,
sensitivity shall be at least 87dB for
2.83V@1m. The impedance and maximum
power shall be 100W at 8 ohms. The
Ci3-
80QT
is best suited for high quality music
and home theatre applications where hi-fi
performance is required, such as:
· Multi Room systems.
· Home Theatre systems.
· Boardrooms & Offices.
· Hotels.
Frequency range 87Hz - 27kHz
Sensitivity (2.83v @ 1m) 87dB
Rec. amplifier power 10 - 100W
Nominal Impedance 8Ω(min. 3.2Ω)
Crossover Frequency 300Hz - 3kHz
Enclosure material Steel
Terminals terminal blocks up to Ø2.5 mm (0.1”)
conductor
Dimensions (H x W x D) 377 x 127 x 122 mm, 14.8 x 5 x 4.8 in.
Net weight 3.14kg (6.9lbs)
500Hz 1kHz
2kHz 4kHz
8kHz 16kHz
PL1616EN
1
3
5
2
4
6
