KEF CI160.2QR Manual

These are the Ci160.2QS and Ci160.2QR.

Like KEF’s smaller version Ci130QS/QR

these share the same Uni-Q®driver array

technologythat provides your living space

with an expansive soundscape, excellent

bass extension thus creating the perfect

sound stage.

You have the versatility of either placing

square speakers in the walls or round

speakers in the ceiling and, thanks to KEF’s

simple and ingenious screw down clamping

system, you’ll also find them easy and quick

to install.

Designed with moisture-resistant fixings

allowing placement in the harshest

environments such as bathrooms or even

outside (under eaves).

The Ci160.2QS and Ci160.2QR give

genuine performance - and great value.

Features and Benefits:

The 2-way Ci160.2QS and Ci160.2QR

combine 100W power handling and 89dB

sensitivity, for a maximum output of 108dB.

A160mm (61⁄2”) polypropylene cone

bass/mid unit with a coincident mounted

19mm (3⁄4”) soft dome, ferrofluid cooled

high-frequency unit gives superb off-axis

dispersion characteristics.

The bezel and grille can be painted or

covered by fabric to match the interior décor.

KEF Audio (UK), Eccleston Road,T

ovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com

KEF America, 10 Timber Lane,Marlboro,New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com

GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de

Information Sheet

Polar graphs

Directivity Index / Beamwidth

Frequency / Power response, Input impedance

Specifications

Installation

Architectural specifications:

The Ci Series Ci160.2QS and Ci160.2QR

comprise a Uni-Q®coincident mounted

19mm soft dome ferrofluid cooled

tweeter with 160mm white polypropylene

bass/mid unit. Performance should meet

or exceed the following criteria: frequency

response 1 metre on-axis with swept

sinewave shall be 60Hz to 20kHz,

sensitivity shall be at least 89dB for

2.83V@1m. The impedance and maximum

power shall be 100W at 8 ohms. The Ci

Series Ci160.2QS and Ci160.2QR is best

suited where high quality music and speech

reinforcement applications require hi-fi

performance such as:

·Multi Room systems.

·Home Theatre systems.

·Lounges, Bars, Boutiques.

·Boardrooms & Offices.

·Airports, Convention Centres, Hotels.

·Live Theatre/Concert Hall fill-in.

·Houses of Worship.

·Sports Arenas.

Frequency range 60Hz - 20kHz

Sensitivity (2.83v @ 1m) 89dB

Rec. amplifier power 10 - 100W

Nominal Impedance 8Ω(min. 3.7Ω)

Crossover Frequency 2.8kHz

Enclosurematerial N/A

Terminals spring terminals up to Ø2.5mm (0.1”)

conductor

Dimensions (H x W x D)

220 x 220 x 93 mm, 8.66 x 8.66 x 3.66 in. QS

Ø220 x 93 mm, 8.66 x 3.66 in. QR

Net weight 1.5kg (3.3lbs) QS, 1.4kg (3.08lbs) QR

500Hz 1kHz

2kHz 4kHz

8kHz 16kHz

PL1598EN

1

3

2

4

56
