KEF T101c Manual de usuario
Model T101 / T101c T301 / T301c T-2
Design Two-way closed box Two and a half-way closed box Closed box powered subwoofer
Drive units 115mm (4.5in.) dual layer MF
25mm (1in.) aluminium HF
2 x 115mm (4.5in.) dual layer MF
25mm (1in.) aluminium HF
1 x 250mm (10in.)
Frequency response 80Hz - 30kHz 80Hz - 30kHz 30Hz - 250Hz
Crossover frequency 1.7kHz 1.7kHz N/A
Amplier N/A N/A 250 Watts built-in Class-D
Amplier requirements 10 - 100 W 10 - 150 W N/A
Sensitivity (2.83V/1m) 90dB (wall mount)
87dB (oor stand mount)
91dB (wall mount)
88dB (oor stand mount)
N/A
N/A
Maximum output (SPL) 107dB 110dB 110dB
Impedance 8Ω8ΩN/A
Low pass lter variable N/A N/A Fixed 250Hz, 2nd-order
Low level signal inputs N/A N/A RCA phono socket
Internal volume 0.7 Litres 1.4 Litres 12.7 Litres
Power requirements N/A N/A 100 - 240V ac ~ 50/60Hz
Power consumption N/A N/A 250VA
Weight 1kg (2.2lbs) 1.5kg (3.3lbs) 13kg (28.6lbs)
Dimensions
(H x W x D)
330* x 140 x 35 mm
(13.0 x 5.5 x 1.4 in.)
600* x 140 x 35 mm
(23.6 x 5.5 x 1.4 in.)
380 x 370 x 177 mm
(15.0 x 14.6 x 7.0 in.)
Dimensions
(H x W x D) center mode
140 x 330 x 35 mm
(5.5 x 13.0 x 1.4 in.)
140 x 600 x 35 mm
(5.5 x 23.6 x 1.4 in.)
N/A
N/A
Finish Black Black Black
