Kaysun KC-01 S Manual de usuario
IMPORTANT NOTE:
Thank you very much for purchasing our product. Before using your unit, please
read this manual carefully and keep it for future reference.
KC-01 S
OWNER’S MANUAL
Wired Controller
• This manual gives detailed description of the precautions that should be brought to your
attention during operation.
• In order to ensure correct service of the wired controller please read this manual carefully
before using the unit.
• For convenience of future reference, keep this manual after reading it.
• The wired controller will reset to factory setting with auto mode, auto fan and 24°C(76°F)
setting temperature when the air conditioner restarts after power failure.
• And this may cause inconsistent displays on the wired controller and on the air
conditioner. You need to readjust the running status through the wired controller.
CONTENTS
1. SAFETY PRECAUTION
2. SUMMARIZE
3. FUNCTION SUMMARY
4. NAME AND FUNCTION OF INDICATORS
ON THE WIRE CONTROLLER
5. INSTALLATION METHOD.
6. NAME AND OPERATION OF THE BUTTON
ON THE WIRE CONTROLLER
7. USING METHOD
Automatic operation
Cooling/heating/fan only operation
Dry operation
Timer setting
Timer on and timer off both
Change timer
Methods of indoor unit address setting and query
Auto-restart
8. TECHNICAL INDICATION AND REQUIREMENT
................................................................ 1
................................................................ 2
................................................................ 2
................................................................ 3
................................................................ 4
................................................................ 5
................................................................ 8
................................................................ 8
..................................... 8
................................................................ 9
................................................................ 9
...................................................... 9
................................................................ 10
...... 10
.................................................. 10
........................................... 11
1
• Identier description
Identier Meaning
Warning Means improper handling may lead to personal injury or
property loss.
Caution Means improper handling may lead to personal severe
injury.
[Note]:
1. “Harm” means injury, burn and electric shock which need long-term treatment but need no
hospitalization
2. “Property loss” means loss of properties and materials.
• Icon description
Identier Meaning
It indicates forbidding. The forbidden subject-matter is indicated in
the icon or by images or characters aside.
It indicates compulsory implementation. The compulsory subject-
matter is indicated in the icon or by images or characters aside.
1. SAFETY PRECAUTIONS
The following contents are stated on the product and the operation manual, including usage,
precautions against personal harm and property loss, and the methods of using the product
correctly and safely. After fully understanding the following contents (identiers and icons), read
the text body and observe the following rules.
2
Warning
Warning
Delegate
installation
Please entrust the distributor or
professionals to install the unit. The
installers must have the relevant know-
how. Improper installation performed by
the user without perm ission may cause
re, electric,shock, personal injury or water
leakage.
Usage
Warning
Forbid Do not spray ammable aerosol to the wire controller
directly. Otherwise, re may occur.
Forbid Do not operate with wet hands or let water enter the wire
controller. Otherwise, electric shock may occur.
Usage condition:
1. Power supply: 5V DC.
2. Operation temperature:
-5°C(23°F)~ +43°C(+109°F).
3. Operation humidity: 40%-90%, RH
Main function:
1. Connecting to indoor unit by A, B, C, D, E termina.;
2. Button setting action mode.
3. LCD display.
4. Timer for rest time.
2. SUMMARIZE
3. FUNCTION SUMMARY
3
4. NAME AND FUCTION OF INDICATORS ON THE CONTROLLER
1. Operation mode indication 3. Follow me function
4. ON / OFF
indication
5. Fan speed
indication
6. Lock
7. Temperature
display zone
2. Timer ON / OFF
1. Operation mode indication:
When press “ MODE “ button, the follow- ing mode can be selected in circle.
Auto → Cool → Dry → Heat → Fan only → Auto.
For cooling only model,heat mode is skipped.
2. Timer:
When adjust setting on time or only on time is set, the “ON” is lighted.
When adjust setting off time or only off time is set , the “OFF” is lighted. If on and off timer are
both set, the”ON” and “OFF”are both lighted.
3. Follow me function:
There is a temperature sensor inside the wire controller, after setting temperature, it will
compare the two temperatures, and the space of wire controller will be the same as setting
temperature. It is available under cooling, heating, auto mode.
4
4. ON/OFF indication:
When it is on, the icon display, otherwise it is extinguished.
5. Fan speed indication:
There are four fan modes: low, middle, high, auto.
For some models, no middle fan then the middle fan is seen as high speed.
6. Lock:
When the “ LOCK “ button is pressed, the icon appear and other buttons is
unable, press again, the icon disappear.
7. Temperature display zone:
Generally it displays setting tempera- ture, it can be adjusted by press temperature button ▲
and ▼. But in fan mode, no display here.
5. INSTALLATION METHOD
wire controller
5
When a wire controller is needed, a small 5-way terminal should be added,x an infrared emitter
with gumwater near the receiver on the switch board. Connect its anode and cathode to A and
B,and +5V, GND, RUN to C, D, E on the switch board.
NOTE
All the pictures in this manual are for explanation purpose only. There may be slightly different
from the wire controller you purchased(depend on model). The actual shape shall prevail.
6. NAME AND OPERATION OF THE BUTTON ON THE WIRE CONTROLLER
MODE BUTTON
TIMER ON BUTTON
TIMER OFF BUTTON
FOLLOW ME BUTTON
RESET BUTTON
ELECTRICAL HEATER
BUTTON
ON / OFF BUTTON
ADJUST BUTTON ▲
ADJUST BUTTON ▼
SWING BUTTON
SLEEP BUTTON
FAN SPEED BUTTON
LOCK BUTTON
6
Mode botton:
When press this botton,the operation mode change as the following sequence:
Remark: For the cooling only model, the heating mode is skipped.
Timer on button:
Press this button, timer on function is active. Then every press, the time increase 0.5h,
after 10h, 1h increasement after each press. If cancel this Function,just set it to “0.0” .
Timer off button:
Press this button, timer off function is active.Then every press, the time increase 0.5h, after 10h,
1h increasement after each press. If cancel this function, just set it to “0.0” .
Follow me button / I-FEEL button:
When under cool, heat and auto mode, press this button, follow me function is active. Press
again, this function is ineffective.
Auxil heater button/Heater button:
If press this button in heat mode, electri- cal heater function become ineffective(it may be
ineffective for some models).
Reset button(hidden):
Use a 1mm stick to press in the little hole , then the current setting is canceled . The wire
controller enter into original state.
ON/OFF button:
When in off state, press this button, the indicator is on, the wire controller enter into on state,
and send setting information to in door Pcb. When in on state,press this button, the indicator
is off, and send instruction. If timer on or timer off has been set, it cancel this setting then send
instruction to stop the machine.
Adjust button ▲:
Set indoor temperature up. If press and hold on, it will increase at 1°C(2°F) per
0.5 second.
Adjust button ▼:
Set indoor temperature down . if press and hold on,it will decrease at 1°C(2°F) per 0.5 second.
7
Swing button:
First press, start swing function;second press, stop swing. (Match to some model with swing
function).
ECO button / Sleep button:
Press this button, the indoor unit operates in economy mode, press again, exit this mode (it may
be ineffective for some models).
Fan speed button:
Press this button consecutively, the fan speed will circle as follow:
Lock button(hidden):
When you push the LOCK button, all current settings are locked in and the wire controller does
not accept any operation except that of the LOCK button. Use the lock mode when you want to
prevent setting from being changed accidentally or play fully. Push the LOCK button again when
you want to cancel the LOCK mode.
Auto Low Middle High
