Kane 455 Manual de usuario

KANE455

Quick Reference Guide

Infra-red emitter and torch light

Menu controls ~ Scroll up/down

Enter

Function buttons x 4

(See below for details)

Rotary switch

Particle filter

Water trap

“Battery charging” indicator

Analyser Connections Flue Gas Inlet

(see diagram overleaf) (see diagram overleaf)

ON / OFF

Turns the analyser ON / OFF

BACKLIGHT

Switches backlight & torch light

ON / OFF

PUMP

Turns the pump ON / OFF

Hold button to zero pressure

SEND / ENTER

Send readings to printer

(Press button for 1 second.)

Send readings to memory

(Hold button down for 2+ secs.)

Stock No. 18839-2 July 2014

Battery charger

connection

Flue Gas Inlet

Watertrap Drain

with Red Screw

Plug

Flue probe temperature (T1)

Inlet temperature (T2)

Pressure connection

P2 (differential)

Fit Spigot to Hose before

connecting to Analyser

1. BEFORE USING ANALYSER CHECK THE FOLLOWING:

Particle filter is not dirty inside

Water trap and flue probe hose are empty of water

Water trap and red screw plug are fitted correctly to the analyser

Flue probe hose is connected properly to the flue gas inlet

Flue probe temperature plug is connected into T1 temperature connection

Please read the Safety Warnings in the User Manual

2. FRESH AIR PURGE

Position the flue probe in fresh air, then press the “On/Off” button. The analyser auto-

calibrates for approximately 90 seconds. When complete…

Select “Ratio” on the dial. In fresh air the CO reading = 0ppm

Select “O2/Eff” on the dial. In fresh air the O2 reading = 20.9%

Select “Status” on the dial to view the following…

STATUS display

BAT 59

11 : 46 : 29

15 / 05 / 08

CAL 283

- Battery status. If less than 20 recharge or replace, (see section 10)

- Current time. Can be set via the “Menu”, (see section 11)

- Current date. Can be set via the “Menu”, (see section 11)

- Number of days until next check and calibration is required

Note: Boiler inlet air temperature can either be…

a) Set automatically by the flue probe during the fresh air purge

or b) Continuously measured if a thermocouple is plugged into the T2 socket

3. COMBUSTION TESTS

Select “Ratio” on the dial to check that the analyser is set for the correct fuel. To change

fuel select MENU / SETUP / SET FUEL then use scroll and enter, (see section 11).

Position the flue probe as per the boiler manufacturer’s instructions; typically the tip of

the flue probe is inserted to the centre of the flue. The readings will stabilise after 60

seconds assuming the boiler conditions are stable.

The rotary switch can be used to display the following information…

RATIO display

NAT GAS

R 0.0001

COP 12

CO2% 8.8

- Fuel type can be changed via “Menu”, (see section 11)

- CO/CO2 ratio

- Carbon Monoxide, (ppm)

- Carbon Dioxide, (%)

Press SEND to print a full combustion test. (Also sends to PC if Wireless module fitted).

Hold SEND for 2+ seconds to log a full combustion report.

O2/EFF display

O2% 5.4

TFC 55.1

TIC 17.2

EfC% 98.3

- Oxygen left after combustion. Should be 20.9% in fresh air.

- Flue temperature, (C)

- Inlet temperature. Normally set by flue probe during fresh air purge.

- Condensing boiler efficiency (EfC). Can be changed via “Menu”

Press SEND to print a full combustion test. (Also sends to PC if Wireless module fitted).

Hold SEND for 2+ seconds to log a full combustion report.

AUX display

O2% 20.9

COP 00

11 : 55 : 02

BAT 59

- The default AUX (auxiliary) display is shown

The parameters on lines 1, 2, 3 and 4 can be set independently

To customise the AUX display select MENU / SCREEN / AUX.

They remain the AUX parameters until changed again by the user.

Press SEND to print a full combustion test. (Also sends to PC if Wireless module fitted).

Hold SEND for 2+ seconds to log a full combustion report.

4. PRESSURE TEST (Also see section 9)

Select “Prs”. The pump stops. Press the PUMP button to auto-zero the pressure sensor.

Using the black connectors and manometer hose connect to P1 for single pressure or P1

and P2 for differential pressure.

PRS display

PRESSURE

P -0.04

mbar

12 : 56 : 29

- Defaults to smoothing ‘off’ on start-up. Can be changed via “Menu”.

- Defaults to ‘low’ resolution on start-up. Can be changed via “Menu”.

- Pressure units can be changed via “Menu”.

- Displays time to enable manually timed tests.

Press SEND to print a pressure test. (Also sends to PC if Wireless module fitted).

Hold SEND for 2+ seconds to log a pressure report.

5. LET-BY and TIGHTNESS TESTING (Also see section 9)

Select “Tightness”. The pump stops. Press the PUMP button to auto-zero the pressure

sensor. Select “yes” or “no” for the let-by test by using  or , then press . Connect

from the test point to P1 using a black connector and manometer hose. Adjust the gas

pressure as you would with a “U” tube manometer. Press to start either the let-by

test or the stabilisation period…

LET BY

P1 10.35

P2 10.35

TIME 59

- Let-by test display.

- Pressure at the start of the let-by test

- Real time pressure reading

- Let-by default time is 1 minute. Can be changed via “Menu”.

When complete adjust the gas pressure if necessary then press to start the

stabilisation period…

STABIL’N

P1 20.00

mbar

TIME 59

- Stabilisation display.

- Real time pressure reading

- Stabilisation default time is 1 minute. Can be changed via “Menu”.

When complete adjust the gas pressure if necessary then press to start the tightness

test…

TIGHTN’S

P1 20.33

P2 20.33

TIME 119

- Tightness test display.

- Pressure at start of tightness test

- Real time pressure reading

- Tightness default time is 2 minute. Can be changed via “Menu”.

When complete the display will show…

LOG 06

P1 20.33

P2 20.26

PRINT 

- Let-by and tightness test are automatically stored as a log number

- Pressure at start of tightness test

- Pressure at end of tightness test

- The test can be printed immediately or later from the memory

Note: The analyser’s memory can store up to 20 tightness tests. Tightness tests are logged

automatically therefore the tightness section of the memory will be full after the 20th

tightness test is complete. Before the 21st tightness test can be performed the

tightness section of the memory must be cleared. To do this select MENU / REPORT /

TIGHTN’S / DEL ALL / YES then press .

6. DIFFERENTIAL TEMPERATURE

Select “Diff Temp” to measure flow, return and differential temperatures

DIFF TEMP display

TEMP

T1C 60.1

T2C 47.0

TC 13.1

- Pump automatically switches off when dial is moved to Diff Temp

- Use the T1 connection for the flow temperature sensor

- Use the T2 connection for the return temperature sensor

- Real time temperature difference

Press SEND to print a differential temperature test. (Also sends to PC if Wireless module

fitted).

Hold SEND for 2+ seconds to log a differential temperature report.

7. ROOM CO TESTING

Select “Room CO” for CO investigations. Please refer to user manual.

ROOM CO display

ROOM CO

COP 00

TEST 14

LOG 01

- Duration of this test is variable from 0 to 30 minutes as per BS7967

- Real time CO reading, (ppm)

- Test 00 = start. To stop the Room CO test press the PUMP button

- The complete Room CO test is automatically stored as a log number

8. OTHER DISPLAY CODES

-PO- = Pump Off

-OC- = Open Circuit on temperature input

9. FOR BEST PRESSURE SENSOR ACCURACY

1) Switch the analyser on for 5 minutes to let the temperature stabilise.

2) Zero the pressure sensor when the analyser in the exact position that it will be

used.

10. TO FULLY CHARGE NiMH RECHARGEABLE BATTERIES

1) The analyser must be switched on.

2) Connect the charger and switched it on; charging indicator illuminates.

3) Switch the analyser off; the display will show “BATTERY CHARGING”.

4) The BAT status number of fully charged NiMH batteries is typically 70+

11. USING THE MENU

Select “Menu” on the rotary switch and navigate using the function buttons…

 = Scroll up  = Scroll down

= Enter

MAIN MENU SUB MENU OPTIONS / COMMENTS

SETUP SET FUEL NAT GAS, L OIL (28/35 sec), PROPANE, BUTANE, LPG, PELLETS

(Wood)

N  C  G EfN = nett efficiency, EfG = gross efficiency, EfC = condensing efficiency

SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00

SET DATE Uses DD-MM-YY format

PRESSURE SMOOTH OFF = normal response. ON = slower (damped) response

RESOLVE LOW = normal. HIGH = displays to an extra decimal place

PS UNITS mbar, mmH2O, Pa, kPa, PSI, mmHg, hPa, InH2O

TIMES

LET-BY = Set duration of let-by test in minutes. Default = 1 minute

STABIL’N = Set duration of stabilisation in minutes. Default = 1 minute

TIGHTN’S = Set duration of tightness test in minutes. Default = 2 minute

REPORT COMB’N Stored combustion tests, VIEW, DEL ALL or EXIT (max = 99 tests)

PRESSURE Stored pressure tests, VIEW, DEL ALL or EXIT (max = 20 tests)

TIGHTN’S Stored let-by and tightness tests, VIEW, DEL ALL or EXIT, (20 tests)

TEMP Stored differential temperature tests, VIEW, DEL ALL or EXIT (20 tests)

ROOM CO Stored room CO tests, VIEW, DEL ALL or EXIT (max = 20 tests)

SCREEN CONTRAST Factory setting is 04

AUX Enables users to customise the parameters on the AUX display

User can set any parameter on lines 1, 2, 3 and 4

HEADER Sets printout header, 2 lines, 20 characters per line

SERVICE CODE Password protected for authorised service agents. Leave set to 0000.

To EXIT EACH Sub MENU select EXIT.

To EXIT the MENU move the rotary switch to any position other than “Menu”.

Any changes that have not been “entered” will be ignored.

12. Printouts

KANE455 V 1.00B

YOUR COMPANY NAME &

PHONE NUMBER HERE

SERIAL NO. 000000000

KANE455 V 1.00B

YOUR COMPANY NAME &

PHONE NUMBER HERE

SERIAL NO. 000000000

KANE455 V 1.00B

YOUR COMPANY NAME &

PHONE NUMBER HERE

SERIAL NO. 000000000

DATE 01/07/14 PRESSURE DIFF TEMP

TIME 12:00:08

DATE 01/07/14 DATE 01.07/14

COMBUSTION TIME 12:00:08 TIME 12:00:08

FUEL NAT GAS PRS mbar -0.037 T1

C 60.1

O2 % 5.4 T2

C 47.0

CO2 % 8.8 ∆T

C 13.1

CO Ppm 12 Customer

FLUE

C 55.1

INLT

C 17.2 Appliance Customer

NETT

C 37.9

Ref. Appliance

EFF (C) 98.3

LOSSES 1.7 Ref.

XAIR % 34.8

-----------------------------------------------------

C a l . d u e o n 0 1 / 0 7 / 1 5

----------------------------------------------------- KANE455 V 1.00B

YOUR COMPANY NAME &

PHONE NUMBER HERE

SERIAL NO. 000000000

CO/CO2 0.0001

KANE455 V 1.00B

YOUR COMPANY NAME &

PHONE NUMBER HERE

SERIAL NO. 000000000

PRS mbar 0.00

Customer ROOM CO TEST

Appliance LOG 01 LOG 04

DATE 01/07/14 DATE 01/07/14

Ref. TIME 12:00:08 TIME 12:00:08

TEST CO ppm LET BY TEST

1 PRS-1 mbar 10.12

2 PRS-2 mbar 10.11

3 LET-BY MINS 1:00

5 TIGHTNESS TEST

7 PRS-1 mbar 20.12

8 PRS-2 mbar 20.10

9 ∆PRS mbar -0.02

STABIL’N

MINS

1:00

TIGHTN’S MINS 2:00

MAXIMUM CO 11

Customer

Appliance

Ref.

PRODUCT REGISTRATION

Please complete, detach and return to: Kane International Ltd

Kane House, Swallowfield, Welwyn Garden City, Hertfordshire, AL7 1JG

Your Details

Name:

Job Title:

Company Name:

Company Address 1:

Address 2:

Town/City:

County:

Postcode:

Country:

Phone Number:

Fax Number:

Mobile Number:

Email Address:

Product Details

Note: Proof of Purchase may be required for warranty claims.

Date Purchased:

as numbers (28.01.14):

Purchased From:

Model Number: KANE455

Product Serial Number:

located on the rear product label

beneath the protective rubber sleeve

Why did you buy a Kane Product?

 Made in the UK  Previous Owner

 Value for Money  Our Fixed Price Servicing Programme

 Kane Brand  Dealer Recommendation

 Not your Decision  Other:

What brand was your previous analyser?

How did you hear about Kane?

 Magazine Advert  Trade Counter

 Training School  Previous Owner

 Personal Recommendation  Internet Search

 Exhibition  Other:

Which do you read most often?

Often Sometimes Hardly Ever

Registered Gas Engineer   

Gas Installer   

P.H.P.I.   

P.H.A.M. News   

Heating Ventilating & Plumbing   

Heating & Plumbing Monthly   

Your feedback is important to us, please add any additional comments

you would like to make with regard to your recent Kane purchase:

Thank you for completing this survey.

All the information we have collected is confidential.

We do not sell or share data with any other company or organisation.

Otros manuales para 455

Tabla de contenidos

Otros manuales de Instrumento de medición de Kane

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
