Kambrook KFH29 Manual de usuario

Upright Fan Heater

KFH29/30/31 Issue 1/03

1. 2heat settings plus fan only

2. Clear control cover

3. Thermostat control (KFH31 & KFH29 only)

4. Neon light indicator

5. Safety tip-over cut-out switch

6. Oscillating switch (KFH29 only)

BEFORE USINGYOUR UPRIGHT

FAN HEATER, PLEASE READ

THESE INSTRUCTIONS

CAREFULLY AND RETAIN

FOR FUTURE REFERENCE.

KNOWYOUR KAMBROOK UPRIGHT FAN HEATER

(KFH29 Pictured)

IMPORTANT PRECAUTIONS

When using electrical appliances,

basic precautions should always be

followed to reduce the risk of fire,

electric shock and injury to persons,

including the following:

1.Avoid touching heater body while it is

on, some parts of the heater are hot.

When moving the unit switch off and hold

heater by the handles where provided.

2. Keep combustible materials such as

drapes and other furnishings at least 1.7

metres from the front, sides and rear of

the heater. Do not use heater to dry your

laundry. Do not cover the heater whilst it

is operating.

3. Extreme caution and supervision is

necessary when this heater is used by or

near children, invalids or animals.

4.Young children should be supervised to

ensurethey do not play or operate

the heater.

5. Important – this heater is intended for

floor use only. Do not mount on ceiling

or walls.

6. Do not leave heater unattended.

Always switch off the heater at the

controls and at the power outlet then

unplug heater from the power outlet

when not in use.

7. Do not operate heater whilst asleep.

8. Do not operate any heater with a

damaged cord or plug, or if heater has

been dropped or damaged in any manner.

Return the heater to your nearest service

centre for examination, electrical or

mechanical adjustment or repair.

9. Do not use outdoors.This heater is not

intended for commercial use, such as

contruction sites.

10. Do not locate the heater immediately

below a socket outlet when in use.

11. Do not use this heater with a

programmer, timer or any other device

that switches the heater on automatically,

since a firerisk may exist if the heater is

covered or positioned incorrectly.

12.This heater is not intended for use in

wet or moist locations such as bathrooms

or laundry areas. Do not immerse or

allow liquids to be spilt on heater.

13.This heater has hot and arcing or

sparking parts inside. Do not use in areas

where petrol, paints, aerosols, or other

inflammable substances are used or

stored.

14. Do not operate heater with the cord

hanked or wound around any part of the

heater, or in contact with heated surfaces

of the heater.

15. Do not run the power cord under

carpeting or cover the cord with rugs,

runners or the like.Arrange cord away

from traffic areas and where it will not

be tripped over.

16.Todisconnect the heater turn the

control to OFF then switch off at the

power outlet then removeplug from its

outlet.

17. Do not insert or allow foreign objects

to pass through the inlet or outlet

openings, this may cause an electric shock,

fire or damage the heater.

18.To prevent a possible fire or heat

damage, allow ample space around the

heater (at least1.7m at front and 0.5m at

the rear, top and sides) and do not totally

or partially block air inlets or outlets in

any manner. Check the openings from

time to time for accumulated dust. Ensure

long shag carpet does not obstruct airflow

under the unit.

19. Do not touch hot metal surfaces.

20. Switch off at the control switch and

power outlet, then unplug and allow

heater to cool down before cleaning

or storing.

21. Use this heater only as described in

this instruction manual.Anyother use not

recommended bythe manufacturer may

cause fire, heat damage, electric shock or

injuryand voids all warranties.

22. Regularly inspect the supply cord, plug,

control settings, air inlets and outlets and

main housing for any damage. If found

damaged in any way, immediately cease

use of the heater and return to

Kambrook or an authorized service

agent for inspection.

23.The installation of a residual current

device (safety switch) is recommended to

provide additional safety protection when

using electrical appliances. It is advisable

that a safety switch with a rated residual

operating current not exceeding 30mA be

installed in the electrical circuit. See your

electrician for professional advice.

HOW TO OPERATE

1. Remove your heater from its carton

and associated protective wrapping,

unwind the cord to its full length and

remove any protective cardboard or foam

that may have been used to minimise

transportation damage.

2. Place the heater on a firm, level surface

in a stable upright position.

3.Visually inspect the air inlet and outlets

to ensure no foreign material is blocking

these areas.

4. Make certain the selector knob is

turned to OFF “O” and the temperature

knob to HIGH (KFH29 and KFH31 only).

5. Plug the power cord in a 230-240Volt

power outlet.To avoid an electrical circuit

overload, it is recommended that no

other appliances are plugged into the

same circuit with your heater when you

switch the unit on.

6. Control the heater with the selector

knob and temperature knob, as follows:

The selector knob has 4 settings:

O Shuts off both heater and fan

*Turns fan on and gives cool air

1 Gives warm air with half

heating power

2 Gives hot air with maximum

heating power

For KFH29 and KFH31:The temperature

knob acts as an automatic thermostat:

• Turn both selector and temperature

knobs to high

• Once a comfortable room temperature

has been reached, slowly turn

temperature knob anti-clockwise until

you hear a click.

• At this setting your heater will

automatically cycle high and low to

maintain the desired room temperature

• For KFH29 only: Set the Oscillating

switch to ON, the heater will oscillate

400to each side.

Note:There is a tip over switch on the

base of the heater.When the heater tips

over, it will turn off automatically.

Overheating Safety device

Your heater is fitted with a safety device

that switches off the heater in the event

of overheating. Should the heater stop

working, turn the heater off and inspect

for blockage of air inlet or outlet.Wait at

least 5 minutes for the protection system

to reset beforeattempting to restartthe

heater.

If the heater fails to operate or the safety

device switches the heater off again,

return the heater to your nearest service

centre for examination or repair.

CARE AND MAINTENANCE

• Always turn off and then unplug the

heater before cleaning.

• Use only a clean, dry cloth to clean the

external surfaces of the heater only.

•If the heater has collected dust or dirt

inside the unit or around the element,

have the unit cleaned by a qualified

service agent. Do not operate the heater

in this condition.

•Do not attempt to open the case of the

heater at anytime, there are no

customer serviceable parts inside.

•When not in use, pack the heater,

preferably in its original box for best

protection, and store in a cool, clean

and dry location.

•Under normal operation in a dark

environment it may be possible to

see the heating element turn a dull

red during operation. This is a

normal operation.

Notes:

KAMBROOK

12 MONTH

WARRANTY

KAMBROOK warrants the purchaser

against defects in workmanship and

material, for a period of 12 months

from the date of purchase (3 months

commercial use).

Guarantee and purchase receipt for this

product are to be retained as proof of

purchase and must be presented if making

aclaim under the terms of the

KAMBROOK guarantee.

KAMBROOK reserves the right to

replace or repair the appliance within

the warranty period.

Warranty does not apply to any defect,

deterioration, loss or injury or damage

occasioned by, or as a result of the misuse

or abuse, negligent handling or if the product

has not been used in accordance with the

instructions.The guarantee excludes

breakages and consumable.

This warranty is void if there is evidence

of the product being tampered with by

unauthorised persons.

If the product includes one or a number

of accessories only the defective accessory

or product will be replaced.

In Australia, this KAMBROOK Guarantee

is additional to the conditions and

guarantees which are mandatory as

implied by the Trade Practices Act 1974

and State Territory legislation.

For service, spare parts or product

information in Australia, please call

KAMBROOK on the Customer Service

Line (free call) 1800 800 634.

For service, spare parts or product

information in New Zealand, please

call KAMBROOK New Zealand,

Greenmount, Auckland Phone 09 2713980

Fax 0800 288 513. For spare parts phone

09 2713980.

If claiming under this guarantee the product

must be returned freight prepaid.

YOUR PURCHASE RECORD (Please complete)

DATE OF PURCHASE______________________________________________________

MODEL NUMBER ________________________________________________________

SERIAL NUMBER (If applicable) ______________________________________________

PURCHASED FROM ______________________________________________________

Attach a copyof purchase

receipt here.

Please don’t return purchase record

unless you are making a claim

Kambrook 4Kingston Town Close Oakleigh,Victoria 3166,Australia

Customer Service Line (free call) 1800 800 634 Customer Service Fax 1800 621 337

Kambrook New Zealand, Private Bag 94411, Greenmount, Auckland, New Zealand

Customer Service Line/Spare Parts 09 2713980 Customer Service Fax 0800 288 513

Due to continual improvement in design or otherwise,the product you purchase may differ slightly from the one illustrated in this book. Issue 1/03

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Kambrook

Kambrook

Kambrook SNUGASABUG KFH280 Manual de usuario

Kambrook

Kambrook SLIMLINE SILENT KPH200 Manual de usuario

Kambrook

Kambrook CARBON KCF200 Manual de usuario

Kambrook

Kambrook KFH310 Manual de usuario

Kambrook

Kambrook KFH500 Manual de usuario

Kambrook

Kambrook KCE85 Manual de usuario

Kambrook

Kambrook KFH540 Manual de usuario

Kambrook

Kambrook KCE340 Manual de usuario

Kambrook

Kambrook KCE42 Manual de usuario

Kambrook

Kambrook KRH110 Manual de usuario

Kambrook

Kambrook KCE75 Manual de usuario

Kambrook

Kambrook KRH200 Manual de usuario

Kambrook

Kambrook THERMO GUARD KFH15 Manual de usuario

Kambrook

Kambrook KFH700 Manual de usuario

Kambrook

Kambrook KCE95 Manual de usuario

Kambrook

Kambrook SNUGASABUG FAN HEATER KFH20 Manual de usuario

Kambrook

Kambrook KFH210 Manual de usuario

Kambrook

Kambrook CERAMIC KCE440 Manual de usuario

Kambrook

Kambrook KFH340 Manual de usuario

Kambrook

Kambrook KRH110 Manual de usuario

Kambrook

Kambrook CERAMIC KCE640 Manual de usuario

Kambrook

Kambrook KFH520 Manual de usuario

Kambrook

Kambrook Suits KFH600 Manual de usuario

Kambrook

Kambrook KCE240 Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
