KAISER BAAS
CAMESCOPE ACTION
KB X650
ACTIONCAMERA
MANUEL D’UTILISATION
Visit kaiserbaas.com for more information
X650
Quick Start Guide
OVERVIEW
Before operating your
X650 please ensure you
have read and understood
the safety precautions
The X650 Action Camera has a
waterproof body to a 8m depth (with
doors securely closed/sealed). You
won’t need any additional waterproof
case unless you are going below 8m.
Please ensure you remove the plastic
protection lm from the front lens
and back screen before using.
GETTING STARTED
Charge your X650
Open the side door and connect your
camera to a USB charger or computer
using the included Micro-USB cable. To
open the side door, hold down the latch
release button on the side door and slide
it down. Whilst charging the red light will
appear. Once fully charged it will turn o.
Insert your SD Card
Once your camera is fully charged, insert the
Micro SD card into the SD card slot inside
the battery compartment at the bottom of
your Action Camera.
Note: Please ensure you format your SD card
before you start lming with it for the rst time.
2
1
01 - ENG
2
1
*SD Card not included
We recommend using a Class UHS 3 and
above Micro SD card up to 128GB for
maximum performance.
Format your SD Card before using
the camera for the rst time
Tap on the Settings icon (3) in the
bottom right corner of the screen.
Tap to select the Settings icon the left
of the screen. Scroll down the menu
until you get to Format SD Card. Tap
on Format SD Card. Tap on Conrm
to format your SD Card.
NOTE: This will clear all data on
the card and ensure it is ready for
recording. 4
4
GETTING STARTED 02 - ENG
3
Format SD Card
3
CAMERA SETTINGS
Using your Camera
To turn your camera on/o - hold the
Power button on the side of your X650 for
a few seconds.
Select from the following modes to
capture your footage by scrolling down on
the mode menu page: Video; Photo; Time
Lapse Video; Time Lapse Photo; Slow Mo;
Burst Mode; Self Timer; Photo & Video.
To access settings and change video/
image resolutions, tap the settings icon
on the screen.
To start recording video, press the Record
button on the top of your camera. To take
a photo, press the Record button once.
1
2
3
4
1
03 - ENG
32
4
Side View
Back View
Top View
CAMERA SETTINGS 04 - ENG
Switching between screens
To switch between the back and front
screen, rst ensure you are in camera
mode. Press and hold the Mode button
on top to switch between the front sele
screen or rear touch screen.
1
2
2
1
Top View
Top View
To use the front camera, simply frame the
shot and press the Record button.
Note: You will not be able to switch
between the front and back screens if the
settings or playback menu options are on
the screen.
REVIEWING YOUR FOOTAGE
Reviewing your footage
To review footage, tap the Playback
icon on the screen.
Scroll through the les to select and
review footage.
Click on the back button to return to
the main screen.
Main Menu Screen
Playback Menu
05 - ENG
2
2
3
3
1
1
Wi-Fi & KB APP
Connecting to the KB
Capture App
Turn on Wi-Fi on your camera by
swiping down on the screen and
then tapping the Wi-Fi icon.
Go to your Smartphone settings
and ensure your Wi-Fi is turned on.
Select KB-X650 network. The default
password is: 12345678.
If your connection fails, please close
down the App and relaunch it and
restart the camera.
06 - ENG
Visit www.kaiserbaas.com/support or email
the complete user guide, visit www.kaiserbaas.com
1
2
Scan these codes to access the KB-X650 App.
Wi-Fi
Wi-Fi
KB-X650
1
2
X650 Action Cam
14 Megapixels
Video Resolution Options
4K 30FPS (3840x2160) - Default
2.7K 30FPS (2704x1520)
1440P 60/30FPS (1920x1440)
1080P 90/60/30FPS (1920x1080)
720P 120/60/30FPS (1280x720)
Photo Resolution (Image Size)
16M, 14M, 12M, 8M, 5M, 3M
Storage
We recommend using a Class UHS 3
and above Micro SD card up to
128GB for maximum performance.
PRODUCT SPECIFICATIONS
1. Power Button
2. Record Button
3. Microphone
4. Mode Button
5. Battery Latch Release Button
6. Side Door Latch Release Button
7. Charging, Data Transfer and Mic Input port
07 - ENG
1
2
3
4
5
6
7
