K40 RL100 Manual de usuario
Register your K40 RL100 today to
activate your guarantees:
Guaranteed immunity from speeding tickets
If you get a speeding ticket within one year of purchase,
we’ll reimburse you for the full cost of the ticket.*
Guaranteed performance
If your K40 radar detection system does not outperform any
other radar detector you’ve owned, return it within 30 days
for a full product credit.
One year warranty
K40 offers a one-year “repair or replace” warranty if your
product fails to work properly.
*Offer not valid for speeding ticket violations incurred in school or
construction zones, or connected with a DUI.
Register your RL100 online today by visiting K40.com
Table of Contents
Mounting and Powering the RL100 . . . . . . . . . . . . . .4
Mounting Instructions. . . . . . . . . . . . . . . . . . . . 4
Power Connection. . . . . . . . . . . . . . . . . . . . . . . 4
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Receiving Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Radar Alert Sequence . . . . . . . . . . . . . . . . . . . .6
Laser Alert Sequence . . . . . . . . . . . . . . . . . . . . .7
Non-Police Alerts . . . . . . . . . . . . . . . . . . . . . . . .7
Special Features/Functions . . . . . . . . . . . . . . . . . . . 8-13
Filter Operation (Sensitivity) . . . . . . . . . . . . . . . . . .8
Quiet RideTM . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Reference Guide . . . . . . . . . . . . . . . . . . . .10-11
Mark Location . . . . . . . . . . . . . . . . . . . . . . . . .12
Mute Sounds . . . . . . . . . . . . . . . . . . . . . . .12-13
Speed Monitor . . . . . . . . . . . . . . . . . . . . . . . .13
Menu / Customizable Settings . . . . . . . . . . . . . . .14-15
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . .16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3
Mounting and Powering the RL100
Mounting Instructions
To help ensure that your RL100 functions properly and
offers maximum protection, please follow these mounting
instructions:
1. Clean the area of the windshield where the unit will
be mounted.*
2. Attach the supplied Windshield Mounting Bracket to
your car’s windshield by firmly pressing the suction cups
in the bracket to the windshield.
a. Mount the bracket as low as possible near
the center of the windshield.
b. Do not mount the unit behind wipers or any
metal obstructions.
3. Slide the RL100 unit itself on to the bracket to complete
the mounting.
4. Level the radar detector, if necessary, by carefully
bending the Windshield Mounting Bracket.
*IMPORTANT NOTE: Some windshields include a metallic coating that can
significantly affect reception of radar signals. Consult with your dealer or
check your vehicle’s owner‘s manual to determine if your windshield has
such a coating.
Power Connection
1. Plug the small end of the supplied Power Cord into the
Power Input Jack on the side of the radar detector.
2. Plug the large end of the Power Cord into your vehicle’s
cigarette lighter socket or other 12V outlet.
3. Switch on the RL100 by turning the Power On/Volume
Control Wheel located on left side of the unit.
No power? See Troubleshooting Guide on page 16.
4
Quick Start
(using factory default settings)
Once your K40 RL100 has been mounted and had the power
connected, you may begin using immediately by following
these steps:
1. Switch on the RL100 – Turn the Power On/Volume
Control Wheel on the side of the unit.
2. Wait for Test Scan to complete – The radar detector
will announce(voice) and display(screen) K40 SCAN then
go through a “wake up sequence” lasting approximately
5 seconds.
a. You will hear and see all bands tested. Adjust the
volume during this test.
b. Upon completion of the sequence scan, the screen
will display HIGHWAY .
c. After finding available satellites, the unit will announce
“GPS Connected” then display GPS .
3. You’re ready to drive! – The RL100 will now display
filter setting, your speed and direction of travel. For
example, if you are driving West at 57 mph and the filter
is on Highway setting, the display will show
H W 57
Please read the entire Owner’s Manual to fully understand
all of the RL100’s operations and functions.
5
Filter
HIGHWAY Travel
Direction
WEST
Speed
57mph
Receiving Alerts
The K40 RL100 provides a combination of audio and visual
alerts to warn you when radar and laser signals are detected.
Radar Alert Sequence
The RL100 detects every kind of FCC approved police radar.
When a signal is identified:
•A voice alerts which band was detected. (This assumes the
factory default “Voice ON” setting has not been changed.)
•A series of beeps indicates the strength of the signal. Each
band has its own distinctive beep. (Volume reduces
automatically after 5 seconds.)
•The display will provide you band and strength information.
Radar Alert Examples:
You are driving 45 mph and a low K-Band is detected.
Visual Alert: K 2 45
Audio Alert: Voice announces “K-Band” followed
by slow beeps.
As you approach the source, you slow to 40 mph and
the signal becomes stronger:
Visual Alert: K 8 40
Audio Alert: Beeping is faster due to stronger signal.
Radar source strength: low medium strong
Display reading: 123 456 789
Audio alert beeps: slowly rapidly
6
Laser Alert Sequence
When the RL100 detects a laser signal:
•A voice alerts announces “Laser.” (This assumes the factory
default “Voice ON” setting has not been changed.)
•You then hear a distinctive audio tone. (Volume reduces
automatically after 5 seconds.)
•Display indicates laser has been detected and reports
your speed.
•NOTE: Unlike radar, signal strength from laser remains
constant.
Laser Alert Example:
You are driving 55 mph and laser is detected.
Visual Alert: LASER 55
Audio Alert: Voice announces “Laser” followed by
distinctive audio tone.
Alerts from non-police signals
Your RL100 is sensitive enough to detect signals generated
by non-police equipment, such as bank security systems.
To learn how to deal with these signals, please read about
FILTER options (page 8) and Quiet RideTM (page 9).
7
Special Features/Functions
Filter Operation
(i.e. signal sensitivity)
The Filter system on the RL100 offers you 3 levels of sensitivity
settings to accommodate various driving situations. To change
the level at any time, press and release FILTER button.
8
Level / Mode Sensitivity Recommended Use
1. Highway Detects all types of FCC For highway travel or in
approved police radar any area in which you are
(factory default or laser signals at full unfamiliar with the types
sensitivity. of radar used.
2. City The X-Band sensitivity is When traveling in an
reduced.This is because urban area with minimal
it is the most common non-police radar signals.
source of non-police radar
signals.K,KA and Laser
remain at full sensitivity.
3. Filter Eliminates X-Band detect- When traveling in a con-
ion completely. Reduces gested traffic area with
K and KA Band sensitivity. a high concentration of
Laser detection will re- non-police radar signals.
main at full sensitivity.
setting)
Quiet RideTM
The RL100’s exclusive Quiet RideTM Function will automati-
cally silence all radar and laser alerts when traveling under
a specific speed of your choice between 20-65 MPH.
The factory default setting for Quiet Ride is “On” and your
unit is already preset to silence alerts when you travel below
25 MPH.
To change the speed at which alerts are silenced:
• Press and hold MENU button for 3 seconds to access the
Menu Function.
•Press release MENU button to scroll through functions
until you reach Quiet Ride. The display shows Quiet On
•Press and hold MUTE button for 3 seconds to access
speed options.
• Press and release MUTE button to scroll through speed
selections. With each press, speeds between 20 - 65 MPH
are displayed in increments of 5 MPH. (20, 25, 30, etc.)
Stop pressing button when you reach your desired Quiet
Ride speed. For example, if 45 is your desired setting, stop
pressing when the display shows 45 MPH .
The RL100 automatically saves your settings after 10 seconds,
exits the Menu Function and the display returns to the
main screen.
NOTE: Locations that you have “Marked for Alert” are not
affected by the Quiet Ride function and will initiate alerts at
any speed. (see page 12)
9
M
RL100 Radar and Laser Detection
Reference Guide
10
Windshield Mounting Bracket
(with suction cups) – For proper
installation (page 4)
Power Cord – Plug into
cigarette lighter or other
12v outlet
Power Input Jack – Insert
small end of power cord
here
Power On/Volume
Control Wheel – Turn on the
RL100 unit and adjusts volume
of voice/tones
MENU/DIM Button – Press and release
to change display brightness from bright
(factory default) to dim or dark, or press
and hold for 3 seconds to enter MENU
mode (page 14 )
