JVC GC-FM1 Manual de operación y mantenimiento
HD MEMORY CAMERA
GC-FM1
1SM321404
Basic User Guide
For more details on the operations, refer
to the“Detailed User Guide”in the internal
memory. (p. 4)
ENGLISH
ESPAÑOL
FRANÇAIS
PORTUGUÊS
中文
U
Downloaded From VideoCamera-Manual.com Manuals
2
Safety Precautions
IMPORTANT:
In the event that any of the
following occur, make a request for
repair to the dealer.
•Smoke or abnormal odor is emitted
•Damage from being dropped
•Water or an object enters inside
If a malfunction occurs, stop using
the camcorder immediately and
contact www.jvc.com or by phone
at 1-800-252-5722
Caution on camcorder
The camcorder may present a
re or chemical burn hazard if
mistreated. Do not disassemble,
heat above 100 °C or incinerate.
•Dispose of used camcorder
promptly.
•Do not disassemble and do not
dispose of in re.
WARNING:
The camcorder shall not be
exposed to excessive heat such as
direct sunshine, re or the like.
If this symbol is shown,
it is only valid in the
European Union.
Downloaded From VideoCamera-Manual.com Manuals
3
(For owners in the U.S.A.)
Changes or modications not approved by JVC could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or
more of the following measures: Reorient or relocate
the receiving antenna. Increase the separation between
the equipment and receiver. Connect the equipment
into an outlet on a circuit dierent from that to which
the receiver is connected. Consult the dealer or an
experienced radio/TV technician for help.
FCC WARNING
(For owners in the U.S.A.)
This equipment may generate or use
radio frequency energy. Changes or
modications to this equipment may
cause harmful interference unless the
modications are expressly approved
in the instruction manual. The user
could lose the authority to operate this
equipment if an unauthorized change
or modication is made.
(For owners in the U.S.A.)
•
The supplied interface cable must be
used with the equipment in order to
comply with the limits for a digital
device pursuant to Subpart B of Part 15
of FCC Rules.
•
Use an HDMI cable with the HDMI logo.
Downloaded From VideoCamera-Manual.com Manuals
4
USB Cable
To Computer
<Button
USB Connector
Accessories
•USB Cable
(WUU102SCP001)
•AV Cable
(WPU122SCP001)
•Hand Strap
•Application software
The supplied software is pre-
installed in the camcorder.
Refer to the “Detailed User Guide”
on the right column for installing
software.
Viewing the“Detailed
Preparation:
•Charge the camcorder. (p. 8)
•Turn on the computer.
•Press the <button for more than
1 second to turn on the camcorder.
•Connect the camcorder to a
computer.
Downloaded From VideoCamera-Manual.com Manuals
5
For Windows user
!The“FMCAM_FRM” window appears.
#Select [MediaBrowser LE Install and User Guide].
$Select [Detailed User Guide].
%Click a language.
For Mac user
!Double-click [FMCAM_FRM] on the desktop.
#Double-click [FM1_guide].
$Double-click [FM1_start.pdf].
%Click a language.
䡵
䡵
User Guide”in the internal memory
Downloaded From VideoCamera-Manual.com Manuals
6
Names of Components
Focus Switching Lever
Normal Recording [M]
Macro Recording [ ]
Power Button [<]
Power Lamp
Select Button [%]
Recording/Playback
Hand Strap
Attachment Area
Delete Button [$]
Charge Lamp
Status (Warning) Lamp
Recording Select Button
Video [!]
Still Image [#]
Index Button [7]
Reset Hole
•If the camcorder malfunctions,
push into the reset hole with a
pointed object such as a wire to
initialize the camcorder.
¡, ¢, £, ¤Buttons
Zoom Buttons
Volume Buttons
Recording Start/Stop Button
Shutter Button
Set Button
LCD Monitor
Downloaded From VideoCamera-Manual.com Manuals
7
Microphone
Speaker
AV Connector
HDMI Connector
USB Connector
Inserting an SD Card
Operations are conrmed on the
following SDHC cards (class 4 or higher)
with capacity 4 GB to 32 GB. Panasonic,
TOSHIBA, SanDisk, ATP.
To conserve power, the camcorder turns o
automatically if there is no operation for 3 minutes.
Tripod Mounting
Socket
Lens
SD Slot Cover
Downloaded From VideoCamera-Manual.com Manuals
8
Charge Lamp
USB Cable
To Computer
<Button
Power Lamp
USB Connector
1Press the <button to turn o
the camcorder.
The power lamp goes out.
2Connect the camcorder to a
computer.
Charge lamp turns on: Charging
goes out: Charging finished
Charging time approx. 180 minutes
Charging
NOTE
•Charging is not possible while the camcorder is turned on.
•Make sure that the computer is turned on during charging.
Charge the battery connecting to PC with the USB cable.
Downloaded From VideoCamera-Manual.com Manuals
9
Preparation:
Turn on the power and select the recording mode.
1While pressing the $button,
press the 7button.
2Select [Time setup], and then
press the set button.
3Set the date and time by selecting items with
¡, ¢and setting values with £, ¤.
4After completing the setting,
press the set button.
5Select [Exit] to quit the screen.
NOTE
•When you rst turn on the power after purchasing the camcorder, the [Time
setup] screen appears.
Setting Date and Time
Downloaded From VideoCamera-Manual.com Manuals
10
During recording, the screen
display changes to red
!: Video mode
Preparation:
Press the !/ #button to select !mode.
Video Recording
1Press the set button to start recording.
Press it again to stop the recording.
Video Playback
1Press the
%button to select the playback
mode.
2Press the
¡, ¢, £, ¤buttons to select a video.
3Press the set button to start playback.
Press it again to stop the playback. To return to the
index screen, press the 7button.
䡵
䡵
Video Recording/Playback
