KS-FX210 [EN] GET0052-001A [J]

INSTRUCTIONS

MANUAL DE INSTRUCCIONES

MANUEL D’INSTRUCTIONS

For customer Use:

Enter below the Model No. and

Serial No. which are located on

the top or bottom of the cabinet.

Retainthisinformationforfuture

reference.

Model No.

Serial No.

GET0052-001A

[J]

For installation and connections, refer to the separate manual.

Para la instalación y las conexiones, refiérase al manual separado.

Pour l’installation et les raccordements, se référer au manuel séparé.

ENGLISH

ESPAÑOL

FRANÇAIS

KS-FX210

CASSETTE RECEIVER

RECEPTOR-REPRODUCTOR DE CASSETTE

RADIOCASSETTE

EN00COVER.KS-FX210[J]f 10/8/01, 10:13 AM3

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

How to reset your unit

Press and hold both the SEL (Select) and (Standby/On/Attenuator) buttons at the same

time for several seconds.

This will reset the built-in microcomputer.

Note:

• Your preset adjustments — such as preset channels or sound adjustments — will also be erased.

SEL (Select)

(Standby/On/Attenuator)

EN02-03-KS-FX210[J]f 10/8/01, 10:13 AM2

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

Thank you for purchasing a JVC product. Please read all instructions carefully before operation,

to ensure your complete understanding and to obtain the best possible performance from the unit.

CONTENTS

How to reset your unit .............................. 2

LOCATION OF THE BUTTONS ........... 4

Control panel............................................ 4

BASIC OPERATIONS ...................... 5

Turning on the power ............................... 5

RADIO BASIC OPERATIONS ............. 6

Listening to the radio................................ 6

Storing stations in memory ...................... 7

Tuning into a preset station...................... 8

Other convenient tuner functions ............. 9

TAPE OPERATIONS ....................... 10

Listening to a cassette ............................. 10

SOUND ADJUSTMENTS.................. 11

Turning on/off the loudness function ........ 11

Selecting preset sound modes................. 11

Adjusting the sound ................................. 11

Storing your own sound adjustments....... 12

BEFORE USE

*For safety....

• Do not raise the volume level too much, as this

will block outside sounds, making driving

dangerous.

• Stop the car before performing any complicated

operations.

*Temperature inside the car....

If you have parked the car for a long time in hot

or cold weather, wait until the temperature in the

car becomes normal before operating the unit.

OTHER MAIN FUNCTIONS ............... 13

Setting the clock....................................... 13

Detaching the control panel ..................... 14

CD CHANGER OPERATIONS ............. 15

Playing CDs ............................................. 15

Selecting CD playback modes ................. 16

MAINTENANCE ............................ 17

TROUBLESHOOTING ..................... 18

SPECIFICATIONS.......................... 19

EN02-03-KS-FX210[J]f 10/8/01, 10:13 AM3

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

278

356

KS-FX210

RNDRPT

CD-CH

MOST

PTY TP

BEAT POP SOFT

LOUD

i;a

LOCATION OF THE BUTTONS

Control panel

1(Standby/On/Attenuator) button

2LOUD (Loudness) button

30(Eject) button

4Cassette compartment

51/ ¡(PROG program) buttons

6CD-CH button

7AM button

8FM button

9+/– button

pSEL (Select) button

q4/ ¢buttons

• Also functions as SSM buttons when

pressed together.

wMO (Monaural) button

RND (Random) button

eNumber buttons

rDISP (Display) button

tRPT/SCAN (Repeat/Scan) button

ySOUND button

u(Control panel release) button

Display window

iRND (Random) indicator

oRPT (Repeat) indicator

;Band indicators

FM1, FM2, FM3,

aCD-CH (CD Changer) indicator

sMO(Monaural) indicator, ST(Stereo) indicator

dMain display

fSound mode indicators

BEAT, POP, SOFT

gLOUD indicator

EN04-KS-FX210[J]f 10/8/01, 10:14 AM4

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

F M

CD-

A M

BASIC OPERATIONS

Adjust the sound as you want

(see pages 11 – 12).

To drop the volume in a moment

Press briefly while listening to any

source. “ATT” starts flashing on the display, and

the volume level will drop in a moment.

To resume the previous volume level, press the

button briefly again.

To turn off the power

Press and hold for more than 1 second.

Note:

When you use this unit for the first time, set the built-in

clock correctly, see page 13.

To increase the volume.

To decrease the volume.

Turning on the power

Turn on the power.

Note on One-Touch Operation:

• When you select a source in step 2 below, the

power automatically comes on. You do not

have to press this button to turn on the power.

• If the cassette is already in the cassette

compartment, tape play starts automatically.

However, it is not recommended to leave the

cassette in the compartment when turning off

the power or ignition key. It may damage the

tape head and the cassette.

Select the source.

To operate the tuner (FM or AM),

see pages 6 –9.

To operate the tape,

see page 10.

To operate the CD changer,

see pages 15 –16.

Adjust the volume.

Volume level appears

PTY TP

EN05-KS-FX210[J]f 10/8/01, 10:14 AM5

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

RADIO BASIC OPERATIONS

To stop searching before a station is received,

press the same button you have pressed for

searching.

Searching a station manually:

Manual search

Select the band (FM1 – 3, AM).

Note:

This receiver has three FM bands (FM1, FM2,

FM3).You can use any one of them to listen to an

FM broadcast.

Press and hold ¢or 4until

“M” (manual) starts flashing on the

display.

Listening to the radio

You can use either automatic searching or manual

searching to tune into a particular station.

Note:

When a cassette is in the cassette compartment, you

cannot select the tuner. Be sure to eject the cassette from

the cassette compartment to listen to the radio.

Searching a station automatically:

Auto search

Select the band (FM1 – 3, AM).

Note:

This receiver has three FM bands (FM1, FM2,

FM3).You can use any one of them to listen to an

FM broadcast.

Start searching a station.

When a station is received, searching stops.

To search stations of

higher frequencies.

To search stations of

lower frequencies.

Selected band appears

FM1 FM2

FM3

A M

F M

FM1 FM2

FM3

A M

F M

BEAT POP SOFT

LOUD

BEAT POP SOFT

LOUD

EN06-08-KS-FX210[J]f 10/8/01, 10:14 AM6

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

Storing stations in memory

You can use one of the following two methods to

store broadcasting stations in memory.

• Automatic preset of FM stations: SSM (Strong-

station Sequential Memory)

• Manual preset of both FM and AM stations

FM station automatic preset: SSM

Youcanpreset6localFMstationsineachFMband

(FM1, FM2 and FM3).

Select the FM band (FM1 –3) you

want to store FM stations into.

Each time you press the

button, the FM band changes

as follows:

Press and hold both buttons for

more than 2 seconds.

Local FM stations with the strongest signals

are searched and stored automatically in the

band number you have selected (FM1, FM2 or

FM3). These stations are preset in the number

buttons—No.1(lowestfrequency)toNo.6(highest

frequency).

When automatic preset is over, the station stored

in button number 1 will be automatically tuned into.

Tune into a station you want while

“M”is flashing.

• If you release your finger from the button,

the manual mode will automatically turn off

after 5 seconds.

• If you hold down the button, the frequency

keeps changing until you release the

button.

When an FM stereo broadcast is hard

to receive:

PressMO/RND(Monaural/Random)whilelistening

to an FM stereo broadcast.

• Eachtimeyou press the button, the MO indicator

lights up and goes off alternately.

When the MO indicator is lit on the display,

the sound you hear becomes monaural but

the reception will be improved (the ST indicator

goes off).

To restore the stereo effect, press the same

button again.

To tune into stations

of higher frequencies.

To tune into stations

of lower frequencies.

“SSM”appears, then disappears when automatic

preset is over.

MO/RND

Lights up when receiving an

FM broadcast in stereo.

FM1 FM2 FM3

F M

BEAT POP SOFT

LOUD

BEAT POP SOFT

LOUD

BEAT POP SOFT

LOUD

EN06-08-KS-FX210[J]f 10/8/01, 10:14 AM7

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

Manual preset

You can preset upto6stationsineachband(FM1,

FM2, FM3 and AM) manually.

Ex: Storing an FM station of 88.3 MHz into the

preset number 1 of the FM1 band

Select the band (FM1 –3, AM) you

want to store stations into (in this

example, FM1).

Each time you press the button, the FM

band changes as follows:

Tune into a station of 88.3 MHz.

Press and hold the number button

(in this example, 1) for more than

2 seconds.

Preset number “P1”flashes for a while

Repeat the above procedure to store

other stations into other preset

numbers.

Notes:

• Apreviouslypresetstationis erased when a new station

is stored in the same preset number.

• Preset stations are erased when the power supply to

the memory circuit is interrupted (for example, during

battery replacement). If this occurs, preset the stations

again.

Tuning into a preset station

You can easily tune into a preset station.

Remember that you must store stations first. If you

have not stored them yet, see “Storing stations in

memory”on page 7.

Select the band (FM1 –3, AM).

Select the number (1 –6) for the

preset station you want.

To tune into stations

of higher frequencies.

To tune into stations

of lower frequencies.

FM1 FM2

FM3

A M

F M

BEAT POP SOFT

LOUD

FM1 FM2 FM3

F M

BEAT POP SOFT LOUD

EN06-08-KS-FX210[J]f 10/8/01, 10:14 AM8

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

Other convenient tuner

functions

Scanning broadcast stations

When you press RPT/SCAN while

listening to the radio, station

scanning starts. Each time a

broadcast is tuned in, scanning

stops for about 5 seconds (tuned

frequency number flashes on

the display), and you can check

what program is now being

broadcast.

If you want to listen to that

program, press the same button

again to stop scanning.

Changing the AM/FM channel intervals

When using this unit in an area other than North

or South America:

When this unit is shipped from the factory, the

channel intervals are set to 10 kHz forAM and 200

kHz for FM. You can change the channel intervals

by following the procedure below.

1Press SEL (Select) for more than 2 seconds.

“CLOCK H”, “CLOCK M” or “AREA” appears on

the display.

2If “AREA” does not appear, press 4or

¢until it appears.

3Press +.

“AREA EU” appears and the channel intervals

are set to 9 kHz for AM and 50 kHz (for manual

tuning) / 100 kHz (for searching) for FM.

To reset to the factory setting, follow the above

step 1 and 2, then press – in step 3 (“AREA US”

appears on the display.)

AREA EU : Select this when used in an area

other than North and South America.

AREA US: Select this when used in North or

South America.

RPT

SCAN

EN09-KS-FX210[J]f 10/8/01, 10:14 AM9

ENGLISH

KS-FX210 [EN] GET0052-001A [J]

TAPE OPERATIONS

Listening to a cassette

You can playback type 1 (normal) tapes.

Turn on the power.

Note on One-Touch Operation:

If a cassette is already in the cassette compartment,

tape play starts automatically. However, it is not

recommended to leave the cassette in the compartment

when turning off the power or ignition key. It may

damage the tape head and the cassette.

Insert a cassette into the cassette

compartment.

When one side of the

tape reaches its end

during play, the other

side of the tape

automatically starts

playing. (Auto Reverse)

Select the tape direction.

Press both buttons at

the same time.

Eachtimeyou press both

buttons,the tape direction

changes alternately –

forward( ) and

reverse ( ).

To stop play and eject the cassette.

Press 0.

Tape play stops and the cassette automatically

ejects from the cassette compartment. The source

changes to the previously selected one.

• You cannot change the source if the cassette is

still in the cassette compartment.

To change source, you must eject the cassette

first.

• You can also eject the cassette by pressing 0

while the unit is turned off.

To fast-wind a tape.

Press in ¡or 1.

The tape will be wound in the direction of the

arrows (¡or 1).

Tape direction

To restart playback, lightly press the other

button which is not pressed in (1or ¡).

/I/ATT

PROG

EN10-KS-FX210[J]f-1 10/8/01, 10:15 AM10

Otros manuales para KS-FX210

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Receptor de coche de JVC

JVC

JVC KD-R975BTS Manual de usuario

JVC

JVC KS-FX453R Manual de usuario

JVC

JVC GET0266-003A Manual de usuario

JVC

JVC KD-R746BT Manual de usuario

JVC

JVC KD-S5055SU Manual de usuario

JVC

JVC KD-LH3105 Manual de usuario

JVC

JVC KD-AR390 Manual de usuario

JVC

JVC KD-DV5000 Manual de usuario

JVC

JVC KD-LX30R Manual de usuario

JVC

JVC KD-X80BT Manual de usuario

JVC

JVC CD Receiver KD-SHX701 Manual de usuario

JVC

JVC KD-DV5301 Instrucciones de montaje

JVC

JVC KD-G161 Manual de usuario

JVC

JVC KS-FX722R Manual de usuario

JVC

JVC KD-AVX77 - EXAD - DVD Player Manual de usuario

JVC

JVC GET0163-001A Manual de usuario

JVC

JVC KD-R862BT Manual de usuario

JVC

JVC EXAD KD-AVX44 Manual de usuario

JVC

JVC KD-DV5500 - Single DIN DVD/CD/WAV/MP3/WMA iPod/HD Radio Receiver/Satellite... Guía

JVC

JVC CD Receiver KD-G437 Manual de usuario

JVC

JVC KD-LH2000R Manual de usuario

JVC

JVC KD-G326 Guía

JVC

JVC EXAD KW-AVX826 Manual de usuario

JVC

JVC CD Receiver KD-G631 Guía

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario

Medion

Medion Car Audio Manual de usuario
