Jura Impressa Xs9 OT Classic Guía de configuración
My Coffee Shop Pty Ltd
ACN 102 850 037
9 Hall St
Hawthorn Ea t VIC 3123
ph: 03 9946 4160
fax: 03 9822 6269
Shop 93,1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: 02 9034 6586
clientservices@mycoffeeshop.com.au 1300 365 487 www.mycoffeeshop.com.au
Jura Impre a X 9 OT Cla ic
Operating & cleaning instructions
4
Control elements
Figure: IMPRESSA XS95 One Touch
Control elements
1 Bean container cover
2 Bean container with aroma preservation
cover
3 Water tank with handle
4 Power switch and power cable
(back of machine)
5 Coffee grounds container
6 Cup platform
7 Drip tray
8 Fineness of grind switch
9 Cup tray
10 Cover of filler funnel for pre-ground coffee
11 Filler funnel for pre-ground coffee
12 Connector System©
for removable frothers
13 Professional Cappuccino Frother
14 Height-adjustable coffee spout
15 Hot water spout
12
1
2
3
13
14
4
8
11
10
15
9
5
6
7
5
Control elements
Front left
1Display
2Rotary Switch cover
3f Rotary switch
Q On/off button
c Maintenance button
i 1 Espresso button
4 2 Espressi button
o1 Coffee button
d 2 Coffees button
e Coffee à la Carte button
vPre-ground coffee button
Front right
4 öSelector switch
5 Professional Cappuccino Frother
6 Easy Cappuccino Frother
a Hot water portion symbol
m Hot water symbol
p Cappuccino button
z Milk portion symbol
n Milk symbol
qLatte Macchiato button
The Connector System©permits the use of different frothers. These are available from stockists.
2
3
4
1
5
56
Operating Instructions – Jura Xs9 OT
My Coffee Shop Pty Ltd
ACN 02 850 037
9 Hall St
Hawthorn East VIC 3 23
ph: 03 9946 4 60
fax: 03 9822 6269
Shop 93, -5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: 02 9034 6586
clientservices@mycoffeeshop.com.au 1300 365 487 www.mycoffeeshop.com.au
Cappuccino
. Place your cup / mug under the milk / coffee spout on the right.
2.
Turn the milk selector to the foam milk position – See diagram below.
3. Press the cappuccino key. Your cappuccino will now be poured
Flat white
. Place your cup/mug under the spout on the right.
2. Turn the milk selector to the flat milk position – See diagram below.
3. Press the Latte macchiato key. Your flat white will now be poured
Café Latte
. Follow the procedure for making a cappuccino.
2. When your cup or glass /3 full of foam milk, turn the milk selector to the flat milk position.
Espresso or Long Black
. Place your cup / mug under the middle spouts and press espresso or coffee key. Your drink
will now be poured. Press the button twice for a double espresso or two long blacks.
Note: Each key is fully programmed however you can stop the milk and coffee flow short by pressing
any key while it is pouring. Adjustments to suit personal preference can also be made using
the rotary dial. These changes do not affect the programmed settings.
IMPRESSA Xs9 Classic
Precondition: COFFEE READY
1
2
MAINTENANCE
3
CLEAN CAPPUCCINO
4
CLEANER FOR CAPPU.
5
6
7
8
CAPPUCCINO /CLEANS
WATER FOR CAPPUCCINO
250 ml
1x 15 ml
9
10
11
CAPPUCCINO /CLEANS
COFFEE READY
c250 ml
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
Cleaning the
cappuccino frother
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
JURA Cappuccino Cleaner
1000 ml (Art. 62536)
Weekly cleaning proceedure – Milk system
My Coffee Shop Pty Ltd
ACN 102 850 037
9 Hall Street
Hawthorn Ea t Vic 3123
ph: 03 9946 4160
fax: 03 9822 6269
93/1-5 Harwood Street
Pyrmont NSW 20009
ph: 02 9034 6580
fax: 02 9034 6586
servicecentre@mycoffeeshop.com.au
1300 365 87
www.mycoffeeshop.com.au
Complete thi procedure once a week after the daily milk y tem clean.
1. Remove the automatic milk frother from the machine. (Fig 1 - 2)
2. Separate the automatic milk frother into 4 part . (Fig 3)
3. Soak the part in 250ml of warm water (not hot) and 15ml of Jura cappuccino cleaner for 15 – 20 min
(max).
4. Remove the part from the olution and rin e them under cold tap water.
5. Re-a emble the auto frother and refit onto the machine.
Figure 1
Figure 2
Figure 3
IMPRESSA Xs9 Classic
Precondition: COFFEE READY /
CLEAN MACHINE
1
DURATION 20 MIN. /
START YES
2
EMPTY TRAY
3
4
5
PRESS RINSE
6
7
CLEANS
ADD TABLET /PRESS
RINSE
8
9
10
11
REINIGT
EMPTY TRAY
12
13
14
COFFEE READY
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
Cleaning the machine
Approximate duration 20 min.
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
2-phase cleaning tablets
Tub of 25 (Art. 62535)
Pack of 6(Art. 62715)
IMPRESSA Xs9 Classic
Precondition: COFFEE READY /
DECALCIFY MACHINE
1
DURATION 45 MIN. /
START YES
2
EMPTY TRAY
3
4
5
SOLVENT IN TANK
6
7
8
SOLVENT IN TANK /
PRESS RINSE
3x
9
10
11
DECALCS
EMPTY TRAY
12
13
14
RINSE WATER TANK /
FILL WATER TANK
15
16
PRESS RINSE
c
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
Descaling the machine
Approximate duration 45 min.
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
Descaling tablets
Tub of 36 (Art. 70751)
Pack of 3 (Art. 61848)
17
18
19
DECALCS
HEATING UP
MACHINE RINSING
EMPTY TRAY
20
21
22
COFFEE READY
48
6 Display messages
6 Display messages
Message Cause/Result Action
FILL WATER TANK The water tank is empty.
You cannot prepare any coffee
products, hot water or milk
products.
TFill the water tank (see
Chapter 1, ‘Preparing and using
for the first time – Filling the
water tank’).
EMPTY GROUNDS The coffee grounds container
is full. You cannot prepare any
coffee products, but you can
prepare hot water or milk.
TEmpty the coffee grounds
container and the drip tray.
EMPTY TRAY The drip tray is full. You cannot
prepare any coffee products,
hot water or milk products.
TEmpty the drip tray.
TRAY MISSING The drip tray is not inserted
correctly or is not inserted at
all. You cannot prepare any
coffee products, hot water or
milk products.
TInsert the drip tray.
TClean the metal contacts on
the back of the drip tray.
FILL BEANS The bean container is empty.
You cannot prepare any coffee
products, but you can prepare
hot water or milk.
TFill the bean container (see
Chapter 1, ‘Preparing and using
for the first time – Filling the
bean container’).
PRESS RINSE The IMPRESSA is prompting
you to start a rinse operation
or continue a started mainte-
nance programme.
TPress the maintenance button
to start rinsing or to continue the
maintenance programme.
COFFEE READY /
RINSE CAPPUCCINO
The IMPRESSA is prompting
you to start cappuccino
rinsing.
TPress the maintenance button
to start cappuccino rinsing.
COFFEE READY /
CLEAN MACHINE
After 220 preparations or
80 switch-on rinses, the
IMPRESSA will prompt you to
clean it.
TClean the machine (see
Chapter 5, ‘Maintenance –
Cleaning the machine’).
