Instruction Manual

US-8010D/US-8010/Mh-700D/Mh-700/Mh-800

59506-041-08

US-8010

US-8010D Series

PT-900BD/PT-900B

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,

you are recommended to take a few minutes to read this instruction manual carefully.

1. Important Caution

2. Features

3. Specication

3-1 Receiver// US-8010D/ US-8010

3-2 Handheld Transmitter // Mh-700 / Mh-800 / Mh-700D

3-3 Body-pack Transmitter // PT-900B / PT-900BD

3-4 Optional Condenser Microphone

4. Part Identication & Accessories

4-1 Receiver// US-8010D/ US-8010

4-2 Handheld Transmitter // Mh-700 / Mh-800 / Mh-700D

4-3 Body-pack Transmitter // PT-900B / PT-900BD

4-4 Optional Condenser Microphone

4-5 Accessories

5. Preparing Procedures & Basic Operation

5-1 Receiver// US-8010D/ US-8010

5-2 Rack Mounting

5-3 System Operation

5-4 Handheld transmitter // Mh-700 / Mh-800 / Mh-700D

5-5 Body-pack Transmitter // PT-900B / PT-900BD

5-6 Installation of Condenser Microphones

7. Important Notice

INDEX

6. Recommendation

WIRELESS MICROPHONE SYSTEM

1. Important Caution

2. Features

Always makes all connections before plugging the unit into an AC power outlet.•

Do not leave the device in a place neither with high temperature nor high humidity.•

Always do not handle the power cord with wet hands!•

Keep the devices away from re and heat sources.•

Operated in UHF band where there is less RF interference than the VHF band.•

Equipped with a SAW lter can benet to reducing spurious RF content.•

Including balanced XLR output and unbalanced 1/4” output.•

Integrated antenna of the handheld transmier benets less hindrance for performer.•

Built-in noise mute and squelch circuit mode can validly resist extraneous noise.•

Body-pack transmier is available to work together with a lavalier mic. or headset mic.•

Space-saving half-rack housing design.•

3. Specication

3-1 Receiver

3-2 Handheld Transmitter

Model No....................................

Frequency Preparation......

Carrier Frequency Range

Frequency Stability...............

S/N Ratio...................................

T.H.D..................................

Display..............................

Display Contents...................

Controls............................

Audio Output Level............

AF Output Impedance.......

Squelch.............................

Operation Voltage.................

Output Connector................

Dimension(m/m)...............

US-8010D / US-8010

Crystal

600~960 MHz

±10KHz

> 105dB

<0.6%@1KHz

LED

Antenna, RF/AF Status Power On/O,

Audio Level

-12dB

600Ω

Pilot Tone, Noise and Mute

12-18 VDC, 150mA

1 XLR Balanced Socket

1 Unbalanced Ø6.3mm Phone Jack

210mm (W)* 40mm (H)* 171mm (D)

Mode No.............................................

Frequency Preparation..............

Carrier Frequency Range.........

RF Outputs........................................

Stability.................................

Frequency Deviation..................

LED Display......................................

Controls................................

Spurious Emissions.....................

Audio Frequency Response..

Battery..................................

Mh-700 / Mh-800 / Mh-700D

Crystal

600~960 MHz

10mW

±10KHz

±48KHz

Low Baery, Power On/O

Power On/O

<-50 dBC

50~16,000 Hz

UM3, AA 1.5V*2

WIRELESS MICROPHONE SYSTEM

3-3 Body-pack Transmitter

3-4 Optional Condenser Microphone

Model No..........................................

Frequency Preparation............

Carrier Frequency Range......

RF Outputs......................................

Stability.................................

Frequency Deviation................

LED Display....................................

Controls.................................

Spurious Emissions...................

Audio Frequency Response

Battery...................................

PT-900 / PT-900BD

Crystal

600~960 MHz

10mW

±10KHz

±48KHz

Power On/O, Low Baery

Power On/O, AF Level

<-50 dBC

40~18,000 Hz

UM3, AA 1.5V*2

Headset Microphone

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-235

4P Mini XLR

50~18,000 Hz

Omni-directional

-53±3 dB

1.8kΩ

130dB

155mm(W)

* 134mm(H)

* 157mm(D)

17g (cable excluded)

CX-504

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

285mm(W)

* 55mm(H)

* 111.3mm(D)

56.3g

Model No...............................

Connector...............................

Option Connector...........

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-214

801C4

(4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-60±3 dB

1.8kΩ

130dB

125mm(W)

* 134mm(H)

* 157mm(D)

32.9g

CM-214U

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

205mm(W)

* 134mm(H)

* 157mm(D)

38.4g

CM-214UL

801C3 (3P Mini XLR)

801C4 (4P Mini XLR)

801CS (3.5 stereo plug)

801CR

100 ~ 18,000Hz

Cardioid

-65±3 dB

1.8kΩ

120dB

125mm(W)

* 134mm(H)

* 157mm(D)

18g (cable excluded)

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-501

4P Mini XLR

100~15,000 Hz

Cardioid

-60±3 dB

2.2kΩ

130dB

Ø10.1mm(W)

* 26.4mm(H)

21.5g

CM-201

4P Mini XLR /

60~15,000 Hz

Omni-directional

-60±3 dB

2.2kΩ

130dB

Ø5mm(W)

* 9mm(H)

20.7g

CM-125

4P Mini XLR

50~18,000 Hz

Omni-directional

-53±3 dB

4.4kΩ

130dB

Ø4mm(W)

* 11mm(H)

7g (cable excluded)

Lavaliere Microphone

WIRELESS MICROPHONE SYSTEM

4. Parts Identication & Accessories

4-1 Receiver // US-8010D / US-8010

Power On/O

RF indicator

AF indicator

Volume control

Antenna

DCV Input (12-18V DC/150mA)

Unbalanced 6.3mm jack socket

Balanced XLR socket

Interchangeable capsule module

Baery tray release knobs

Baery tray

Power On/O switch

LED Indicator

ID housing

4-2 Handheld Transmitter // Mh-800 / Mh-700D / Mh-700

Mh-800 Mh-700 / Mh-700D

1 2 3 4

6 8 7

1 2 3 4

6 8 7

13 14

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For.................................

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For.................................

CX-500

4P Mini XLR

20~20,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Violin

CX-508W

4P Mini XLR

50~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Winds

CX-500F

4P Mini XLR

20~20,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Flutes

CX-520

4P Mini XLR

50~16,500 Hz

Supercardioid

-78±3dB

600Ω

148 dB

Harmonica

CX-516W

4P Mini XLR

30~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Accordion

Compatible Instrument Microphone

Model No...............................

Connector..............................

Option Connector...........

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

CM-801/CM-804i

801C4 (4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-64±3 dB

1.8kΩ

130dB

CM-8015/CM-825i

801C4 (4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

50~18,000 Hz

Omni-directional

-53±3 dB

1.8kΩ

130dB

Ear-hook Microphone

WIRELESS MICROPHONE SYSTEM

Mic. input

Power On/o switch

Power Indicator

Antenna

AF level control

Baery tray

Baery tray cover

Carry case

Belt-loop

Clip

4 Pin Mini XLR

Windscreen

4-3 Body-pack Transmitter // PT-900B / PT-900BD

4-4 Optional Condenser Microphone

Lavaliere Microphone // CM-501 / CM-201 / CM-125

31 31 31

Headset Microphone // CM-214 / CM-214U / CM-214UL / CM-235 /

CX-504

CM-501 CM-201 CM-125

26 26 26

24 24

28 2828

2928

CM-214 CM-214U

CM-235

CM-214UL

Standard :

4 Pin Mini XLR

3 Pin Mini XLR

3.5 Stereo Plug

CX-504

16 15 19

Gooseneck

Adjustable headband

Headband

4 Pin Mini XLR

Windscreen

WIRELESS MICROPHONE SYSTEM

Gooseneck

Clip

Bracket

Volume Control

Windscreen

4 Pin Mini XLR

Compatible Instrument Microphone // CX-500 / CX-500F / CX-520

CX-508W / CX-516W

CX-508W CX-516W

42 42

46 46

CX-500

46 CX-500F

CX-520

Boom

Adjustable Headband

Adjustable ear hook

Detchable Cable

Cable Clip

Windscreen

4 Pin Mini XLR

3 Pin Mini XLR

3.5 Stereo Plug

4Pin Hirose connecter

Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i

CM-825i 36

Option

CM-801

CM-804i 36

CM-8015

WIRELESS MICROPHONE SYSTEM

AC/DC adaptor

Switching Power Supply(100V~240V , 50~60Hz)

Linear Power Supply (220V , 50Hz)

Linear Power Supply (220V , 60Hz)

Screwdriver

DR-900 dual rack adaptor

RP-900 panel cover

AF output cable (with Φ6.3 plug at both ends)

GC-80/GC-100 Guitar Cable

GC-80L/GC-100L Guitar Cable

4-5 Accessories

53 54

Option

B C

5. Preparing Procedures & Basic Operation

5-1 Receiver // US-8010D / US-8010

(1) Audio Output Connector

e receiver equipped with both balanced XLR output and unbalanced φ 6.3mm jack output;

you can choose the proper way for using.

Connect one end of the Audio cable to the AF output socket in the rear panel of the receiver and

plug another end to the “MIC IN” input socket of a mixer or amplier. (Step 1 of Figure 1)

(2) Power connection

Connect one end of AC/DC adaptor cable to DC input socket in the rear panel of the receiver,

and plug another end into an AC outlet. (Step 2 of Figure 1)

MIXER

AC/DC ADAPTOR

AC POWER SOCKET

AUDIO OUTPUT

DC INPUT

WIRELESS MICROPHONE SYSTEM

5-2 Rack Mounting

5-3 System Operation

(1) Before mount receivers onto DR-900 rack adaptor, please release any cables from the rear of

the receiver.

(2) Turn over receiver and DR-900 rack adaptor simultaneously, there are 4 threaded holes each

in the boom of receiver and rack adaptor for inserting screws.

(3) Single receiver

Insert in a receiver through the front of DR-900 until it is rmly aached to the rack, then

screw on a RP-900 to another side of the rack.

(4) Dual receivers

e same way as above, put one receiver to each rack space.

Be sure to mute the audio signal of mixer or amplier before turning on the receiver and

transmier.

5-4 Handheld transmitter // Mh-700D / Mh-700 / Mh-800

(1) Mh-700D & Mh-700 & Mh-800 Handheld Transmier

1. Turn the microphone ball grille counter-clockwise

( Figure 1), press both release knobs to remove the

baery tray from the mic. housing ( Figure 2).

2. Insert two 1.5V baeries according to the correct polarity

(Step 1 of Figure 3) and return the baery tray back to

housing (Step 2 of Figure 3).

Aim the connecting pins exactly toward the cavities on the

boom side of detachable mic. capsule module ( Figure 4)

and tighten it clockwise!

Figure 1 Figure 2 Figure 3 Figure 4

WIRELESS MICROPHONE SYSTEM

5-5 Body-pack Transmitter // PT-900B / PT-900BD

(1) Basic operation

1. Slide the baery tray cover in the direction of the

arrow to open it, insert two 1.5V baeries according

the correct polarity, and return the cover.

2. Switch the transmier On

e On/O switch is located on the top of the

transmier.

3. Sensitivity adjusting

ere is a gain control adjustor in the up-le of its

back, you can adjust the level in 3 steps from 0 dB

to 30 dB.

AUDIO ADJUSTING STICKER

AF LEVEL CONTROL

ON/OFF

(2) Wearing the Body-pack transmier

e carry case allows body-pack transmier to be aached on performer’s belt, place the

antenna towards the back of his body. e Velcro tag around the belt and x it.

5-6 Installation of Condenser Microphones

(1) Lavaliere microphone

Aach lavaliere microphone to a tie, lapel, where is suitable for sound pick-up. Plug the

connector into input socket on the body-pack transmier.

(2) Headset microphone

Put the headband behind your head, and x the temples on your ears as shows, then

adjust the gooseneck to have best miking. Plug the connector into input socket on the

body-pack transmier.

(3) Instrument Microphones

e system is compatible with JTS various instrument microphones.

For detail please refer to user’s manuals of these microphones.

MIC IN

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de micrófono de JTS

Manuales populares de Sistema de micrófono de otras marcas

Paso

Paso R824 Manual de usuario

Naxa

Naxa NAM-982 Manual de usuario

Motorola

Motorola PMNN4461 Manual de usuario

Xvive

Xvive U3 Manual de usuario

Tekon

Tekon DUOS Manual de usuario

Heyuan Intelligence

Heyuan Intelligence IOT-G2S-01 Manual de usuario

Devine

Devine WMD-IE Manual de usuario

LG LF-D7150 Manual de usuario

GE S768DAV Manual de usuario

LD U305 HBH 2 Manual de usuario

Chainway

Chainway URA8 Manual de usuario

ORATOR

ORATOR D860TD Manual de usuario

Sennheiser

Sennheiser Evolution Wireless Digital EW-DX EM 2 Manual de usuario

Alpha Technologies

Alpha Technologies RBMS Manual de usuario

SWIT Electronics Co.,LTD.

SWIT Electronics Co.,LTD. CW-S150 Manual de usuario

Shure

Shure UA844 Manual de usuario

Panasonic

Panasonic SHFX70 - DVD HOME THEATER WIRELESS SYSTEM Manual de usuario

Pyle

Pyle PDWM5000 Manual de usuario
