JTS E-7R Manual de usuario

59508-113-02

PROFESSIONAL CO., LTD.

No.148,9thIndustryRoad,Ta-LiIndustrialPark,

TaichungCity,Taiwan,R.O.C.

Tel:886-4-24938803Fax:886-4-24914890

E-mail:[email protected]

www. jts.com.tw

E-7TH(D)/E-7TB(D)

Instruction Manual

UHF PLL

Single/Dual Channel Diversity System

Thank you for choosing the JTS wireless system. In order to obtain the best efficiency from the

system, you are recommended to take a few minutes to read this instruction manual carefully.

1. Important Caution

2. Features

3. Specication

3-1 Receiver // E-7R / E-7Du

3-2 Handheld Transmitter // E-7TH(D)

3-3 Body-pack Transmitter // E-7TB(D)

3-4 Optional Condenser Microphone

4. Part Identication & Accessories

4-1 Receiver // E-7R / E-7Du

4-2 Handheld Transmitter // E-7TH(D)

4-3 Body-pack Transmitter // E-7TB(D)

4-4 Optional Condenser Microphone

4-5 Accessories

5. Preparing Procedures & Basic Operation

5-1 Receiver // E-7R / E-7Du

5-2 Rack Mounting

5-3 Battery Insertion of the transmitter

5-4 Body-pack Transmitter // E-7TB(D)

6. System operation

7. Recommendation

8. Important notice

INDEX

WIRELESS MICROPHONE SYSTEM

1. Important Caution

2. Features

• Always makes all connections before plugging the unit into an AC power outlet.

• Do not leave the device in a place neither with high temperature nor high humidity.

• Always do not handle the power cord with wet hands!

• Keep the devices away from re and heat sources.

• Operated in UHF band where there is less RF interference than the VHF band.

• Due to the PLL synthesized technology, the system oer 16 selectable channel.

• Advanced antenna diversity ensure the stable transmission and reception.

• Tuned antennas can benet the stable RF reception.

• Built-in Tone key Squelch & Noise Mute detection are available to restrain the interference

signal.

• Rugged plastic housing can pass through the dicult environment.

• Equipped with balanced Ø6.3 mm phone Jack.

• Body-pack transmier provides phantom powering for condenser lavaliere and headset

microphones.

3. Specication

3-1 Receiver

3-2 Handheld Transmitter

Model No .........................................

Frequency Preparation..............

Carrier Frequency Range.......

S/N Ratio...........................................

T.H.D.............................................

Display........................................

Display Contents...........................

Controls............................

Audio Output Level....................

AF Output Impedance..............

Squelch.............................

Operation Voltage.........................

Output Connector.......................

Dimension(m/m)...............

E-7R / E-7Du

PLL Synthesized Control

470~960 MHz

> 100dB

<0.6%@1KHz

LED

RF/AF Status

Power On/O, Channel Selecting, Audio Level

-15dB

600Ω

Pilot Tone, Noise and Mute

12 VDC, 150mA (E-7R)

12 VDC, 250mA (E-7Du)

1 Balanced Ø6.3mm phone jack

221mm (W)* 40mm (H)* 152mm (D)

Model No............................................

Frequency Preparation...............

Carrier FrequencyRange..........

RF Outputs........................................

Stability..................................................

Frequency Deviaion....................

LED Display.......................................

Controls................................................

Spurious Emissions.......................

Audio Frequency Resonse.......

Baery.....................................................

E-7TH(D)

PLL Synthesized Control

470~960 MHz

10mW

±10KHz

±48KHz

Power On/O, Low baery, mute

Power On/O, Channel Selecting, mute

<-60 dBC

50~16,000 Hz

UM3, AA 1.5V*2

WIRELESS MICROPHONE SYSTEM

3-3 Body-pack Transmitter

Model No........................................

Frequency Preparation.........

Carrier Frequency Range......

RF Outputs.....................................

Stability...................................

Frequency Deviation................

LED Display....................................

Controls..................................

Spurious Emissions...................

Audio Frequency Response

Battery....................................

E-7TB(D)

PLL Synthesized Control

470~960 MHz

10mW

±10KHz

±48KHz

Power On/O, Low baery , mute

Power On/O, Channel Selecting, mute

<-50 dBC

40~18,000 Hz

UM3, AA 1.5V*2

3-4 Optional Condenser Microphone

Model No...............................

Connector..............................

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-501

4P Mini XLR

100~15,000 Hz

Cardioid

-60±3 dB

2.2kΩ

130dB

Ø10.1mm(W)

* 26.4mm(H)

21.5g

CM-201i

4P Mini XLR

60~15,000 Hz

Omni-directional

-60±3 dB

2.2kΩ

130dB

Ø5mm(W)

* 9mm(H)

20.7g

CM-125i

4P Mini XLR

50~18,000 Hz

Omni-directional

-53±3 dB

4.4kΩ

130dB

Ø4mm(W)

* 11mm(H)

7g (cable excluded)

Lavaliere Microphone

Headset Microphone

Model No...............................

Connector..............................

Option Connector...........

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-214i

801C4

(4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-60±3 dB

1.8kΩ

130dB

125mm(W)

* 134mm(H)

* 157mm(D)

32.9g

CM-214Ui

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

205mm(W)

* 134mm(H)

* 157mm(D)

38.4g

CM-214ULi

801C3 (3P Mini XLR)

801C4 (4P Mini XLR)

801CS (3.5 stereo plug)

801CR

100 ~ 18,000Hz

Cardioid

-65±3 dB

1.8kΩ

120dB

125mm(W)

* 134mm(H)

* 157mm(D)

18g (cable excluded)

Model No...............................

Connector..............................

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-235i

801C4 (4P Mini XLR )

50~18,000 Hz

Omni-directional

-53±3 dB

1.8kΩ

130dB

155mm(W)

* 134mm(H)

* 157mm(D)

17g (cable excluded)

CX-504

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

285mm(W)

* 55mm(H)

* 111.3mm(D)

56.3g

WIRELESS MICROPHONE SYSTEM

Model No...............................

Connector..............................

Option Connector...........

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

CM-801/CM-804i

801C4 (4 pin mini XLR)

801C3 (3 pin mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-64±3 dB

1.8kΩ

130dB

CM-8015/CM-825i

801C4 (4 pin mini XLR)

801C3 (3 pin mini XLR)

801CS (3.5 stereo plug)

801CR

50~18,000 Hz

Omni-directional

-53±3 dB

1.2kΩ

130dB

Ear-hook Microphone

Model No...............................

Connector..............................

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For................................

Model No...............................

Connector..............................

Frequency Response......

Polar Paern.........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For................................

CX-500

4P Mini XLR

20~20,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Violin

CX-508W

4P Mini XLR

50~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Winds

CX-500F

4P Mini XLR

50~18,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Flutes

CX-520

4P Mini XLR

50~18,000 Hz

Supercardioid

-78±3dB

600Ω

148 dB

Harmonica

CX-516W

4P Mini XLR

50~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Accordion

Compatible Instrument Microphone

4. Parts Identication & Accessories

4-1 Receiver // E-7R / E-7Du

Power On/Off

7-SEG Display

Channel Selector

RF indicator

AF indicator

Volume control

Antenna

DCV Input

0dB/-20dB Switch

Balanced 6.3mm phone Jack

4-2 Handheld Transmitter // E-7TH(D)

Interchangeable capsule module

Baery tray

Channel selector

Power On/O, mute switch

7-SEG Display

Power ON/OFF, mute, Low Ba. LED

ANT. BANT. A

7 7

910

166

55 3

ANT. BANT. A

7 7

910

E-7R

E-7Du
