Johnson Controls GLAS Manual de usuario

Support

If at any point you need assistance, we’re here to help.

Visit glas.johnsoncontrol.com/support for how-to videos and frequently asked ques-

tions.

Can’t nd what you’re looking for? Give us a call at 1-833-297-4527(GLAS) and our

technical team can walk you through it.

Before you start, download the GLAS app for easy installation.

Included in box

GLAS Thermostat 4 Screws

Wall Plate 4 Drywall Anchors

4 to 5 Wire Adapter Quick Start Guide

Tools required

Screwdriver

Drill

Level

Compatibility

GLAS is compatible with most 24 VAC heating and cooling systems.

Use the compatibility checker to ensure your system will work with GLAS by going to

glas.johnsoncontrols.com/compatibilitychecker.

Heating One or two stages

Cooling One or two stages

Heat Pump One or two stages with one-or-two stage auxiliary heat

Fan Single-speed fan

Auxiliary Humidier, dehumidier, or ventilator (including HRV or ERV)

Terminal descriptions

Note: If you have only one R wire, connect to RC.

Note: If you are replacing an existing thermostat, remove any jumper wires between

R and RH or RC and RH.

YFirst stage of cooling or rst stage heat pump

Y2 Second stage of cooling command or second stage heat pump

WFirst stage of conventional heating or rst stage auxiliary heat for heat pump

systems

W2 Second stage of conventional heating or second stage of auxiliary heat for

heat pump system

Terminal descriptions

GFan

O/B Heat pump reversing valve (supports both O type and B type)

AUX Auxiliary - humidier, dehumidier, or ventilator

R 24 VAC Cool

RH 24 VAC Hot

C24 VAC Common

IMPORTANT: If your thermostat is built into the wall and connected

to thick wires with wire nuts, or if it is labeled 110, 120, or 240 volts,

you have a high voltage system that is not compatible with the GLAS

Thermostat. Do not connect your thermostat to these high voltage

wires. GLAS is only compatible with 24VAC systems.
