PGP914 Wireless PIR Motion Detector

Installation Guide

Installation guidelines

The reference to PGP914 throughout this manual includes the model PG9914.

CAUTION:

Only qualified personnel may install this equipment. Place this device in non-

hazardous indoor locations only.

Important:

Check the device andthe entire alarm system weekly to ensure optimal

performance.

Note:

TocomplywithFCCandISEDCanadaRFexposurecompliancerequirements,locate

the device at a distance of at least 20 cm from all persons during normal operation. Do not

co-locate the antennas used for this product, or operate them in conjunction with any other

antenna or transmitter.

Figure 1: PGP914

Callout

Description

Lens

Battery pull-tab

Enroll button

Tamper switch

*D-308495*

D-308495

D-308495PGP914Rev.0

Figure 2: Optimizing detection and avoiding false alarms

For more information refer to About PGP914.

Do not install near high-voltage electrical lines.

Keep away from heat sources.

Do not install outdoors.

Avoid direct sunlight.

Do not expose to air drafts.

Do not install behindpartitions.

Do not mount on an unstable surface.

Install the device on a solid and stable surface at a height of 1.8 m to 2.4 m (6 ft. to 8 ft.)

Warning!

Do not obscure partially or completely the device's field of view.

Enrolling the device

Refer to the control panel installation manual for the complete set of enrollment instructions

and testing procedures.

From the

Installation

menu, enter the

Device enrollment

menu and select the option to add

a new device.

Remove the battery pull-tab to power on the device and begin the auto-enrollment process.

If the battery pull-tab is not available or if the device does not automatically enroll, open the

device cover to trigger the enrollment. Alternatively, press the enroll button until the yellow

LED light turns on.

If requested, enter the PIN code printed on the device label.

To manually enroll the device:

Scan the QR Code on the device box, using the IQ4 camera if available, or see step b.

Manually enter the device ID, printed on the product label, in the format ID:125-xxxx.

Note:

If the device has been powered up for more than 2 hours it will be identified by

the system only after the device has been reset.

The PGP914 is enrolled with device ID 125-XXXX. In fall back mode it enrolls as PGx914 with

device ID 126-XXXX.

Select the desired zone.

Configure any device parameters that are required.

Mount and test the device. See Local diagnostics test for information on testing the device.

Configuring the device parameters

1. Enter the

DEVICE SETTINGS

menu and follow the configuration instructions for the device as

described in the following table.

PGP914 Wireless PIR Motion Detector Installation Guide

D-308495PGP914Rev.0

Table 1: Configuration options

Option

Action

Alarm LED

Define whether the alarm LED indication will be activated.

Optional settings:

LED ON

(default) and

LED OFF

Event counter

Define whether an alarm will be activated upon continued

motion (low sensitivity) or upon a single alarm event (high

sensitivity).

Optional settings: LOW sensitivity (default) and HIGH

sensitivity.

Disarm activity

Define whether the device is active when the system is

disarmed.

Optional settings:

NOT Active

while disarmed (default),

delay, 5 s delay, 15 s delay, 30 s delay, 1 min delay, 2 min

delay, 5 min delay, 10 min delay, 20 min delay and 60 min

delay.

VERY HOT > 35°C [>95°F]

Note:

Feature not eval-

uated by UL/ULC

Define whether or not the control panel will report a very

hot alert when the temperature rises above the threshold

value for at least the

Alert Delay

duration value. Alert restore

will occur when the temperature drops 1°C (1.8°F) below the

threshold for at least the

Restore Delay

duration.

Note:

The default threshold value for very hot is 35°C

(95°F).

Optional settings: See Configuring the Temperature Alerts.

COLD < 19°C [<66°F]

Define whether or not the control panel reports a cold alert

when the temperature drops below the threshold value for at

least the

Alert Delay

duration. Alert restore occurs when the

temperature rises 1°C (1.8°F) above the threshold for at least

the

Restore Delay

duration.

Note:

The default threshold value for cold is 19°C (66°F).

Optional settings: See Configuring the Temperature Alerts.

PGP914 Wireless PIR Motion Detector Installation Guide 3

D-308495PGP914Rev.0

Table 1: Configuration options

Option

Action

FREEZING < 7°C [<45°F]

Define whether or not the control panel will report a freezer

alert when the temperature drops below the threshold value

for at least the

Alert Delay

duration. Alert restore will occur

when the temperature rises 1°C (1.8°F) above the threshold

for at least the

Restore Delay

duration.

Note:

The default threshold value for freezing is 7°C

(45°F).

Optional settings: See Configuring the Temperature Alerts.

FREEZER > -10°C [<14°F

Define whether or not the control panel will report a freezer

alert when the temperature rises above the threshold value

for at least the

Alert Delay

duration. Alert restore will occur

when the temperature drops 1 °C (1.8 °F) below threshold for

at least the

Restore Delay

duration.

Note:

Thedefault threshold value for freezer is -10°C

(14°F).

Optional settings: See Configuring the Temperature Alerts.

4 PGP914 Wireless PIR Motion Detector Installation Guide

D-308495PGP914Rev.0

Configuring the temperature alerts

You can configure the temperature alerts with the settings described in the following table.

Table 2: Temperature alert configuration options

Option

Action

Threshold

Displays the last saved threshold value and provides the

installer with the ability to change the value using the back or

next button.

Disable/Enable

Define whether the panel reports an alert or not.

Alert delay

Define the amount of time the panel waits before an alert is

reported when the temperature exceeds the defined default.

The alert delay time values are:

Immediately

1 min

2 min

min

(default),

15 min

20 min

30 min

Restore delay

Define the amount of time the panel waits before an alert is

reported when the temperature exceeds the defined default.

The restore delay time values are:

Immediately

1 min

2 min

10 min

(default),

15 min

20 min

30 min

Opening and closing the device cover

To open the device cover, loosen the cover screw located on the underside of the device. See

A1 in the following figure.

Figure 3: Device cover removal

Push in the tab on the underside of the device and pull the cover upwards. See A2 in the

previous figure.

To close the device cover, clip the cover onto the device base and tighten the cover screw.

PGP914 Wireless PIR Motion Detector Installation Guide 5

D-308495PGP914Rev.0

Figure 4: Closing the device cover

Installing the pet mask

Install the pet mask if you require pet immunity. For pet rejection, the optimal installation height is

2.1

m (7 ft.). Pet immunity is up to 38 kg (85 lb).

Note:

Pet immunity is not supported at heights of 2.4 m (7.87 ft.) and above. Do not install the

pet mask if you are mounting the device at this height or above.

Insert the tabs at the base of the pet mask into the holes below the PIR sensor. See A1 in the

following figure.

Align the tabs on the sides of the pet mask with the holes on either side of the PIR sensor. See

A2 in the following figure.

Press down gently to install the pet mask.

Figure 5: Installing the Pet Mask

Close the device cover. See Figure 4.

6 PGP914 Wireless PIR Motion Detector Installation Guide

D-308495PGP914Rev.0

Removing the pet mask

Remove the pet mask if you do not require pet immunity.

Open the device cover. See Figure 3.

Remove the tabs at the sides of the pet mask from the holes on either side of the PIR sensor.

See A1 in the following figure.

Remove the tabs at the base of the pet mask from the holes below the PIR sensor. See A2 in

the following figure.

Gently lift the petmask.

Figure 6: Removing the Pet Mask

Close the device cover. See Figure 4.

Mounting the device using tape

Ensure the plug is attached to the back of the corner bracket. See Figure 9.

Peel the release liners off the two strips of double-sided adhesive tape and attach the tape to

the back of the bracket. See Figure 7. Use option A for flat surface mounting and B for corner

surface mounting.

PGP914 Wireless PIR Motion Detector Installation Guide 7

D-308495PGP914Rev.0

Figure 7: Double-sided adhesive tape placement on the bracket

Mount the bracket on the wall. For flat bracket see Figure 8. For corner bracket see Figure 11.

Align the device with the bracket. See A1 in the figure below.

Slide the device upward until a click is heard. See A2 and A3 in the figure below.

Figure 8: Attaching the device to the bracket

Mounting the device using screws

About this task:

Note:

Mounting using screws is required for UL/ULC commercial burglary and residential fire

type installations. Wall tamper (break-away segment) shall also be enabled.

Screw the bracket onto the wall.

Note:

Make sure to fasten the break-away segment to the frame. If the device is forcibly

removed from the wall, this segment will break away from the base, causing the tamper

switch to open.

8 PGP914 Wireless PIR Motion Detector Installation Guide

D-308495PGP914Rev.0

Wall tamper is required for UL/ULC commercial burglary and residential fire installations.

To mount the bracket on a flat surface, screw the mounting bracket to the wall. See A in

the following figure.

Figure 9: Flat bracket screw installation

Ensure the corner bracket plug is attached. See B in the following figure. To mount

the bracket on a corner see C or D in the figure below. C is for without back tamper

protection, and D is for with back tamper protection.

Figure 10: Corner bracket screw installation

Callout

Component

Flat surface mounting

Corner bracket with plug

Corner bracket with back tamper

Corner bracket without back tamper

Stopper snap

Break-away segment

Align the device with the bracket. See A1 in the following figure.

Slide the device upward until a click is heard. See A2 and A3 in the following figure.

PGP914 Wireless PIR Motion Detector Installation Guide 9

D-308495PGP914Rev.0

Figure 11: Attaching the device to the corner bracket

Disassembling the device from the bracket

Open the device cover. See Figure 3.

Remove the battery.

Use a screwdriver to press on the stopper snap to release the device base from the bracket.

See A1 in the following figure.

Slide the device downwards to remove it from the bracket. See A2 in the following figure.

Figure 12: Disassembling the device from the bracket

Replacing the battery

Note:

The device transmits a low battery signal upon detection of low voltage. It is

recommended to wait about 1 minute after battery removal before inserting the new battery.

CAUTION:

Risk of explosion if battery is replaced by an incorrect type. Dispose of used

batteries according to the manufacturer's instructions and according to local rules and

regulations.

Remove the device cover. See Figure 3.

Remove the battery. See A in the following figure.

Insert the new battery while observing battery polarity. See B in the following figure.

10 PGP914 Wireless PIR Motion Detector Installation Guide

Tabla de contenidos

Otros manuales de Sensor de seguridad de Johnson Controls

Johnson Controls

Johnson Controls Tyco Kantech T.REX Instrucciones de montaje

Johnson Controls

Johnson Controls PG8932 Manual de usuario

Johnson Controls

Johnson Controls PG9200AX Manual de usuario

Johnson Controls

Johnson Controls PGP922 Manual de usuario

Johnson Controls

Johnson Controls Tyco SR Series Manual de usuario

Johnson Controls

Johnson Controls PENN RLD-H10P Manual

Johnson Controls

Johnson Controls LC-203 Manual de usuario

Johnson Controls

Johnson Controls LC-203 Manual de usuario

Johnson Controls

Johnson Controls MP-802 PG+ Manual de usuario

Johnson Controls

Johnson Controls LC-200S Manual de usuario

Johnson Controls

Johnson Controls F62AA Manual de usuario

Johnson Controls

Johnson Controls PG9350SL Manual de usuario

Johnson Controls

Johnson Controls RLD-H10G Manual de usuario

Johnson Controls

Johnson Controls tyco Bentel Security BW-SHK Manual de usuario

Johnson Controls

Johnson Controls FTX-P2J Manual de usuario

Johnson Controls

Johnson Controls Tyco Visionic MP-843/XHM2 Manual de usuario

Johnson Controls

Johnson Controls LC-200 Manual de usuario

Johnson Controls

Johnson Controls LC-224 Manual de usuario

Johnson Controls

Johnson Controls HTD-432 PG2 Manual de usuario

Johnson Controls

Johnson Controls tyco Bentel Security BW-DTM Manual de usuario

Johnson Controls

Johnson Controls tyco Bentel Security BW-IRC Manual de usuario

Johnson Controls

Johnson Controls PG9350SL Manual de usuario

Johnson Controls

Johnson Controls PG9200AX Manual de usuario

Johnson Controls

Johnson Controls FS-1300 Manual de usuario

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
